Summary of Contents for CYCMOTOR Topology DS103
- Page 1 Topology DS103 Display Guide...
-
Page 2: Table Of Contents
TOPOLOGY DS103 Topology DS103 Display Guide Contents PRODUCT DETAILS ............................2 ..............................2 RODUCT ................................2 EATURES & M ............................2 IMENSIONS ATERIALS Materials ................................ 2 Dimensions ..............................2 ............................3 LECTRICAL PECIFICATIONS QUICK START GUIDE ............................4 FUNCTIONALITIES ............................1 .............................. -
Page 3: Product Details
TOPOLOGY DS103 Product Details Product Name Intelligent LCD display, model：DS103 Firmware: CYCMotor Ltd specific Features • Simple and lightweight, separate installation bracket design • High brightness, high contrast 3.5 inch coloured TFT screen • Clock function (clock is on when the display shutdown) •... -
Page 4: Electrical Specifications
TOPOLOGY DS103 Electrical Specifications • Power supply：DC 24V/36V/48V/ 52V • Rated current：30ma/36V • Shutdown leakage current：<1uA • Screen specification： 3.5” colored TFT（480*320pixels） • Communication method：UART (default) • Operating temperature：-20°C ~ 60°C • Storage temperature：-30°C ~ 80°C • Waterproof level：IP65 The information contained in this document is derived from the TFT LCD Display Guide provided by Zhejiang Topology Intelligent Technology Co., Ltd. -
Page 5: Quick Start Guide
TOPOLOGY DS103 Quick start guide After unboxing and installing your CYC motor system, there are two main things you need to set up. 1. Change your Battery No. setting according to your rated voltage. Within 15 seconds of turning on your display, long press the MENU button to enter the settings functions. -
Page 6: Functionalities
TOPOLOGY DS103 Functionalities Power On/ Off Press and hold the POWER button for 3 seconds to turn the display on/ off. Navigation The MENU button is used to go into your main settings page & your clear data page. It is also used to enter and select a setting or function. -
Page 7: Assist Level Operating
TOPOLOGY DS103 Assist Level Operating Press the UP/ DOWN button to change the assist level between level 1, 2, and 3. Note that “OFF” means no motor assistance will be given. Dark & Light Themed Dashboard Long press the UP button to switch between light and dark themed dashboard. -
Page 8: Walk Assist
TOPOLOGY DS103 Walk Assist Hold in the DOWN button to activate walk assist. Note that it takes 3 seconds to activate & will deactivate immediately when the button is released. Settings Long press the MENU button within 15 seconds of switching on the display to enter the “Settings”... -
Page 9: Clean Trip Data
TOPOLOGY DS103 Clean Trip Data Wait 15 seconds after starting up the motor system to enter the “Clean Data” menu. Long press the MENU button to clear the previous trip data. Please note that the trip data does not automatically clear once you restart the motor system. This is a manual process. -
Page 10: Compatibility
TOPOLOGY DS103 5. Fix and tighten the handlebar fixing screw with M3Hex wrench (locking torque is 0.8Nm). 6. Connect the display connector to the controller connector according to the label. Note: Damage caused by excessive torque is not covered by the warranty. -
Page 11: Certification
TOPOLOGY DS103 Certification CE / IP65 (waterproof) / ROHS. Be sure to contact technical_support@cycmotor.com if further assistance is needed. THANK YOU! The information contained in this document is derived from the TFT LCD Display Guide provided by Zhejiang Topology Intelligent Technology Co., Ltd. (otherwise known as Topology). All the information contained in this manual is published in good faith and for general information purpose only.
