- Page 1 Multi-Purpose Cutter Operation and Maintenance Manual Register your 91566 – 99427 WARRANTY within 30 days of purchase 888-376-7027 | BlueDiamondAttachments.com...
- Page 2 Serial Number: _____________________________ Blue Diamond is continually working to improve its Dealer Name: ______________________________ products. Blue Diamond reserves the right to make any improvements or changes as deemed practical and pos- Dealer Number: _____________________________ sible without incurring any responsibility or obligation...
-
Page 3: Table Of Contents
4.3 Blade Servicing..............20 4.4 Service Schedule ..............22 5. Parts ..................23-32 5.1 Main Frame Components – 44” Deck ....... 23 5.2 Main Frame Components – 32” Deck......25 5.3 Motor Assembly ..............26 5.4 Safety Decals ................. 30 6. Warranty ..................33 Blue Diamond® Attachments... -
Page 4: Introduction
Ensure that all safety pictograms/decals are legible. If pictograms/decals are worn, they must be replaced with new ones obtained from Blue Diamond and placed in the position indicated by this manual. Blue Diamond® Attachments... -
Page 5: Qualified Operators
If the cutter has been altered in any way from alertness or coordination while working. An the original design, Blue Diamond® does not operator who is taking prescription drugs must accept any liability for injury or warranty. -
Page 6: Attachment Information
Diamond® Attachments cutter. This equipment has been designed and manufactured to meet the needs of discerning users. The Blue Diamond® multi purpose cutter is designed to cut grass, weeds, and light brush. Many features incorporated into this cutter are the result of suggestions made by customers like Disposal of Equipment at End of Useful you. -
Page 7: Safety
• The cutter can throw objects up to 300 feet. To avoid serious injury or death, keep all thrown object shielding in place. Inspect area for potential thrown objects before cutting. Blue Diamond® Attachments... -
Page 8: Qualified Operators
• All fuels, most lubricants, and some coolant mixtures are flammable. Flammable fluids that are leaking or spilled onto hot surfaces or onto electrical components can cause a fire. Blue Diamond® Attachments... -
Page 9: General Safety Information
29. 5. Replacement parts must have replacement labels attached during installation and/or before the offset mower is used. 6. Labels are available from your authorized dealer at no charge. Blue Diamond® Attachments... -
Page 10: Operation
Be familiar with all controls before using this • Avoid cutting in reverse. equipment. • Approved Roll–Over Protective Structure (ROPS) or ROPS cab and seat belt. • Tractor Safety Devices; Slow Moving Vehicle (SMV) emblem, lighting. Blue Diamond® Attachments... -
Page 11: Attachment Installation
ADDITIONAL INFORMATION. Figure 1 Park the machine/attachment on a flat level surface. Place all controls in neutral, engage the park brake, stop the engine and wait for all moving parts to stop. Leave the operator’s position. Figure 2 Blue Diamond® Attachments... - Page 12 NOTE: An optional Hose Kit is available consisting of two male QD couplings, two female QD couplings, two 5/8” diameter hoses, and two pump fittings. Figure 7: Vertical mowing configuration Blue Diamond® Attachments...
- Page 13 2. Disconnect both the supply and return hoses to the mower. 3. Place the ends of the hoses in a place they will not be contaminated by dirt. 6. Replace locking tube in the hole it was previously in. Blue Diamond® Attachments...
- Page 14 10. Select the proper hole for the desired cutting position. Replace the red-handled t-pin. 9. Take the outside edge of the deck and reposition it into the offset position. 11. Reconnect supply hoses to the mower and the tractor. Blue Diamond® Attachments...
- Page 15 Replace the red-handled t-pin into the fixed 90 degrees position hole. NOTE: Use the top hold of the float bar to utilize the “floating” position seen below. 3. Reconnect supply hoses to the mower and to the tractor. Blue Diamond® Attachments...
- Page 16 1. After 1/2 hour of operation: Tighten all fasteners if necessary. Lubricate all grease fittings. 2. After 10 hours of operation, go to the normal servicing and maintenance schedule in section 4.1 on page 22. Blue Diamond® Attachments...
-
Page 17: Operation
Avoid operating the offset mower in reverse direction when possible. Check to make sure that there are no persons behind the offset mower, and use extreme care when maneuvering in reverse. Blue Diamond® Attachments... -
Page 18: Right Of Way Or Roadway Mowing
Visibility: Clean reflectors, SMV or SIS sign, and lights before towing. Make sure all the lights and reflectors required by highway and transport authorities are in place and can be seen clearly by all overtaking and oncoming traffic. Blue Diamond® Attachments... -
Page 19: Storage
4. Lubricate all grease points. Make sure all grease cavities have been filled with grease to remove any water residue from washing. 5. Touch up all paint nicks and scratches to prevent rusting. Blue Diamond® Attachments... -
Page 20: Maintenance
Replacement Parts: If replacement parts are necessary, genuine factory replacement parts must be used to restore the unit to its original specifications. Blue Diamond® will not accept responsibility for damage as a result of the use of unapproved parts. Safety Shields and Devices: When completing... - Page 21 Blade Sharpening DO NOT SHARPEN BLADES. The mower blades are two-sided and can be flipped over once to create a new cutting edge. Once both cutting edges have been used, the blades MUST be replaced. Figure 9 Blue Diamond® Attachments...
-
Page 22: Service Schedule
Before performing any type of welding repair Inspect blades before each use to determind that to the offset mower, contact Blue Diamond® for they are properly installed and in good condition. If approval. Repair welding must be done with care... -
Page 23: Parts
5. Parts 5.1 Main Frame Components — 44” Deck Manual Holder Blue Diamond® Attachments... - Page 24 503815 Clevis Pin 1/2” 503866 R-Clip 503875 / 503897 T-Handle OR Bent Handle pin with R-Clip 503866 R-Clip 503886 Deck with decals 503881 Safety shield spring 503848 Bolt & Locknut 3/8” X 2” Gr.2 503880 Safety Shield Blue Diamond® Attachments...
-
Page 25: Main Frame Components - 32" Deck
5. Parts 5.2 Main Frame Components — 32” Deck Manual Holder Blue Diamond® Attachments... - Page 26 503815 Clevis Pin 1/2” 503866 R-Clip 503875 / 503897 T-Handle OR Bent Handle pin with R-Clip 503866 R-Clip 503890 Deck with decals 503881 Safety shield spring 503848 Bolt & Locknut 3/8” X 2” Gr.2 503891 Safety Shield Blue Diamond® Attachments...
-
Page 27: Motor Assembly
5. Parts 5.3 Motor Assembly Blue Diamond® Attachments... - Page 28 Cutter Blade (sold in pairs) for 44” 503820 Cutter Blade (sold in pairs) for 32” 503202 Blade Bolt Kit (sold in pairs) 503847 Blade carrier nut 1” – 12 LH Thread 503853 Cotter pin 1/8” X 2.25” 503888 Hub & Spindle Complete Kit Blue Diamond® Attachments...
- Page 29 5. Parts 5.4 Safety Decal Locations Blue Diamond® Attachments...
-
Page 30: Safety Decals
5. Parts 5.4 Safety Decal Locations Blue Diamond® Attachments... - Page 31 5. Parts 5.4 Safety Decal Locations Cont’d Blue Diamond® Attachments...
- Page 32 This page intentionally left blank Blue Diamond® Attachments...
-
Page 33: Warranty
ATTACHMENTS before work is performed. ® The BLUE DIAMOND® PRODUCT SUPPORT TEAM will advise repairs and applicable parts exchanges. Tampering with the failed part may void the warranty. This warranty does not include freight or delivery charges incurred when returning machinery for servicing. Dealer mileage, service calls, and pickup/delivery charges are the customers’... - Page 34 QUALITY | DEPENDABILITY | INTEGRITY Blue Diamond® Attachments 4512 Anderson Road, Knoxville, TN 37918 888-376-7027...
