Huvema HU 430 DM-4 SUPER VARIO Manual

Drilling - milling - machines
Hide thumbs

Advertisement

Quick Links

Download this manual
D R I L L I N G
-
M I L L I N G
-
M A C H I N E S
HU 430 DM-4 SUPER VARIO

Advertisement

loading
Need help?

Need help?

Do you have a question about the HU 430 DM-4 SUPER VARIO and is the answer not in the manual?

Questions and answers

Related Manuals for Huvema HU 430 DM-4 SUPER VARIO

Summary of Contents for Huvema HU 430 DM-4 SUPER VARIO

  • Page 1 D R I L L I N G M I L L I N G M A C H I N E S HU 430 DM-4 SUPER VARIO...

  • Page 2: Table Of Contents

    able of conTenTs General safety rules for all machines Additional safety rules Control panel and electric scheme Before operation After operation Adjustment of the head Reparing drilling Lifting Cleaning & Lubricating Use of main machine parts Precaution for operation Preparing milling Adjusting table slack Clamping, table base and machine base Speed changing...

  • Page 3: General Safety Rules For All Machines

    hU 430 DM-4 s rilling illing Machine Uper ario eneral safeTy rUles for all Machines N.B.: Read the instructions carefully in order to avoid any problems. As with all machinery there are certain hazards involved with operation and use of this machine. Using the machine with respect and caution will considerably lessen the possibility op personal injury.

  • Page 4: Additional Safety Rules

    DDiTional safeTy rUles Always keep in mind that: • the machine must be switched off and disconnected from the power supply during maintenance and repairs, • clamped workpieces may only be measured when the machine is switched off. Never lean over the machine, mind loose clothing, ties, jewellery etc. and wear a cap. Do not remove safety devices or guards.
  • Page 5 lecTric scheMe CHANGES AND T YPING ERRORS RESER VED...
  • Page 6 ELECTRICAL CONTROL PARTS LIST: ITEM DESIGNATION DESCRIPTION AND FUNCTION Q’TY CU113A1AAC24V AEN-1084LE1-2B YLC-029 EFB-110N E.STOP GLEB221BR START XBG221AGT MEA-9112 APXBG221AB APGCS2232AB RJ2MDE16A INVERTER LS70040K7 UPL.S X3M306N2KA DOWN L.S MY2NJAC24V APPLN22CW24VL MOTOR AC/1HP/400V/50HZ/3PH/4P CHANGES AND T YPING ERRORS RESER VED...
  • Page 7 CHANGES AND T YPING ERRORS RESER VED...
  • Page 8 CHANGES AND T YPING ERRORS RESER VED...
  • Page 9 CHANGES AND T YPING ERRORS RESER VED...
  • Page 10 CHANGES AND T YPING ERRORS RESER VED...
  • Page 11 CHANGES AND T YPING ERRORS RESER VED...
  • Page 12 CHANGES AND T YPING ERRORS RESER VED...
  • Page 13 CHANGES AND T YPING ERRORS RESER VED...
  • Page 14 CHANGES AND T YPING ERRORS RESER VED...

  • Page 15: Explosion Drawings And Parts Lists

    18. e xplosion Drawings anD parTs lisTs 18.1 h CHANGES AND T YPING ERRORS RESER VED...
  • Page 16 CHANGES AND T YPING ERRORS RESER VED...

  • Page 17: Base

    18.2 b CHANGES AND T YPING ERRORS RESER VED...
  • Page 18 CHANGES AND T YPING ERRORS RESER VED...
  • Page 19 CHANGES AND T YPING ERRORS RESER VED...

  • Page 20: Central Lubricating Oil-Feeding Equipment

    18.3 c enTral lUbricaTing oil feeDing eqUipMenT CHANGES AND T YPING ERRORS RESER VED...
  • Page 21 CHANGES AND T YPING ERRORS RESER VED...
  • Page 22 All rights reserved. No part of this booklet may be reproduced in any form, by print, photoprint, microfilm or any other means without written permission from the publisher. © Huberts bv, Kennedylaan 14, Veghel, the Netherlands. Internet: www.huvema.nl CHANGES AND T YPING ERRORS RESER VED...
