7.

SPECIFICATIONS

7.1

Technical Specifications

Model
Type
Theoretical max.
speed
Power consumption
Voltage tolerance
Approvals
7.2

Dimensions

Height
Width
Length
Weight
7.3

Other Specifications

Noise level
Operating
temperature
Humidity
7.4

Document Specifications

Paper quality
Paper size
Folding capacity
Enclosure sizes
FD 6102
Fold and insert system for small office use
1350 inserts per hour, depending on application
100-240 VAC/ 50-60 Hz /Maximum 3 A
100-240 VAC:+6%/-10%
230 VAC: +10%/-10%
EMC Certificate conform EMC-Directive
FCC Certificate conform 47CFR, part 15
CB Certificate conform IEC 60950-1
UL Listed I.T.E. (Information Technology Equipment), conform
UL-IEC 60950-1, file E153801
Conform NEN-EN-IEC 60950-1 and derivatives
22"
16.9"
26" without catch tray
79.3 lb
< 69 dBA (according to ISO 11202)
17°C - 34°C (62.6°F - 93.2°F)
20%-90%
minimum: 17.5# bond
maximum: 30# bond
Minimum width: 5.6"
Maximum width: 8.9"
Minimum length: 3.5"
Maximum length: 14.0"
V-fold - 5 sheets (80 g/m²)
C-fold - 3 sheets (80 g/m²)
Double V-fold - 2 sheets (80 g/m²)
Standard BRE (Business Reply Envelopes)
Maximum length: 6.22"
27
