KWC AVA 2.0 A105 Installation And Service Manual page 22

A105
12.468.041.000FL
12.468.051.000FL
12.468.641.000FL
Z.538.628.000
1
Z.536.568.000
2
Z.639.263
3
Z.536.032
4
Z.537.134.000
5
Z.538.704.000
6
Z.635.815.000
7
Z.638.911
8
Z.538.315
9
Z.638.338
10
A105
12.468.031.000FL
12.468.071.000FL
12.468.631.000FL
Z.538.629.000
1
Z.536.568.000
2
Z.639.263
3
Z.536.032
4
Z.537.134.000
5
Z.538.704.000
6
Z.635.815.000
7
Z.638.911
8
Z.538.315
9
Z.638.338
10
22
S 24
8 Nm + 1 Nm
5
M20 x1
10
7
8
1
2
3
4
6
9
KWC802658-01 11/20
