THE BEST SAUNA EXPERIENCE TO HAVE! am very glad that you have invested in the Saunum device, and I believe that our innovative techno logy will offer you a wonderful and extraordinary sauna experience. I have a degree in thermal engineering and come from Southern Estonia, where my love for saunas began.
Page 3
A moist steamy sauna, a therapeutic salt sauna, or a healthy aroma sauna – all of these functions are available on Saunum’s devices to create a truly relaxing sauna experience. When us-...
Page 4
Saunum congratulates you on choosing an innovative sauna control unit!
DIRECTION FOR USE Using the heater and instructions for bathing _______________ Control unit ________________________________________ Indicators __________________________________________ Heating ___________________________________________ Using the Saunum sauna climate function _________________ Configuring the sauna _________________________________ Sauna scheduling ____________________________________ Technical data _______________________________________ INSTRUCTIONS FOR INSTALLATION Installing the control panel _____________________________...
Persons with reduced physical, sensory, or mental capabilities, or persons with a lack of experience and knowledge, should use this device only under constant and close adult supervision and only after consulting with a physician. Before using sauna, all users should consult with a physician to ensure that they have no health conditions that would make sau- na bathing unsafe, and discuss time and...
Page 7
the sauna if they feel light-headed, dizzy, or • It is vital to install the device experience heat exhaustion. It is prohi bited according to the instructions for to sleep inside the heated sauna. Users installation and use. Failure to should take care to avoid falling asleep carefully follow all instructions while using the sauna.
USING THE HEATER AND INSTRUCTIONS FOR BATHING • Always check before heating that heater once the heater or sauna room there are no objects on the heater or door is equipped with a safety switch near the heater's safety distance des- (door sensor).
CONTROL UNIT The Saunum in sauna control unit Leil Plus consists of a control panel (1), a power unit (2), a temperature sensor (3), a door sensor (4) and temperature sensor and power unit cords (5). The control unit can be used to pre-set the...
Page 10
The control unit will automatically turn the • Remote control – with the Saunum heating elements on and off to maintain mobile app. the desired temperature.
INDICATORS “Sauna ready” starting Value increase time Value decrease Temperature Repeat sauna Sauna duration session Climate device Climate device speeds Light 1. Menu Heater power kW 2. Light 3. Time Glass surface area 4. Heater state 5. WiFi connection Sauna room volume Screen lock / Child lock Move to next view...
Setting a sauna ready time. ing the desired numbers. The “sauna ready” time is when the sauna’s steam zone temperature has reached the selected temperature level. USING THE SAUNUM SAUNA CLIMATE 2. Tap the "Start" button to start heating FUNCTION the sauna.
The with your phone: device is produced according to EU/US • Disable the mobile data on your standard. Saunum and its re-sellers do not phone. take any responsibility of the consequences when incorrect region has been selected.
Page 14
The Saunum Wi-Fi control panel is desig- 5. Opening the Saunum app download. ned to control the electric sauna heater. Scan the QR code that opens the Saunum With the control panel, it is also possi app on Google Play or the App Store. Some...
Page 15
7. Setting the time zone. 9. Setting units (1/2). 10. Setting the temperature unit (2/2). The local time zone (UTC) configuration is required if the sauna control panel has been previously connected to the Wi-Fi network. 8. Setting the date and time.
Page 16
11. Entering sauna data (1/2). 13. Setting passwords. 14. Creating a sauna type (1/4). 12. Entering sauna data (2/2).
17. Creating a sauna type (4/4). Mild Mild 16. Creating a sauna type (3/4). SAUNA SCHEDULING Mild Open the Menu. 1. Menu Saunum allows you to schedule a sauna in advance by setting up a weekly schedule. To do this, tap "Schedule" from the menu.
Page 18
Always make sure the heater and area You can cancel the session by tapping around the heater are clear before a sched- "Cancel”. uled sauna session. If you do not cancel it, the session will be- Note that the planned sauna session does gin and, after the desired temperature is not start if the door has been left open at reached, it will run for 30 minutes, after...
TECHNICAL DATA CONTROL PANEL: • Temperature adjustment range 40–100 °C. • Pre-setting the schedule for the week. • Allows you to set the operating time of the heater: up to 6 hours in a private sauna, up to 12 hours in a public sauna.
Page 21
SAUNA STEAM ZONE min 5 x 0.75 mm2 Cables according to heater manual 1. CONTROL PANEL 4. DOOR SENSOR 2. DATA CABLE (supplied by the installer) 5. TEMPERATURE SENSOR 3. POWER UNIT 6. HEATER (sold separately)
INSTRUCTIONS the wall; if this is not possible, it must be in- stalled on the wall surface. In that case ca- FOR INSTALLATION ble must be rated for temperature at least 85º Celcius. The control panel must be installed on the WARNING! Failure to install the product wall, in a place protected from water splash- in accordance with all instructions here...
Page 23
2. Thread the data cable through the hole in the wall mount. 3. Fasten the wall mount to the wall with screws.
Page 24
4. Connect the data cable to the 5. Press the control panel into the wall connector. mount.
INSTALLING THE POWER UNIT 1. Open the cover of the power unit. SAUNA STEAM ZONE The installation spot must be dry, and its 2. Drill holes in the case and attach the temperature must not exceed 65 °C. power unit to the wall or electrical panel.
ELECTRICAL CONNECTIONS The connection of the power unit is shown • If the connection and installation on the diagram of electrical connections. cables are located higher than 1000 mm from the floor of the sau- For more information on connecting the na room or inside the walls of the heater, see the heater installation and op- sauna room, they must be able to...
Page 27
TEMPERATURE SENSOR DOOR SENSOR CONTROL PANEL HEATER...
INSTALLING • Screw the temperature sensor onto the wall (see figure). THE DOOR SENSOR • The temperature sensor cannot be placed above the heater. A door sensor is a magnetic switch that is at- tached to the door frame of the sauna room. •...
Page 29
The airflow near an air vent cools down the Note! The reason for the switch-off must be sensor, giving the control unit inaccurate clarified before the reset. temperature readings. As a result, the heater might overheat. The overheating protector reset button. •...
Device if it is used in • Adaptation or modification of the a public sauna. device for any purpose other than The Saunum warranty starts from the date that indicated in the instructions of purchase and includes all manufacturer- for use;...
INSTALLATION PROTOCOL Saunum sauna’s control unit model: ___________________________________________ Date of purchase: _________________________________________________________ Original purchaser: _______________________________________________________ Place of installation: _______________________________________________________ Purchased from: _________________________________________________________ Date of electrical installation: _______________________________________________ Signature of the installer: ___________________________________________________ Notes: _________________________________________________________________ Customer’s contact (name, email address): ______________________________________...
Page 32
EC declaration of conformity Manufacturer: Saunum Saunas OÜ certifies that the product: Insauna control unit saunum leil plus complies with the requirements of the following directives of the European Parliament and of the Council, provided that the installation has been carried out in accordance with the installation instructions issued by the equipment manu- facturer.: IEC/EN 60335-2-53...
