  • Page 1 ® Health, Mobility, Adventure Cargo Cargo User Manual...
  • Page 2 Dear Esteemed Buyer, Thanks for purchasing the Moov8:Cargo. This bike is an electric pedal assist bike (EPAB or Pedalecs). It is equipped with pedals and a power-assisted electric motor, which can be driven by both manpower and with the assistance of electric power.
  • Page 3 Cargo Diagram Included in the box:  User Manual  Battery Charger Display Derailleur shifter  Front Basket  USB Port  Brake lever x 2 Tool kit Saddle Assembly Stem folding lock Seat post buckle Front basket Rear light...
  • Page 4 Assembly (1/3) Step 1. Saddle assembly Open seat post buckle. Step 2. Saddle assembly Insert seat post, adjust seat height and direction, and lock Step 3. Pedal assembly seat post buckle. Take the pedal and tools from packing carton, tighten pedal and lock with wrench.
  • Page 5 Assembly (2/3) Step 4. Stem assembly ① Tear off sticker on the ② Set head tube ③ Set the Gasket and ④ Unfold the handlebars stem and screw out bolt (unfolded) in the frame, screw A into stem, and lock and lock the folding lock.
  • Page 6 Assembly (3/3) Step 5. Installing the front wheel ① Loosen the quick release lever and insert into the fork ② tighten the quick release level. dropouts.
  • Page 7 Battery remove/install Removing battery ① Turn the key Power indicator light with one hand Power button ② pulling out the USB port #1 battery with your other hand Battery charging port Assembling battery Push the battery into slot. Precautions for battery use: ...

  • Page 8: Display Control

    Display Control  power on/off Display Press and the hold power button to switch on and switch off.  assist level selection Press the “+” up or “-“down button to increase or decrease the pedal assist level 1-5 Display Control ...

  • Page 9: Routine Maintenance

    Routine Maintenance Service Frequency Lubrication Frequency Frequency Component Lubricant How to Lubricate Task Chain Derailleur Chain Lube or Light Oil Brush on or Squirt Pulleys Derailleurs Chain Lube or Light Oil Brush on or Squirt Be sure batteries are fully charged Weekly Brake Calipers Oil Can...

  • Page 10: Battery Charging And Maintenance

    Battery charging and maintenance A well-maintained battery can perform well even after many kilometers of riding. Please keep the battery 15 ℃ to 40 ℃ when the condition of charging. Do not store below/above - 20 ℃ ~ 50 ℃. Do not store or charge the battery at temperatures outside the stated limits.
  • Page 11 Do not ride in the rain or wet conditions.  Don’t rotate the handle violently while driving at high speed.  Wear a helmet and protective clothing to avoid possible injury.  Do not leave the Cargo charging overnight or unattended. An overheated battery can catch fire.
  • Page 12 As with all mechanical components, the e-bike is subject to wear and high stresses. Different materials and components may react to wear or stress fatigue in different ways. If the design life of a component has been exceeded, it may suddenly fail possibly causing injuries to the rider.

  • Page 13: Specifications

    Specifications Electric/Battery Mechanical & other specs. Motor Power: 36V 250W Bafang motor Brake Type: front and rear Tektro hydraulic disc brakes Battery: 36V 9.6 Ah Frame: 6061 aircraft aluminium frame Range: up to 70 km (by PAS) Wheel Hub: 20” x 2.3-inch KENDA Charge time: 3-4 hours Gears: Shimano 7 speed gears Max Speed: 25km/hr...

  • Page 14: Warranty

    Warranty Your Moov8:Cargo is covered under a limited 24 months warranty Limits of warranty: The warranty will be null and void if:   24 months warranty for the frame & damaged to the bike was due to exceeding the motor.
  • Page 15 Moov8:Cargo's battery must be stored in environments with a temperature ranging Pregnant women or people who are unwell must not use Moov8-Cargo. from -20 to 45°C. Do not place Moov8 - Cargo where the temperature is over 50°C.  When feeling unwell physically or mentally due to illness or under the When the ambient temperature falls below -20°C, the battery will enter into a self-...
  • Page 16  When you need to ride Moov8:Cargo to a remote area, do not go alone. Even if you strongly recommended that you do not ride the e-bike under the above- have partners on your journey, you still have to prepare yourselves well for mentioned conditions to avoid potentially serious dangers.
  • Page 17 ® moov8.com.au Move out with Moov8...
