- Page 1 Health, Mobility, Adventure...
- Page 2 Dear Esteemed Buyer, Thanks for purchasing the Moov8:X. This bike is an electric pedal assist bike (EPAB or Pedalecs). It is equipped with pedals and a power-assisted electric motor, which can be driven by both manpower and with the assistance of electric power.
- Page 3 X Diagram Included in the box: Manual • Derailleur shifter • Charger • Tool kit Display Brake lever x2 saddle Stem folding lock Seat post buckle Rear light Headlight Battery lock Battery case Motor Disc 1 Disc 2...
- Page 4 Assembly STEP 1. Saddle assemble STEP 2. Pedal assemble Pedal folding& unfolding Open seat post buckle picture 1 & 2 insert Take the pedal and tools Push the pedal in horizontal and turn seat post, adjust seat height and direction, from packing carton, tighten 90°...
- Page 5 Assembly Stem fold lock Screw A Screw A Gasket stickier Screw B Screw C STEP 3. Stem assemble ② Set head tube (unfolded) ③ Set the Gasket and screw A ① Tear off sticker on ④ Unfold the handlebars and in the frame, and lock screw into stem, and lock by Allen the stem and screw out...
- Page 6 Assembly STEP 4. installing front wheel Loosen the quick release lever and insert into the fork dropouts and tighten the quick release level.
-
Page 7: Removing Battery
Battery ① power indicator light, each light means about 25% power ② power button ③ USB charging port ④ battery charging port ① ① ② ③ ④ ② Precautions for battery use Please fully charge the battery when charging for the first time. When the battery is not in use for a long time, Removing battery take out and charge at least once a month. -
Page 8: Power On/Off
Controls power on/off Press and hold power button to switch on and switch off. up/down mode Press “+” up or “-“down button to increase or decrease the Peddle Assist level 1-5 light on/off Press and hold “+” up button for 3 second can turn on/off the light walking assist function... -
Page 9: Routine Maintenance
Routine Maintenance Service Checklist Frequency Component Lubricant How to Lubricate Frequency Task Chain Derailleur Chain Lube or Light Oil Brush on or Squirt Be sure batteries are fully charged Pulleys Chain Lube or Light Oil Before every Check tire pressure Brush on or Squirt Weekly ride... - Page 10 Battery charging and maintenance: Please keep the battery 15 ℃ to 40 ℃ when the condition of charging. Do not store below/above - 20 ℃ ~ 50 ℃. Do not A well-maintained battery can perform well even after many kilometers of riding. store or charge the battery at temperatures outside the stated limits.
- Page 11 When riding any ebike, care must be taken to avoid personal injury or damage to the ebike. Damage to the ebike may cause loss of power and affect the performance of the product. Please note the follow before using the ebike: Check if all parts of the Moov8 – M1 are well installed without damage. √...
- Page 12 As with all mechanical components, the e-bike is subject to wear and high stresses. Different materials and components may react to wear or stress fatigue in different ways. If the design life of a component has been exceeded, it may suddenly fail possibly causing injuries to the rider.
-
Page 13: Specification
Brake Type: front and rear dual disc brakes Battery: Samsung Cell 36V 7.8 Ah/8.7 Ah/9.6 Ah/10.5 Ah Frame: 6061 aircraft aluminium frame Range: 40-60 km Wheel Hub: 20” x 1.95-inch KENDA with reflector Charge time: 3-4 hours Gears: Shimano 7 speed gears Max Speed: 25km/hr... -
Page 14: Warranty
18 months warranty for battery √ water damage, physical damage, incorrect charging or (covers malfunction, but does not use of charger other than provided by Moov8 for the X. cover deterioration of performance) √ charging/soring the battery at temperatures outside the √... - Page 15 Improper assembly may cause risks of loss of control, collision or falls. When • Never try to ride Moov8 - X in rainy weathers or on wet roads, as wet and slippery assembling the X, take care to apply appropriate force, as either screwing roads may reduce the tyre’s resistance and lengthen the X braking distance, and...
- Page 16 Nights or other environments with poor light conditions make it hard for • When you need to ride Moov8 – X to a remote area, do not go alone. Even if you riders, drivers and pedestrians to notice each other properly, therefore it's...
- Page 17 Move out with Moov8...
