Owner's Operation and Instruction Manual
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU
TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
SAFETY NOTICE:
If this heater is not properly installed, a house fire
may result. For your safety, follow the installation
instructions. Never use make shift compromises
during the installation of this heater. Contact local
building or fire officials about permits, restrictions
and installation requirements in your area.
CAUTION!
Please read this entire manual before you
install or use your new room heater. Failure
to follow instructions may result in property
damage, bodily injury, or even death.
Improper Installation Could Void Your
Warranty!
WONDERWOOD
MODEL: B2941E(B)
SAVE THESE INSTRUCTIONS
Ce produit peut vous exposer à des produits chimiques, y compris le
monoxyde de carbone, qui est connu dans l'État de Californie pour causer
le cancer, des malformations congénitales et / ou d'autres problèmes de
reproduction. Pour plus d'informations, visitez www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is know to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
United States Stove Company
227 Industrial Park Road
South Pittsburg, TN 37380
Certified to: UL 1482-11 (R2015) and
Not approved for use in mobile homes, do not
U.S. Environmental Protection Agency
Certified to comply with 2015 particulate
P.O. Box 151
Report#: 0215WS054S
Certified to: ULC-S627-00
install in a mobile home
emissions standards.
853134-0405H
Advertisement
Table of Contents
Related Manuals for United States Stove Company WONDERWOOD
Summary of Contents for United States Stove Company WONDERWOOD
- Page 1 This product can expose you to chemicals including carbon monoxide, which is know to the State of California to cause cancer, birth defects and/or other reproductive harm. For more information, go to www.P65warnings.ca.gov United States Stove Company 227 Industrial Park Road P.O. Box 151...
- Page 2 The instructions pertaining to the installation of your wood stove comply with UL-1482-11 (R2015), and ULC-S627-00 standards. This manual describes the installation and operation of the Wonderwood, B2941E(B) wood heater. This heater meets the 2015 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters sold after May 15, 2015.
-
Page 3: Tools And Materials Needed For Installation
TOOLS AND MATERIALS NEEDED FOR INSTALLATION TOOLS MATERIALS • Pencil • Chimney Connection- 6” Diameter Black Steel • Masuring Tape or 6 foot rule pipe (24 gauge minimum) and elbow(s) either • Tin Snips adjustable1 or corrugated as necessary • Drill and 1/8” dia. bit •... -
Page 4: Operation
Assembly Instructions BLOWER ASSEMBLY-OPTIONAL INSTALLATION 1. Remove the Panel (A) using tin snips or knock out using a hammer and chisel careful not to distort the mounting surface. 2. Attach the Blower Mounting Box (B) to the rear of the unit using four(4) of the supplied #10 screws. -
Page 5: Safety Notice
INSTRUCTIONS FOR LATCH OPERATION Follow these instructions to operate you unit safely when operating the feed door. 1. Turn handle clockwise to the 12 o’clock position (A), pull the door open until you engage the second step (B). 2. Hold the door in that position for approximately 10 seconds. 3. -
Page 6: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES It is of utmost importance that the clearances to combustible materials be strictly adhered to during installation of the stove. Refer to the tables below. (458mm) (1296mm) (458mm) 23.25” (2134mm) (407mm) (989mm) (356mm) (305mm) • Floor to ceiling height must be at least 7’ (2.13m) in all cases. NON-COMBUSTIBLE CONSTRUCTION •... -
Page 7: Floor Protector
FLOOR PROTECTOR When the heater is used on a combustible floor, use an Underwriters Listed floor protector that conforms to UL Standards (UL 1618) and CAN/ULC for Canada, that provides at minimum type 1 ember protection. The floor protector should be under the stove, 16” (18” for Canadian Instillations)beyond the front and 8” beyond each side of the fuel loading and ash removal opening. -
Page 8: Chimney Connector (Stove Pipe)
CHIMNEY CONNECTOR (STOVE PIPE) Your chimney connector and chimney must have the same diameter as the stove outlet (6”). If this is not the case, we recommend you contact your dealer in order to insure there will be no problem with the draft. The stove pipe must be made of aluminized or cold roll steel with a minimum thickness of 0.021”... - Page 9 CHIMNEY Take into account the chimney’s location to insure it is not too close to neighbours or in a valley which may cause unhealthy or nuisance conditions. Your wood stove may be hooked up with a 6” factory built or masonry chimney.
-
Page 10: Factory Built Chimney
FACTORY BUILT CHIMNEY When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. Maintain proper clearance to the structure as recommended by the manufacturer. -
Page 11: Masonry Chimney
MASONRY CHIMNEY Ensure that a masonry chimney meets the minimum standards of the National Fire Protection Association (NFPA) by having it inspected by a professional. Make sure there are no cracks, loose mortar or other signs of deterioration and blockage. Have the chimney cleaned before the stove is installed and operated. When connecting the stove through a combustible wall to a masonry chimney, special methods are needed. -
Page 12: Combustible Wall Chimney Connector Pass-Throughs
COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS Method A. 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent. -
Page 13: Do Not Burn
WOODSTOVE UTILIZATION This heater is designed to burn natural wood only. Higher efficiencies and lower emissions generally result when burning air dried seasoned hardwoods, as compared to softwoods or to green or freshly cut hardwoods. DO NOT BURN: 1. Garbage; 10. -
Page 14: Operational Tips
Smaller pieces of wood will dry faster. All logs exceeding 6” in diameter should be split. The wood should not be stored directly on the ground. Air should circulate through the cord. A 24” to 48” air space should be left between each row of logs, which should be placed in the sunniest location possible. - Page 15 Before igniting the paper and kindling wood, it is recommended that you warm up the chimney. This is done in order to avoid back draft problems often due to negative pressure in the house. If such is the case, open a window slightly near the stove and twist together a few sheets of newspaper into a torch.
-
Page 16: Timer Instructions
SECONDARY AIR allows the woodstove to burn clean. This preheated air enters the upper firebox just below the baffle plate. This superheated air mixed with the wood gases and flames ignites, reaching temperatures in this unit range. Without Secondary Air these volatile gases would exit the stove unburned as creosote, smoke, particulates, and high levels of Carbon Monoxide, greatly decreasing efficiency. - Page 17 STEP 3 Using a canned air duster, gently spray any accumulative dust or buildup off of the timer. WARNING: Be careful not to use too much air pressure as this may cause potential damage to the timer STEP 4 Use a general machine oil (3-IN-ONE) to apply a small drop of oil to each of the locations shown below.
-
Page 18: Creosote Formation And Need For Removal
HEATING Controlled combustion is the most efficient technique for wood heating because it enables you to select the type of combustion you want for each given situation. The wood will burn slowly if the wood stove air intake control is adjusted to reduce the oxygen supply in the combustion chamber to a minimum. -
Page 19: Ash Disposal
Attention: This wood heater needs periodic inspection and repair for proper operation. It is against federal regulations to operate this wood heater in a manner inconsistent with operating instructions in this manual. If a chimney or creosote fire occurs, close all dampers immediately. Wait for the fire to go out and the heater to cool, then inspect the chimney for damage. -
Page 20: Repair Parts
Repair Parts... - Page 21 Repair Parts Key Part No. Description Qty. 852472 Hi/Lo Label 610835 Cabinet Front Weldment/Assy. 89687 Thermostat Knob Black 27468 Air Box Cover 610184 Air Distribution Box 69207 Draft Plate Weld Assembly 25550 H.pin Drft Damper 40075 Frame, Draft Door 88090 Gasaket 27388 Dial Bracket...
- Page 22 Repair Parts Key Part No. Description Qty. 892767 Wooden Knob 27486 Door Handle 27462 Door Catch 40763 Feed Door 27489 Fire Door Hinge 88032 1” Rope Fiber 41” 40764 Cast Door 27460 Ash Door Hinge 88032 1” Rope Fiber 27” In order to maintain warranty, components must be replaced using original manufacturers parts purchased through your dealer or directly from the appliance manufacturer.
- Page 23 Repair Parts Part No. Description Qty. 610235 Baffle Weldment 610230 Top Brick Rack 89066 Firebrick (4-1/2 X 9) 27472 Brick Spacers 27564 Floor Back 610221 Floor (Welded) 610223 Cleanout Cover Weldment In order to maintain warranty, components must be replaced using original manufacturers parts purchased through your dealer or directly from the appliance manufacturer.
- Page 24 • Repair or replacement of parts that are subject to normal wear and tear during The warrantor of record is United States Stove Company, PO Box 151, 227 the warranty period. These parts include: paint, pellet, and the discoloration Industrial Park Road, South Pittsburg, Tennessee 37380. Phone number: (800)- of glass.
-
Page 25: Service Record
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary. - Page 26 2. The part description / La description de la pièce ______________________________________________ 3. The model number / Le numéro de modèle ___________________________________________________ 4. The serial number / Le numéro de série _______________________________________________________ United States Stove Company 227 Industrial Park Road P.O. Box 151...
