IMI CORNELIUS INC.
www.cornelius.com
Nordic
Model CCM0830 1, 1030 1
Service Parts Manual
(Includes 50Hz. Units)
Publication Number: 631806064
Revision Date: October 1, 2008
Revision: A
Visit the IMI Cornelius web site at
www.cornelius.com
for all your Literature needs.
CCM0830 1-CCM1030 1 Service Parts Manual
Manual Number 631806064

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nordic CCM0830 1 and is the answer not in the manual?

Questions and answers

Related Manuals for Cornelius Nordic CCM0830 1

Summary of Contents for Cornelius Nordic CCM0830 1

  • Page 1 Model CCM0830 1, 1030 1 Service Parts Manual (Includes 50Hz. Units) Publication Number: 631806064 Revision Date: October 1, 2008 Revision: A Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs. CCM0830 1-CCM1030 1 Service Parts Manual Manual Number 631806064...
  • Page 2 SERVICE PARTS MANUAL 22 INCH WIDE ICE SERIES CUBERS MODEL-ICE0320, ICE0520 Includes 50Hz. Units ICE-O-Matic 11100 East 45th Ave Denver, Colorado 80239 Part Number 9081297-01 PD04/02 Rev1/05...

  • Page 3: Table Of Contents

    Control Box Specific Compressor Components Harvest Assist Assembly Remote Condenser Telephone Number 800-238-3600 All Departments E-Mail: tech.service@Cornelius.com Website: www.cornelius.com The CCM Series Service Manual is available separately, Part Number 631806061 Note: Model Number Suffix Indicates Machine Voltage As Follows 1=115/60/1 2=208-230/60/1...

  • Page 4: Cabinet Assembly

    CCM Series Service Parts Cabinet Assembly Page 2...

  • Page 5: Exterior Panels

    CCM Service Parts Item Model Number No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description 620204811 620204811 620204774 620204774 620204457 620204457 620204930 620204930 620204884 620204884 620204776 620204776 620204809 620204809 620204810 620204810 620204444 620204444 620204337 620204337 620204885 620204885 620204382...

  • Page 6: Evaporator/Water System

    CCM Series Service Parts Evaporator/Water System Page 4...

  • Page 7: Evaporator/Water System

    CCM Series Service Parts Item Model Number No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description 620204873 620204873 620204874 620204874 620204294 620204294 620204453 620204453 620204429 620204429 620204494 620204494 620204486 620204486 620204495 620204495 620204869 620204869 620204493 620204493 620204521 620204521...

  • Page 8: Air Cooled

    CCM Series Service Parts Air Cooled Page 6...

  • Page 9: Air Cooled

    CCM Series Service Parts Item Model Number No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description 620204688 620204686 620204612 620204612 620204614 620204614 620204476 620204476 620204603 620204603 620204534 620204534 620204535 620204535 620204596 620204596 620204478 620204478 620204882 620204882 620204924 620204924...

  • Page 10: Water Cooled

    CCM Series Service Parts Water Cooled Page 8...

  • Page 11: Water Cooled

    CCM Series Service Parts Item Model Number No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description 620204688 620204686 620204883 620204883 620204614 620204614 620204476 620204476 620204602 620204602 620204534 620204534 620204535 620204535 620204587 620204587 620204465 620204465 620204474 620204474 620204882 620204882...

  • Page 12: Remote

    CCM Series Service Parts Remote Page 10...

  • Page 13: Remote

    CCM Series Service Parts Item Model Number No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description 620204688 620204686 620204612 620204612 620204614 620204614 620204476 620204476 620204603 620204603 620204534 620204534 620204535 620204535 620204606 620204606 620204474 620204474 620204882 620204882 620204924 620204924...

  • Page 14: Control Box

    CCM Series Service Parts Control Box Page 12...

  • Page 15: Control Box

    CCM Series Service Parts Item Model Number No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description 620204553 620204553 620204557 620204557 620204548 620204548 620204551 620204551 620204559 620204559 620204545 620204545 See Below See Below See Below See Below See Below See Below 620204555...

  • Page 16: Harvest Assist Assembly

    CCM Series Service Parts Harvest Assist Assembly Page 14...
  • Page 17 CCM Series Service Parts Item Model Number No. CCM0830 5 1 CCM0830 2 1 CCM1030 5 1 CCM1030 2 1 Description 620204366 620204366 620204631 620204631 620204569 620204569 620204483 620204483 620204481 620204481 620204439 620204439 620204484 620204484 620204424 620204424 620204427 620204427 620204451 620204451 620204516 620204516...

  • Page 18: Remote Condenser

    CCM Series Service Parts Remote Condenser Page 16...
  • Page 19 CCM Series Service Parts CCM0530R CCM0630R Item RC05001 RC06002 620204581 620204581 620204369 620204369 620204436 620204436 620204580 620204580 620204647 620204646 620204425 620204425 620204426 620204426 620204448 620204448 620204436 620204436 620204371 620204371 620204373 620204373 620204374 620204374 620204375 620204375 620204373 620204373 620204377 620204377 602204372 602204372 620204370 620204370...
