Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per MSI Prestige P100 9th 9SF-041EU o cerca il tuo prodotto tra le migliori offerte di PC Desktop e Workstation Prestige Series Personal Computer Prestige B929...
Contents Copyright and Trademarks Notice ��������������������������������������������������������������������������iii Revision ������������������������������������������������������������������������������������������������������������������iii Upgrade and Warranty ��������������������������������������������������������������������������������������������iv Acquisition of Replaceable Parts ����������������������������������������������������������������������������iv Technical Support ���������������������������������������������������������������������������������������������������iv Green Product Features ������������������������������������������������������������������������������������������iv Environmental Policy �������������������������������������������������������������������������������������������� v Chemical Substances Information �������������������������������������������������������������������������� v Battery Information �������������������������������������������������������������������������������������������������� v Safety Instructions ���������������������������������������������������������������������������������������������������vi CE Conformity �������������������������������������������������������������������������������������������������������...
If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor� Alternatively, please try the following help resources for further guidance� Visit the MSI website for technical guide, BIOS updates, driver updates and other information via http://www�...
Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at gpcontdev@msi�com for information regarding proper Disposal, Take-back, Recycling, and Disassembly of MSI products�...
Safety Instructions ◙ Read the safety instructions carefully and thoroughly� ◙ All cautions and warnings on the equipment or user’s manual should be noted� Keep the User’s Guide that comes with the package for future reference� Keep this equipment away from humidity and high temperature� Lay this equipment on a reliable flat surface before setting it up.
Page 7
Preface Never pour any liquid into the opening that could damage or cause electrical shock� Place the power cord in a way that people are unlikely to step on it� Do not place anything on the power cord� ◙ When installing the coaxial cable to the TV Tuner, it is necessary to ensure that the metal shield is reliably connected to protective earthing system of the building�...
1� this device may not cause harmful interference, and 2� this device must accept any interference received, including interference that may cause undesired operation� MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www�msi�com...
Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products�...
Overview Congratulations on purchasing the Prestige Personal Computer� This system is your best PC choice� The feature packed platform also gives you an exciting PC experience�...
Packing Contents User Manual & Personal Computer Power Cord Quick Guide (Optional) Keyboard Mouse (Optional) (Optional) * Please contact us immediately if any of the items is damaged or missing� * The illustrations are for reference only and your packing contents may slightly vary depending on the model you purchased�...
Overview System Overview 11 12 Prestige B929 (Z390)
Page 14
Drive Activity Indicator LED blinks when the system is accessing the internal storage drives� USB 3.1 Gen 1 Port (Type-C) USB 3�1 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed data transfer for various devices, such as storage devices, hard drives, video cameras, etc�...
Page 15
Overview S/PDIF-Out This S/PDIF (Sony & Philips Digital Interconnect Format) connector is provided for digital audio transmission to external speakers through an optical fiber cable. LAN Jack The standard RJ-45 LAN jack is provided for connection to the Local Area Network (LAN)� You can connect a network cable to it� Yellow Green/ Orange Color...
Page 16
USB 2.0 Port Power Jack Power supplied through this jack supplies power to your system� Important High-speed devices are recommended for USB 3�1 ports whereas low-speed devices, such as mouse or keyboard, are suggested to be plugged into the USB 2�0 ports�...
Page 18
Drive Activity Indicator LED blinks when the system is accessing the internal storage drives� USB 3.1 Gen 1 Port (Type C) USB 3�1 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed data transfer for various devices, such as storage devices, hard drives, video cameras, etc�...
Page 19
Overview Used as a connector for a miicrophone� USB 3.1 Gen 2 Port USB 3�1 Gen 2, the SuperSpeed USB 10Gbps, delivers high-speed data transfer for various devices, such as storage devices, hard drives, video cameras, etc� LAN Jack The standard RJ-45 LAN jack is provided for connection to the Local Area Network (LAN)�...
Page 20
Power Jack Power supplied through this jack supplies power to your system� Important High-speed devices are recommended for USB 3�1 ports whereas low-speed devices, such as mouse or keyboard, are suggested to be plugged into the USB 2�0 ports� 1-10...
Page 21
Overview h Upper Side View Power Button Press the power button to turn the system on and off. Ventilator The ventilator on the enclosure is used for air convection and to prevent the equipment from overheating� Do not cover the ventilator� 1-11...
Safety & Comfort Tips Choosing a good workspace is important if you have to work with your PC for a long period of time� 1� Your work area should have enough illumination� 2� Choose the proper desk and chair and adjust their height to fit your posture when operating�...
Getting Started Hardware Setup Connecting the AC Power and Power On 1� Connect the power cord to the system and electrical outlet� 2� Press the power button to power on the system� Important When unplugging the AC power cord, always hold the connector part of the cord� Never pull the cord directly�...
System Operations This chapter provides you with essential information on system operations� Important All information is subject to change without prior notice�...
Power Management Power management of personal computers (PCs) and monitors has the potential to save significant amounts of electricity as well as deliver environmental benefits. To be energy efficient, turn off your display or set your PC to sleep mode after a period of user inactivity�...
Page 29
System Operations Waking the System Up The computer shall be able to wake up from power saving mode in response to a command from any of the following: ■ the power button, ■ the network (Wake On LAN), ■ the mouse, ■...
Network Connection (Windows 10) Wired Network 1� Right-click [Start] and select [Network Connections] from the list� 2� Select [Ethernet] and then [Network and Sharing Center]� 3� Select [Set up a new connection or network]�...
Page 31
System Operations 4� Choose [Connect to the Internet] and click [Next]� 5� Select [Broadband (PPPoE)] to connect using DSL or cable that requires a user name and password� 6� Type the information from your Internet Service Provider (ISP) and click [Connect] to establish your LAN connection�...
Page 32
Wireless Network 1� Go to [Start] , click [Settings] and select [Network and Internet]� 2� A list of available WLAN connections pops up� Choose a connection from the list� 3� To establish a new connection, select [Network and Sharing Center]� 4�...
System Operations System Recovery (Windows 10) The purposes for using the System Recovery Function may include: ■ Restore the system back to the initial status of original manufacturer’s default settings� ■ When some errors have occurred to the operating system in use� ■...
Page 34
Reset this PC 1� Go to [Start] , click [Settings] and select [Update and security]� 2� Select [Recovery] and click [Get started] under [Reset this PC] to start the system recovery� 3. The [Choose an option] screen pops up. Choose between [Keep my files] and [Remove everything]�...
Page 35
System Operations Keep my files 1. Select [Keep my files]. 2� The [Your apps will be removed] screen shows a list of apps that will need to be reinstalled from the web or installation discs� Click [Next] to continue� 3� The next screen will show the changes to be made during the process� Click [Reset] to start the system reset�...
Page 36
Remove everything 1� Select [Remove everything]� 2� If you have multiple hard drives, a screen will pop up, asking you to choose between [Only the drive where Windows is installed] and [All drives]� 3. Then select between [Just remove my files] and [Remove files and clean the drive]. 3-10 4�...
Recovering the system with the F3 Hotkey Follow the instructions below to continue: 1� Restart the PC� 2� Press the F3 hotkey on the keyboard promptly when the MSI greeting appears on the display� 3� On the “Choose an Option” screen, tap “Troubleshoot”�...
