R C D F U S E D
C O N N E C T I O N
U N I T
Model: TFP10WL
R C D S I N G L E &
D O U B L E S O C K E T S
Single Models:
TFA01W, TFP02WL, TFA03M, TFP04ML
Double Models:
TFA05W, TFP06WL, TFA07M, TFP08ML
e
e
Downloaded from
Elcodis.com
electronic components distributor
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Timeguard TFP10WL
Summary of Contents for Timeguard TFP10WL
- Page 1 R C D F U S E D C O N N E C T I O N U N I T Model: TFP10WL R C D S I N G L E & D O U B L E S O C K E T S...
- Page 2 General The Timeguard range of RCDs provides protection against fire hazard and rapid double pole disconnection from electric shock for the appliance and cable connected to it. They comply fully with BS7288 and BS1363. They are designed to mount on either a BS4662 recessed box or a BS5733 surface mount box (plastic versions only).
-
Page 3: Pack Contents
Pack Contents 1 TFP10WL 2 3.5mm diameter screws 32mm long 1 Warning label 1 Instruction leaflet N’ Fused Connection Unit Connections Supply Brown (Red) (Live) to L IN Supply Blue (Black) (Neutral) to N IN Supply Bare Earth Wire, sleeved Green/Yellow, to E... - Page 4 RCD Single & Double Sockets Single: TFA01W, TFP02WL, TFA03M, TFP04ML Double: TFA05W, TFP06WL, TFA07M, TFP08ML Single Metal Socket Colour coded, positive action buttons for Status indicator shows Testing (T) and Resetting (R) the RCD red for ‘ON’ Active 30mA Test (T) Before Switched for convenience and...
- Page 5 The RCD socket units come in two forms, a latching (passive) version with the third letter set to ‘P’ (passive) and the last letter ‘L’ in the type number and a non-latching (active) version which has the third letter set to ‘A’ (active). The latching version, if set, will retain closed contacts if the mains supply is interrupted –...
-
Page 6: Socket Connections
Socket Connections Supply Brown (Red) (Live) to L Supply Blue (Black) (Neutral) to N Supply Bare Earth Wire, sleeved Green/Yellow, to E (for double sockets one or both terminals can be used as convenient) Metal Clad Lock rings, with a maximum thickness of 4.2mm and a maximum diameter of 25.7mm must be used on the inside of the box on TL (top left) and TR (top right) entries to secure the gland or conduit. - Page 7 2 x 2.5 sq mm for the ring main or 1 x 2.5 sq mm for the spur. TFP10WL only – Fit the appropriate BS1362 fuse to suit the load appliance to be connected. The cable connecting the load appliance (spur only) should be rated according to the fuse fitted to the connection unit.
- Page 8 General RCD Operation Always test the RCD before use. To test: RESET – press the grey/blue button marked Reset (R), the status indicator should show red. TEST – press the red button marked Test (T), status indicator should show black. This indicates that the RCD has been tripped and power has been disconnected from the outlet.
- Page 9 Fully Complies With: BS7288 & BS1363 Minimum Box Depth Required: 25mm Fixed Cable Capacity: 1 x 8mm or 2 x 4mm or 3 x 2.5mm Flexible Cable Capacity: 10.5mm diameter maximum (TFP10WL only) Downloaded from Elcodis.com electronic components distributor...
- Page 10 Safety Issues to Remember • Electricity can be dangerous, use of an RCD should not be regarded as a substitute for basic electrical safety precautions. • Always test the RCD before use. If the test procedure is not completed satisfactorily or an appliance continues to trip the RCD seek professional advice and switch off the appliance.
- Page 11 THREE YEAR GUARANTEE 3 Year Guarantee In the unlikely event of this product becoming faulty due to defective material or manufacture within 3 years of the date of purchase, please return it to your supplier in the first year with proof of purchase and it will be replaced free of charge.
- Page 12 HELPLINE 020-8450-0515 For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND 020-8452-1112 or email csc@timeguard.com Designed in the U.K. 67-058-126 Downloaded from Elcodis.com electronic components distributor...
