Dynalabs DYN-MS-100 Product Manual

100 n ms shaker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model DYN-MS-100
100 N MS Shaker
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DYN-MS-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Dynalabs DYN-MS-100

Summary of Contents for Dynalabs DYN-MS-100

  • Page 1 Model DYN-MS-100 100 N MS Shaker Product Manual...
  • Page 2 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Product Support If at any time you have questions or problems with the DYN-MS-100 shaker, please contact a Dynalabs engineer at: Phone: +90 312 386 21 89 (9 a.m.

  • Page 3: Table Of Contents

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ............................4 2) General Information ..........................4 2.1) Unpacking and Inspection ......................4 2.2) System Components ........................

  • Page 4: Introduction

    The moving element is usually suspended by an elastic membrane. DYN-MS-100 has a moving coil (driving coil) whose current is controlled for vibration generation. The stationary magnetic field is produced by a permanent magnet.
  • Page 5 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Item Description Sine Frequency Generator Gain Knob External Signal Input Trunnion handle Cooling port DC Power Input...

  • Page 6: Specifications

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.4) Specifications Parameters Specifications Output Force (Sinus) 100 N Frequency 0-7.5 kHz Displacement (Peak to Peak) 10 mm Suspension Carbon Fiber Maximum Acceleration...

  • Page 7: Outline Drawing

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.5) Outline Drawing The dimensional properties of DYN-MS-100 shakers are given below. All dimensions are in mm.

  • Page 8: Operation And Installation

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3) Operation and Installation 3.1) General The general shaker connector configuration is given below. 3.1.1) External Signal Mode Connect DC power source and drive signal to shaker power input and signal input respectively.

  • Page 9: Internal Signal Mode

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.1.2) Internal Signal Mode The amplifier can generate sine signal from 1Hz to 15 kHz with 1 Hz increments that the user can adjust with the Sine Frequency Generator Switch.

  • Page 10: Shaker-Structure Interaction (Stingers)

    Force or impedance head sensors can be mounted on the other side. The Dynalabs modal shakers stinger sets include 4 collet, 1 nut and 3 stinger rod sizes .The chuck consists of two pieces. The collet squeezes the stinger with the tightening effect of the nut.

  • Page 11: Shaker Mounting

    Additional inertial weight may be attached to the bottom of the shaker using hot glue. 3.5) Power Requirements DYN-MS-100 has an integrated power amplifier which is powered by its power adaptor. Please note the output voltage and current ratings of the adaptor in a replacement adaptor is to be used.

  • Page 12: Frequency Response

    4) Maintenance and Troubleshooting The DYN-MS-100 shaker is a sealed device requiring no maintenance if the operating instructions described in this manual are followed. Repair of damage to the coil, exciter body or magnet core should not be attempted.

  • Page 13: Grounding

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 5.1) Grounding The shaker is internally grounded via the power adapter. However, if further grounding is necessary a grounding socket is available on the shaker as shown. Appropriate grounding cable is also supplied with the shaker.

  • Page 14: Declaration Of Conformity

    • MIL-STD-810-H-2019 (Test Methods: 501.7 - High Temperature, 502.7 - Low Temperature, 514.8 - Vibration, 516.8 – Shock) DYNALABS MÜHENDİSLİK SANAYİ TİCARET LİMİTED ŞİRKETİ declares that above mentioned products meet all the requirements of the above mentioned standards and regulations.
