  • Page 1 Model DYN-PM-100 100 N PM Shaker Product Manual...
  • Page 2 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Product Support If at any time you have questions or problems with the DYN-PM-100 shaker, p lease contact a Dynalabs engineer at: Phone: +90 312 266 33 34 (9 a.m.

  • Page 3: Table Of Contents

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ..........................4 2) General Information ........................4 2.1) Unpacking and Inspection ....................4 2.2) System Components ......................4 2.3) Theory of Operation ......................4 2.4) Specifications ........................6 2.5) Outline Drawing ........................7...

  • Page 4: Introduction

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 1) Introduction The DYN-PM-100 is designed to p rovide dynamic force excitation for vibration and shock testing of small sized mechanical structures.
  • Page 5 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. DYN-PM-100 has a moving coil (driving coil) whose current is controlled for vibration generation. The stationary magnetic field is produced by a permanent magnet.

  • Page 6: Specifications

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.4) Specifications Parameters Specifications Output Force (Sinus) 100 N Output Force (Shock) 200 N Frequency 0-7.5 kHz Payload 1.5 kg Displacement (Peak to Peak) 10 mm...

  • Page 7: Outline Drawing

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.5) Outline Drawing The dimensional properties of DYN-PM-100 shakers are given below.

  • Page 8: Operation And Installation

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3) Operation and Installation 3.1) General The general shaker connector configuration is given below. 3.1.1) External Signal Mode Connect DC power source and drive signal to shaker power input and signal input respectively.

  • Page 9: Internal Signal Mode

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.1.2 ) Internal Signal Mode The amplifier can generate sine signal from 1Hz to 15kHz with 1 Hz increments that the user can adjust with the Sine Frequency Generator Switch.

  • Page 10: Power Requirements

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.2) Power Requirements DYN-PM-100 has an integrated power amplifier which is powered by its power adaptor. Please note the output voltage and current ratings of the adaptor in a replacement adaptor is to be used.

  • Page 11: Frequency Response

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.4) Frequency Response The following figure shows the acceleration levels/Input voltage versus frequency of the shaker. 4 ) Mounting Interface The shaker has seven M6 holes for DUT and fixture connection as shown in the following figure.

  • Page 12: Maintenance And Troubleshooting

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 5 ) Maintenance and Troubleshooting The DYN-PM-100 shaker is a sealed device requiring no maintenance if the operating instructions described in this manual are followed. Repair of damage to the coil, exciter body or magnet core should not be attempted.

  • Page 13: Declaration Of Conformity

    • MIL-STD-810-H-2019 (Test Methods: 501.7 - High Temperature, 502.7 - Low Temperature, 514.8 - Vibration, 516.8 – Shock) DYNALABS MÜHENDİSLİK SANAYİ TİCARET LİMİTED ŞİRKETİ declares that above mentioned products meet all the requirements of the above mentioned standards and regulations.
