Visual Tour - SimpleTech SimpleDrive Portable HSD1000 Quick Start Manual

V T
ISUAL OUR
DC-IN Jack
Socket for connecting an optional AC power
adapter to SimpleDrive Portable.
HDD Activity LED (Green)
Indicates disk drive read/write activity.
Power LED (Red)
Indicates SimpleDrive Portable is receiving power.
Integrated USB Cable
USB interface for connecting SimpleDrive Portable
to your computer.
USB/AUX PWR Cable
Use this cable to extend the length of the USB
cable or to provide a secondary USB bus power
source to SimpleDrive Portable.
USB socket (Type A)
Connects to SimpleDrive Portable to provide signal
and USB bus power source.
Type A USB plug (Power only)
Connects to the computer's USB port to provide a
secondary USB bus power source to SimpleDrive
Portable.
Type A USB plug (Signal and Power)
Connects to the computer's USB port to provide
signal and primary USB bus power source to
SimpleDrive Portable.
