Visual Indicators - SimpleTech SimleDrivePS Quick Start Manual

V T
ISUAL OUR
HDD Activity LED (Blue)
Flashes to indicate disk drive read/write activity.
Power LED (Red)
Illuminates when SimpleDrivePS is receiving power.
DC-IN Jack
Socket for connecting an AC power adapter to
SimpleDrivePS.
Mini USB Socket
Mini-B USB socket for connecting SimpleDrivePS to your
computer.
USB/AUX PWR Cable
Use this cable to connect SimpleDrivePS your
computer.
• Mini-B USB plug
Connects to SimpleDrivePS to provide signal and
USB bus power source to SimpleDrivePS.
• Type A USB plug (Power and signal)
Connects to a USB port on your computer to
provide signal and USB bus power source to
SimpleDrivePS.
• Type A USB plug (Power only)
Connects to a USB port on your computer to
provide a secondary USB bus power source to
SimpleDrivePS.
3
