Assembly Instructions
NORNA-40 Cabinet
A (20 pcs) B (20 pcs)
8x35mm 15x12mm
F (8 pcs) G (4 pcs)
3x18mm 4x12mm
K (20 pcs) L (20 pcs)
6x10x2mm 6x14x2mm
3.28.22 so
C (20 pcs) D (6 pcs)
7x35mm
H (13 pcs) I (16 pcs)
4x15mm 6x20mm
M (1 pc) N (8 pcs)
4x21x57mm
E (6 pcs)
J (4 pcs)
6x55mm
O (16 pcs) P (2 pcs)
150x35x18mm
PLEASE NOTE: Check that you have received all
components and hardware before assembling.
If you are missing any parts, contact your retailer.
Q (2 pcs) R (12 pcs)
385x180x68mm 20mm
During assembly, hand tighten screws only. When
the screws are in place, tighten completely.
S (1 pc)
20x215mm
1 of 9
