- Page 1 4-748-481-12(1) Television Reference Guide HOME Help Guide Customer Support and Contact: http://www.sony-asia.com/support KDL-50W667G / 43W667G / 32W617G...
-
Page 2: Table Of Contents
Introduction To attach the Table-Top Thank you for choosing this Sony product. Stand, refer to the Setup Before operating the TV, please read this manual thoroughly and retain it for future reference. Guide. Note • Before operating the TV, please read the “Safety Information”... - Page 3 • Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mount Bracket to the TV set. The This receiver complies with the minimum requirements as supplied screws are designed as indicated by illustration when specified in National Telecommunications Commission, measured from the attaching surface of the Wall-Mount Bracket.
-
Page 4: Parts And Controls
Parts and Controls Controls and Indicators KDL-50W667G / 43W667G KDL-32W617G (Power) /+/– When the TV is off, Press to power on. When the TV is on, Press and hold to power off. Press repeatedly to change the function, then press + or –... -
Page 5: Using Remote Control
Using Remote Control Remote Control Parts Description The remote control shape, location, availability and function of remote control buttons may vary depending on your region/country/TV model. Note • The number 5, , CH/PROG + and AUDIO buttons have tactile dots. Use the tactile dots as references when operating the TV. - Page 6 Number buttons (Mute) Mute the sound. Press again to restore the sound. Use with the 0-9 buttons to select digital CH/PROG +/–// channels. In TV mode: Select the channel. (Text) In Text mode: Select the next () or Display text information.
-
Page 7: Connection Diagram
Connection Diagram You can connect a wide range of optional equipment to your TV. Note • Terminals and labels may vary depending on region/country/TV model. KDL-50W667G / 43W667G Digital still camera/ Camcorder/USB storage media HDMI Device Audio System with ARC/HDMI Device Audio System Router with Optical... - Page 8 KDL-32W617G Digital still camera/ Camcorder/USB storage media HDMI Device Audio System with ARC/HDMI Device Audio System with Optical Audio Input Router Headphone/Audio System/Subwoofer VCR/Video game equipment/ DVD player/Camcorder Cable/Antenna < 14 mm Note * Do not plug in the digital audio connector adapter when not connected to optical audio cable to disable red LED light from DIGITAL AUDIO OUT (OPTICAL) terminal.
- Page 9 USB 1/2 • Connecting a large USB device may interfere with other connected devices beside it. • When connecting a large USB device, connect to the USB 1 port. HDMI IN 1/2 • HDMI interface can transfer the digital video and audio on a single cable.
-
Page 10: Installing The Tv To The Wall
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation. -
Page 11: Troubleshooting
Analog: M Digital: ISDB-T If the problem persists, contact your dealer or Color/video system Sony service centre with the number of times Analog: PAL (Video only)/SECAM (Video only)/ the LED indicator flashes red (interval time is NTSC3.58/NTSC4.43 (Video only) three seconds). Press on the TV to turn it off, Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC... - Page 12 Power requirements via HDMI and HDR videos of built-in Netflix 19.5 V DC with AC adapter and YouTube App only. (See Sony support Rating: Input 100 V – 240 V AC, 50/60 Hz website for more information). Screen size (measured diagonally) (Approx.) •...
- Page 13 • “PlayStation” is a registered trademark and “PS4” is a trademark of Sony Interactive Entertainment Inc. • For DTS patents, see http:// patents.dts.com. Manufactured under license from DTS, Inc. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS Digital Surround is a trademark of DTS, Inc.
- Page 20 Help Guide http://rd1.sony.net/help/tv/gphl4/h_ph/ © 2019 Sony Corporation...
