Easily Programmed Six-Digit User Code
•
Simple 9-Volt Battery Replacement
•
Lock Bolt Retraction and Extension Controlled by Turning Keypad Ring Manually
Increasing Dependability and Longer Battery Life
•
Up to 10,000 Openings on One 9-Volt Battery
•
User Code Stored in Memory Within Safe Door Shielded, Along with Internal Lock,
From Drill Attacks by Ball Bearing or Hardened Steel Protection Plate
•
User Code Remains in Memory for Years Even if Battery or Keypad Destroyed or
Removed
•
After Five Incorrect User Code Attempts Lock Begins Lockout Delay Period Disabling
All Inputs to Keypad Delaying Further Tampering
OPERATING INSTRUCTIONS
Opening Safe for the First Time
S&G® Spartan™ D-Drive Electronic Lock is shipped unlocked. Open the door by rotating
the hub on the front of the safe clockwise and pulling the safe door open. If the hub
seems stiff, insert a solid round wooden stick into one of the handle holes and turn the
hub clockwise to open. Then install the handles, if applicable.
Installing the Battery
Rhino Metals highly recommends using a 9-volt Duracell
battery with a "Use Date" of at least four years in the future.
1.
Unlock and pull the safe door open.
2.
To remove the keypad, pull the tab (marked with blue arrow) on
the outer ring and rotate the ring around the keypad counter-
clockwise slightly.
3.
Carefully pull the ring away from the safe to prevent damage to
the wiring harness, revealing the battery cavity.
4.
With the battery cavity accessible, install a new 9-volt battery
into the terminals and tuck the battery and wiring harness back
into the battery cavity.
5.
Push the ring back towards the safe and rotate the ring
clockwise. The ring will slide back towards the safe and click
into place.
6.
With the door open, test the operation of the lock several
times before closing and locking the safe.
SARGENT AND GREENLEAF®(S&G®)
SPARTAN™ D-DRIVE
ELECTRONIC LOCK
Model 1007
or Energizer
alkaline
®
®
Tab
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for S&G SPARTAN 1007
Summary of Contents for S&G SPARTAN 1007
- Page 1 SARGENT AND GREENLEAF®(S&G®) SPARTAN™ D-DRIVE ELECTRONIC LOCK Model 1007 • Easily Programmed Six-Digit User Code • Simple 9-Volt Battery Replacement • Lock Bolt Retraction and Extension Controlled by Turning Keypad Ring Manually Increasing Dependability and Longer Battery Life • Up to 10,000 Openings on One 9-Volt Battery •...
- Page 2 Operating the Electronic Lock To unlock the safe, enter the existing six-digit user code. Each key press is confirmed with an audio and visual (LED flash) signal. The lock will indicate a valid user code entry with a double signal. Within four seconds, turn the outer ring clockwise until it stops to retract the lock tang.
- Page 3 Lost User Code for Electronic Locks Most safes with electronic locks have their override user code on file at Rhino Metals The override user codes are tracked by model and serial number. If user code is lost, a $25.00 research fee will be assessed for restoring the user code. The request requires completing and providing proper documentation of ownership of the safe.
- Page 4 TROUBLESHOOTING Common Issues Possible Solutions Replace the battery with a new 9-volt Duracell® or Energizer® alkaline battery with a “Use Date” of at least four years in the future. Any pressure on the side of the lock tang might prevent the lock from operating properly.
- Page 5 INSURANCE COVERAGE Rhino Metals highly recommends purchasing additional insurance coverage to the total value of the contents in the safe. The Limited Lifetime Warranty does not insure any of the contents inside the safe. Most homeowner insurers require purchasing endorsements or riders for valuables exceeding the standard coverage policy for personal items.
- Page 6 LIMITED LIFETIME WARRANTY Rhino Metals offers to the original Purchaser, a Limited Lifetime Warranty, covering defects in workmanship, material, damage by unlawful attempted or actual break-in, and fire. Warranty applies only to safes located in the United States and Canada, purchased at an authorized Rhino Metals safe dealer, and that have been used solely in residential applications.
- Page 7 EXTENDED LOCK WARRANTY (SOLD SEPARATELY) Warranty must be purchased within 30 days of safe purchase to become valid. Rhino Metals offers to the original Purchaser, an Extended Lock Warranty, covering defects in workmanship and material on either electric or manual locks. Locks and electronic keypads carry a five-year Warranty for labor and parts.
