Summary of Contents for TP-Link tapo C125

Page 2: Table Of Contents
Contents About This Guide ······················································································································· 1 Introduction ·································································································································· 2 Appearance ·································································································································· 3 Before You Start ························································································································· 5 Set Up Your Camera ················································································································· 6 Set Up Using Amazon Frustration-Free Setup ·························································· 7 Set Up HomeKit ······················································································································· 11 Install Your Camera ················································································································ 13 Authentication ··························································································································...
Page 3: About This Guide
About This Guide This guide provides a brief introduction to the AI Home Security Wi-Fi Camera and the Tapo app, as well as regulatory information. Please note that features available in Tapo may vary by model and software version. Tapo availability may also vary by region. All images, steps, and descriptions in this guide are only examples and may not reflect your actual Tapo Camera experience.
Page 4: Introduction
• Ultra-Wide 140° Field of View – Capture more views with an ultra-wide field of view. • Magnetic Mounting – Effortlessly set up your Tapo C125 using its versatile magnetic base. • Activity Zones – Notifies you when activity is detected in specific zones.
Page 5: Appearance
Appearance Front Back Side microSD microSD Card Slot Insert a microSD card (not included) and initialize it on the Tapo app for local recording. Adjust View Tilt and rotate the camera and stand for your desired viewing angle. Microphone Lens Speaker Privacy / Reset Button System LED...
Page 6 System LED Indication Starting up, video recording or Solid red live streaming Blinking red and blue Ready for setup Blinking blue quickly Connecting to Wi-Fi Blinking red slowly Connected to Wi-Fi Solid blue Connected to the cloud Camera updating or Blinking red quickly camera resetting...
Page 7: Before You Start
Before You Start Position your camera’s adjustable stand for setup. If the camera lens is hidden, do not manually push the lens cap up to prevent scratches. Note: After setup, you can press the Privacy/Reset button once to turn off Privacy Mode and the camera lens will appear. Physical Privacy Shutter/ Reset...
Page 8: Set Up Your Camera
Step 3. Add Your Camera Get the Tapo app from the App Store or Open the app, and log in with your TP-Link ID. Tap the button in the app and search for Google Play, or by scanning the QR code If you don't have an account, create one first.
Page 9: Set Up Using Amazon Frustration-Free Setup
Set Up Using Amazon Frustration-Free Setup What is Amazon Frustration-Free Setup? Amazon Frustration-Free Setup can help connect and set up Tapo smart devices in fewer steps, without having to remember and re-enter your Wi-Fi password on each device. To use this feature, confirm the following: ●...
Page 10 How to use Amazon Frustration-Free Setup with Tapo devices 1. Open the Amazon Alexa app. Then tap More and select Skills & 2. Enter Tapo in the search bar and choose Tapo. Games.
Page 11 3. Tap the ENABLE TO USE button. 4. Log in with your TP-Link ID that has bound to your Tapo device, and tap Authorize. After authorized successfully, the message Tapo has been successfully linked will come up.
Page 12 5. Plug in your Tapo device and the setup will complete automatically in two minutes. For setting up more Tapo devices, just plug in and enjoy! Done! If this device displays on the Home page in the Tapo app, it indicates this device has been successfully associated with your Amazon account and joined your Wi-Fi network automatically.
Page 13: Set Up Homekit
To control a Tapo device in the Home app, we must follow Apple guidelines. As a result, some Tapo app features will be disabled. To know about the disabled features in the Home app, refer to https://www.tp-link.com/support/faq/3653/ or scan the QR code on the right.
Page 14 • Move your iPhone/iPad and the Tapo device closer to the router to get a stronger Wi-Fi signal. • Factory reset the Tapo device and restart your phone. Then try again. • Refer to the FAQ below for detailed instructions: https://www.tp-link.com/support/faq/3390/...
Page 15: Install Your Camera
Install Your Camera When you finish adding your camera in the Tapo app, you can set it on a table or shelf. You can also mount it using its versatile magnetic base. Follow the steps below to install your new camera. Option 1: Set on a table or shelf Option 2: Mount to metallic surfaces 1.
Page 16 Option 3: Stick to a clean wall Option 4. Mount to the wall 1. Attach the included adhesive to the back of the 1. Stick the mounting template to the desired metal plate properly. mounting place. Drill two holes according to the template.
Page 17: Authentication
Authentication FCC compliance information statement Product Name: AI Home Security Wi-Fi Camera Model Number: Tapo C125 Component Name Model I. T .E. Power Supply T090060-2B1 Responsible Party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: http://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: sales.usa@tp-link.com...
Page 18 We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
Page 19 We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
Page 20 EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tapo.com/en/support/ce/. RF Exposure Information This device meets the EU requirements (2014/53/EU Article 3.1a) on the limitation of exposure of the general public to electromagnetic fields by way...
Page 21 UKCA Mark UK Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.tapo.com/support/ukca/.
Page 22 為避免本器材影像畫面遭偷窺或擷取，本器材使用者應先修改預設密碼，並定期更新密碼。安全諮詢及注意事項 • 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。 • 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。 • 注意防潮，請勿將水或其他液體潑灑到本產品上。 • 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。 • 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。 • 不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。限用物質含有情況標示聲明書設備名稱：AI Home Security Wi-Fi Camera 型號（型式）：Tapo C125 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元多溴二苯醚鉛汞鎘六價鉻...
Page 23 電源供應器 − ○ ○ ○ ○ ○ 其他及其 − ○ ○ ○ ○ ○ 配件備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值 Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the reference percentage value of presence condition.
Page 24 Safety Information • Keep the device away from water, fire, humidity or hot environments. • Do not use damaged charger or USB cable to charge the device. • Do not use any other chargers than those recommended. • Do not use the device where wireless devices are not allowed. •...
Page 25 • When you leave the product unused for a long time unplug the product from the power outlet. • This product may interfere with other electronic products such as TV, radios, personal computers, phones or other wireless devices. • Operating Temperature: 0 °C ~ 40°C (32°F ~ 104°F) •...
Page 26 Explanation of the symbols on the product label Note: The product label is on the bottom of the product and its power supply. Symbols may vary from products. Symbol Explanation Class II equipment Class II equipment with functional earthing Alternating current DC voltage Polarity of output terminals Indoor use only...
Page 27 Symbol Explanation Functional earthing Caution, hot surface Caution Operator’s manual Stand-by “ON”/”OFF” (push-push) Fuse Fuse is used in neutral N RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
Page 28 Symbol Explanation Switch of mini-gap construction Switch of micro-gap construction (for US version) µ Switch of micro-gap / micro-disconnection construction (for other versions except US) ε Switch without contact gap (Semiconductor switching device)
