Sharp Actius PC-UM30W Quick Setup Manual

PC-UM Series Quick Setup Guide
Thank you for purchasing a SHARP PC-UM Series personal computer.
Follow the instructions below to use the computer for the first time.
1.
Be sure to check all the following items are included:
• Notebook Computer
• AC Adapter
• AC Power Cord
• Battery Pack
• External CD-ROM Drive
• Modem Cable
• Core for a LAN cable
• Parallel/VGA Converter Cable
• Memory Upgrade Tool
• Recovery CD-ROMs Pack
• Windows Quick Start Guide
• Operation Manual
2.
Install the battery pack into the
computer.
1. Place the computer upside down.
2. Slide the battery stopper on the battery pack to the
unlocked position( ).
3. Insert the battery pack into the computer by
matching the notched parts of the battery to the
projected parts in the computer and push the
battery pack until you hear the clicking sound.
Projected Part
4. Slide the battery stopper to the locked position( ).
←Memory Upgrade Tool for
installing a memory module
(Refer to Appendixes of the
provided Operation Manual)
Battery Stopper
Notched Part
Carefully inspect each component to make sure nothing is
missing or damaged. If any of these items is missing or
damaged, notify your dealer immediately. Be sure to save the
shipping materials and carton in case you need to ship or store
the computer in the future.
Attach the included core to your LAN cable to insure
compliance with requirements of EMC regulations for
computing equipment.
Some brochures or supplements may be contained other than
the left.
3.
Connect the computer to AC power.
1. Plug the AC adapter cable to the AC adapter jack
on the left side of your computer.
2. Plug the AC power cord into the AC adapter.
3. Plug the AC power cord into a wall outlet.
AC Adapter Jack
AC Adapter
To Wall
AC Power Cord
Outlet
• Always use the AC adapter included with the
computer or the optional one (may not be
available in some countries). Using other AC
adapters may damage the computer.
• Always hold the AC power cord by its plug
when removing it from the wall outlet. Never
pull on the cord.
• When using the computer for the first time,
be sure to connect it to AC power. If using the
battery instead, you may not be able to
complete the Windows setup if the battery
does not have enough power.
Please turn over and go to the
next section
TINSE3389ACZZ
