Step 9
H A R D WA R E
C
Screw Cap Ø10 mm
Screw M 6.3 x 50 mm
G
C O M P O N E N T S
1
Top Shelf
5
Pillar Top Rear
7
Top Support
Step 10
H A R D WA R E
C
Screw Cap Ø10 mm
Screw M 6.3 x 50 mm
G
C O M P O N E N T S
2
Bottom Shelf
6
Pillar Bottom Rear
9
Bottom Middle Support
x1
x1
x1
x1
x1
x2
x2
x1
x1
x1
PAGE 7 OF 11
