Let's Get Started - modway EEI-6346 Assembly Instructions Manual

Let's get started!

Read through all of
the instructions
before starting
Approx. 60 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1 Top Shelf
2 Bottom Shelf
3 Pillar Left
4 Pillar Right
5 Pillar Top Rear
6 Pillar Bottom Rear
7 Top Support
8 Top Middle Support
9 Bottom Middle Support
10 Bottom Front Support
11 Pillar Support
12 Mirror Support
13 Mirror
Provided hardware:
A Cam Lock Ø15 mm
B Cam Bolt Ø7.5 x 32 mm
C Screw Cap Ø10 mm
D Plastic Dowel Ø8 x 32 mm
E Plastic Dowel Ø8 x 40 mm
F Screw M 10 x 33.5 mm
G Screw M 6.3 x 50 mm
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1
x1
x1
x1
x1
x1
x1
x1
x1
x1
x2
x1
x1
x9 H
x7 I
x20 J
x19 K
x2 L
x2 M
N
x20
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
Assemble your item on a fl at, carpeted area, with plenty of space to work.
This will prevent damage and scratches to your fl oors or the item while
you're assembling the product.
Keep all components and packaging out of reach of children or animals
to avoid risk of choking or suff ocation.
Double End Ø7 x 67.5 mm x1
Screw M 6 x 30 mm x1
Screw M 6 x 60 mm x2
Handle x3
Allen Key x1
Screw Cap Ø17 mm x7
Screw Cap Ø15 mm x5
What you need:
Phillips Head Screwdriver
Phillips
You may also need:
+ Power Drill
PAGE 2 OF 11
