- Page 1 INSTRUCTION MANUAL FRIDGE FREEZER C55CW16 C55CS16...
-
Page 3: Table Of Contents
Contents Safety Warnings ............................. 4 Unpacking ..............................6 Installation ..............................7 Location......................................7 Levelling the Unit..................................7 Installing the Spacers .................................. 7 Free Space Requirements ................................7 Reversing the Door Swing ................................. 8 Cleaning Before Use ...................................11 Before Using Your Unit ................................11 Product Overview ............................ -
Page 4: Safety Warnings
Safety Warnings For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. - Page 5 • Do not store bottles or glass containers in the freezer compartment. Contents can expand when frozen (fizzy drinks) which may break the bottle and damage your freezer compartment. (If applicable) WARNING • Keep ventilation openings in the unit enclosure or in the built-in structure clear of obstructions.
-
Page 6: Unpacking
Thank you for purchasing your new Currys Essentials Fridge Freezer. We recommend that you spend some time reading this instruction manual so that you fully understand all the operational features it offers. Read all the safety instructions carefully before use and keep this instruction manual for future reference. -
Page 7: Installation
Installation INSTALLATION Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 16°C and 32°C. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. -
Page 8: Reversing The Door Swing
INSTALLATION Reversing the Door Swing Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner • Ensure the unit is unplugged and empty. • To take the door off it is necessary to tilt the unit backwards. You should rest the unit on something solid, e.g. - Page 9 INSTALLATION 5. Remove the lower screws, hinge bracket and levelling foot from the unit bottom. Keep the matching bracket and foot together. unscrew unscrew 6. Remove the remaining levelling foot from the other side of the unit bottom and transfer it to the corresponding position on the opposite side of the unit bottom.
- Page 10 INSTALLATION 9. Remove and replace the pin on the 180˚ reverse side of the hinge. unscrew screw 10. Carefully set the upper door back into place. Re-attach the re-assembled upper door hinge on the opposite side of the unit. Ensure the fridge door is aligned horizontally and vertically so that the seals are closed on all sides before finally tightening the top hinge.
-
Page 11: Cleaning Before Use
INSTALLATION Cleaning Before Use Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a ‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the shelves and salad bin. Clean the exterior of the unit with a damp cloth. If you require more information refer to the Cleaning section. -
Page 12: Product Overview
Product Overview Internal Light and Thermostat Control Dial Upper Fridge Door Shelf Glass Shelf Salad Bin Cover Salad Bin Lower Fridge Door Shelf Upper Freezer Drawer Bottom Freezer Drawer Levelling Feet Egg Tray Ice Tray... -
Page 13: Operation
Operation Switching On Your Unit 1. Connect the mains cable to the mains socket. The internal temperature of your unit is controlled by a thermostat. There are eight settings, of which position 7 is the coldest and position 0 turns the unit off. -
Page 14: Tips For Keeping Food In The Unit
Tips for Keeping Food in the Unit • Cooked meats/fishes should always be stored on a shelf above raw meats/fishes to avoid bacterial transfer. Keep raw meats/fishes in a container which is large enough to collect juices and cover it properly. Place the container on the lowest shelf. • Leave space around your food, to allow air to circulate inside the compartments. -
Page 15: Defrosting Frozen Food
Defrosting Frozen Food 1. Take the frozen food out from the freezer compartment and uncover the frozen food. Let it defrost at room temperature. Don’t forget that defrosting in a warm area encourages the growth of bacteria and low temperature cooking may not destroy dangerous bacteria. 2. -
Page 16: Cleaning
Cleaning Defrosting Frost might build up in the freezer compartment after it has been used for a period of time. Scrape away the frost using a plastic scraper (not included). Do not use a metal or sharp instrument to scrape away the frost, nor should you use any electrical appliances to aid defrosting. -
Page 17: Maintenance
Maintenance Changing the Internal Light 1. Before carrying out the bulb replacement always adjust the thermostat control dial to Position 0, then disconnect the mains supply. 2. Use a flat bladed screwdriver and gently prise off the light bulb cover. 3. -
Page 18: Specifications
Specifications Model C55CW16 / C55CS16 Appliance Category Category 7 (Refrigerator – Freezer) Overall Dimension (H x W x D) 1510 x 550 x 580 mm Fresh Food Storage Compartment 139L Volume Frozen Food Storage Volume Fridge = Auto Defrosting Type Freezer = Manual Climate Class This appliance is intended to be used at an ambient temperature between 16°C and 32°C. - Page 20 For general information about this appliance and handy hints and tips, please visit www.knowhow.com/knowledgebank or call 0344 5611234. Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories. With over 1 million spares and accessories available we can deliver direct to your door the very next day.
