- Page 1 INSTRUCTION MANUAL UNDERCOUNTER FREEZER CUF48W13...
-
Page 3: Table Of Contents
Contents Safety Warnings ............................. 4 Unpacking ..............................6 Installation ..............................7 Location......................................7 Levelling the Unit..................................7 Installing the Spacers .................................. 7 Free Space Requirements ................................7 Reversing the Door Swing ................................. 8 Cleaning Before Use ...................................11 Before Using Your Unit ................................11 Product Overview ............................ -
Page 4: Safety Warnings
Safety Warnings For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. - Page 5 • Do not store bottles or glass containers in the freezer compartment. Contents can expand when frozen (fizzy drinks) which may break the bottle and damage your freezer compartment. (If applicable) WARNING • Keep ventilation openings in the unit enclosure or in the built-in structure clear of obstructions.
-
Page 6: Unpacking
Thank you for purchasing your new Currys Undercounter Freezer. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. You will also find some hints and tips to help you resolve any issues. -
Page 7: Installation
Installation INSTALLATION Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 16°C and 32°C. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. -
Page 8: Reversing The Door Swing
INSTALLATION If the appliance is placed under a continuous worktop, the appliance lid (if applicable) may be removed and a ventilation grille of at least 200 cm (available from DIY shops or specialist retailers) should be installed to the worktop above the rear of the appliance to increase ventilation. - Page 9 INSTALLATION 2. Undo the screws. Then remove the hinge bracket. unscrew 3. Remove the top left screw cover. 4. Move the core cover from left side to right side. And then lift the door and place it on a padded surface to prevent it from scratching.
- Page 10 INSTALLATION 6. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it. Unscrew Screw 7. Refit the bracket fitting the bottom hinge pin. Replace both adjustable feet. Transfer the door to the proper position. Screw 8. Place the door back on. Ensure the door is aligned horizontally and vertically so that the seals are closed on all sides before finally tightening the top hinge.
-
Page 11: Cleaning Before Use
INSTALLATION 11. Put the hinge cover and the screw cover back. 12. With the door closed, check that the door is aligned horizontally and vertically and that the seal is closed on all sides before finally tightening the bottom hinge. Re-adjust the levelling feet as needed. -
Page 12: Product Overview
Product Overview Thermostat Freezer Drawers Levelling Feet... -
Page 13: Operation
Operation Switching On Your Unit 1. Connect the mains cable to the mains socket. The internal temperature of your unit is controlled by a thermostat. There are 3 settings MIN, NORMAL and MAX. 2. After the unit has been on for 20 minutes adjust the thermostat control dial to NORMAL. -
Page 14: Preparations For Freezing
Preparations for Freezing • Use quality food and handle it as little as possible. Freeze food in small quantities as it freezes faster, takes less time to defrost and enables you to control the quantity you need better. • Leave cooked food to cool completely. Chill food before freezing if possible. • Consider how you will want to cook the food before freezing it. -
Page 15: Cleaning
Cleaning Defrosting Frost might build up in the unit after it has been used for a period of time. Scrape away the frost using a plastic scraper (not included). Do not use a metal or sharp instrument to scrape away the frost, nor should you use any electrical appliances to aid defrosting. -
Page 16: Maintenance
Maintenance Care When Handling / Moving the Unit Hold the unit around its sides or base when moving it. Servicing The unit should be serviced by an authorised engineer and only genuine spare parts should be used. Under no circumstances should you attempt to repair the unit yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunction. -
Page 17: Specifications
Specifications Model CUF48W13 Appliances Category Category 8 (Upright Freezer) Overall Dimension (H x W x D) 840 x 480 x 500 mm Net Frozen Food Storage Volume Defrosting Type Manual Defrost Climate Class This appliance is intended to be used at an ambient temperature between 16°C and 32°C. Storage Temperature ≤... - Page 20 For general information about this appliance and handy hints and tips, please visit www.knowhow.com/knowledgebank or call 0344 5611234. Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories. With over 1 million spares and accessories available we can deliver direct to your door the very next day.
