Traxxas STAMPEDE 4x4 67014-4 Assembly Manual

Hide thumbs Also See for STAMPEDE 4x4 67014-4:

Advertisement

Quick Links

Download this manual
MODEL 67014-4
ASSEMBLY MANUAL

Advertisement

loading

Related Manuals for Traxxas STAMPEDE 4x4 67014-4

Summary of Contents for Traxxas STAMPEDE 4x4 67014-4

  • Page 1 MODEL 67014-4 ASSEMBLY MANUAL...
  • Page 2 • DO NOT let any exposed battery contacts or wires touch each associated with LiPo battery use. Traxxas does not recommend other. This will cause the battery to short circuit and create the risk that anyone under the age of 14 use or handle LiPo battery packs of fire.
  • Page 3 SAFETY PRECAUTIONS All of us at Traxxas want you to safely enjoy your new • No Reverse Voltage: The ESC is not protected against model. Operate your model sensibly and with care, and reverse polarity voltage. it will be exciting, safe, and fun for you and those around •...
  • Page 4 Join thousands of registered members in our online • 4mm / 8mm wrench community at Traxxas.com. Traxxas offers a full-service, on- site repair facility to handle any of your Traxxas service needs. Required but not included: Maintenance and replacement parts may be purchased •...
  • Page 5 INTRODUCTION RADIO SYSTEM INSTRUCTIONS The Traxxas TQ 2.4GHz radio system is provided with your unassembled kit. Complete instructions for operating the radio system are included in the Stampede 4X4 Owner’s Manual. You can download the Owner’s Manual for the Stampede 4X4, as well as the manuals for all Traxxas vehicles, at Traxxas.com.
  • Page 6 A. DIFFERENTIAL ASSEMBLY DIFFERENTIAL BAG A1. Install output and spider gears into differential carrier A2. Add differential fluid Differential Carrier Tip: Lubricate the shaft of the differential output Spider gear assembly gear with a drop of 30K differential oil before 30K Differential Oil installing the X-ring.
  • Page 7 B. SHOCK ASSEMBLY SHOCK BAG B1. Assemble front and rear shocks Shock Assemblies Silicone Shock Oil Slowly move piston Fill with Front Shock Springs to remove excess shock oil air, then let sit a few Rear Shock Springs minutes until all the Unscrew bubbles are out.
  • Page 8 C. FRONT MODULE ASSEMBLY FRONT BULKHEAD BAG C1. Install differential housing onto front bulkhead C2. Install 12T pinion gear into differential housing Front Differential Housing Front Differential Front Bulkhead Housing 4x12mm CCS (2) 12T Pinion Gear 12T Pinion Gear 6x12x4 BB 6x12x4mm BB (2) Front Bulkhead 6x12x4 BB...
  • Page 9 C. FRONT MODULE ASSEMBLY FRONT BULKHEAD BAG C4. Install front suspension arms Front Suspension Arms (L&R) Front Tie Bar Front Suspension Pins (2) Right Front Suspension Front Suspension Pin Front Tie 3x15mm BCS Front Suspension Pin 3x15mm BCS ACCESSORY Left Front Aluminum Accessory Suspension 6823R Red Tie Bar...
  • Page 10 C. FRONT MODULE ASSEMBLY FRONT BULKHEAD BAG C6. Assemble front hubs Steering Blocks (L&R) 5x11x4mm BB 10x15x4mm Caster Blocks (L&R) Left Steering Block 3x12mm CSS (4) Right Steering Block 10x15x4mm 5x11x4mm BB (2) 5x11x4mm BB 3x12mm 3x12mm Right 10x15x4mm BB (2) Left Front Hub Right Front Hub Caster...
  • Page 11 C. FRONT MODULE ASSEMBLY FRONT BULKHEAD BAG C8. Install front driveshaft and hub assemblies 3x11mm Screw Pin (2) Left Front Assembly 3x11mm Screw Pin 3x28mm Hinge Pin (2) 3x11mm Screw Pin 3x28mm Hinge Pin 3x28mm Right Front Assembly Hinge Pin FRONT BULKHEAD BAG C9.
  • Page 12 C. FRONT MODULE ASSEMBLY FRONT BULKHEAD BAG C10. Install front bumper 3x15mm Front Bumper 4x14mm BCS (2) 4x14mm 4x14mm 3x15mm BCS (2) Front Bumper FRONT BULKHEAD BAG C11. Install assembled front shocks Upper shock mounting location Front Shock Guards Lower shock mounting location 3x12mm CSS (2) 3x18mm BCS (4) 3x6x0.5mm MW (2)
  • Page 13 C. FRONT MODULE ASSEMBLY STEERING BAG C12. Assemble bellcrank onto chassis C13. Install steering draglink onto bellcrank Bellcrank Sleeve 3x8mm 3x6x.05mm Bellcrank Arm 3x10mm 3x8mm CS 5x8x2.5mm 3x6x.05mm MW Bellcrank Sleeve 5x8x2.5mm PB (2) Bellcrank 5x8x2.5mm 3x10mm CSS (2) Steering draglink orientation *Note: Do not overtighten STEERING BAG C14.
  • Page 14 D. REAR MODULE ASSEMBLY REAR BULKHEAD BAG D1. Install differential housing onto rear bulkhead D2. Install 12T pinion gear into differential housing Rear Differential Housing Rear Bulkhead 3x10mm CCS (2) Rear Differential Housing 12x18x4mm BB 12T Pinion Gear 12T Pinion Gear 12x18x4mm BB D3.
  • Page 15 D. REAR MODULE ASSEMBLY REAR BULKHEAD BAG D5. Install suspension arms onto rear bulkhead assembly Rear Suspension Arms (L&R) Rear Suspension Pins (2) Left Rear Suspension Arm Rear Suspension Pin Rear Suspension Pin Right Rear Suspension Arm REAR BULKHEAD BAG D6.
  • Page 16 D. REAR MODULE ASSEMBLY REAR BULKHEAD BAG D7. Assemble rear driveshafts and hub assemblies Outer Driveshaft Inner Driveshaft Inner Driveshaft Stub Axle Carrier 5x11x4mm BB (2) Stub Axle Carrier 5x11x4mm 5x8x0.5 PTFE Washer (2) 5x11x4mm Outer Driveshaft 2x9.8mm Pin Wheel Adapter ACCESSORY Aluminum Accessory 5x8x0.5 PTFE...
  • Page 17 D. REAR MODULE ASSEMBLY REAR BULKHEAD BAG D9. Install rear camber links Camber Links (2) 3x12mm CSS (4) 3x6x0.5mm 3x6x0.5mm MW (4) Rear camber link Camber mounting location Link 3x6x0.5mm ACCESSORY 3x12mm Option Part Camber 3644 Turnbuckle Link 3x6x0.5mm 3x12mm Camber Links REAR BULKHEAD BAG D10.
  • Page 18 E. CHASSIS ASSEMBLY CHASSIS BAG E1. Assemble motor mount and install into chassis 3x10mm BCS Motor Mount M3x0.5 Telemetry Magnet Holder Cover 3x10mm BCS 3x6mm CCS Motor Mount M3x0.5 NL 3x6mm 3x6mm FCS 3x6mm Telemetry Magnet FCS* Holder Cover *Note: Do not overtighten 3x10mm BCS (2) 3x8mm BCS installs from...
  • Page 19 E. CHASSIS ASSEMBLY CHASSIS BAG E3. Install battery hold down Use included 3x15mm BCS 3x15mm BCS 4-way wrench 3x15mm CCS for battery post installation 3x15mm CCS Center Driveshaft Cover 3x6mm Battery Hold 3x6mm BCS Down Retainer Battery Post Battery Post Battery Hold Down Center Driveshaft Cover...
  • Page 20 E. CHASSIS ASSEMBLY CHASSIS BAG E5. Install lower receiver box onto chassis E6. Install receiver into lower receiver box Lower Receiver Box Place on smooth surface portion 2.5x8mm CS 2.5x8mm CS (2) 2.5x8mm CS Receiver Foam Tape Receiver Foam Tape ELECTRONICS BAG TQ Receiver TQ Receiver...
  • Page 21 E. CHASSIS ASSEMBLY CHASSIS BAG E8. Slide the antenna wire into E9. Waterproof and seal the receiver box the antenna tube and insert Antenna Tube Upper Receiver tube into chassis Apply small 3x10mm Box Foam bead of grease Antenna Cap 3x10mm 3x4mm GS Antenna Cap...
  • Page 22 F. SUSPENSION & DRIVELINE INSTALLATION CENTER DRIVELINE BAG F1. Build slipper clutch assembly Slipper Clutch Spring Slipper friction material install 54T Spur Gear 2x9.8 Slipper Hub Slipper Input Shaft Slipper Pressure Plate Slipper Input Slipper Steel Disc Shaft Drive Hub Slipper Slipper Friction 2x9.8mm Pin...
  • Page 23 F. SUSPENSION & DRIVELINE INSTALLATION CENTER DRIVELINE BAG F4. Install center driveshaft Center Driveshaft 3x11 Screw Pin 3x11 Screw Pin Center Driveshaft Thread driveshaft into chassis and attach front assembly ACCESSORY Aluminum Accessory 6755 Aluminum Center Driveshaft CHASSIS BAG F5. Secure front assembly to chassis 4x12mm BCS (2) Note orientation 4x12mm BCS...
  • Page 24 F. SUSPENSION & DRIVELINE INSTALLATION CHASSIS BAG F6. Install rear assembly to chassis 4x12mm BCS (4) Install slipper clutch assembly into chassis Note: Slipper clutch drive hub seats into center driveshaft Install rear module onto chassis Tip: Wiggle rear driveshafts until the slipper clutch assembly shaft seats into the rear differential input.
  • Page 25 F. SUSPENSION & DRIVELINE INSTALLATION CHASSIS BAG F7. Install motor plate to motor F9. Install motor into motor chassis 3x8mm CCS (2) 9-Tooth Pinion Gear Motor Plate 3x15mm 3x4 GS Titan 12T Motor 3x15mm CS 3x8mm Motor Plate Wire Hold Down Clip F8.
  • Page 26 WHEELS AND TIRE BAG G2. Glue tires and install on front and rear axles M4x0.7 NL (4) Wheels (4) Tires with Foam Inserts (4) Traxxas Ultra Premium Tire Glue (Part #6468 Sold Separately) M4x0.7 ACCESSORY Glue the tires to the wheels. Use your thumb to push the side of the tire away from the wheel.
  • Page 27 G. FINAL ASSEMBLY Kit assembly complete STAMPEDE 4X4 • 27...
  • Page 28 APPENDIX Painting the Body Note: Please read this entire section and plan your paint job before beginning. Buying Paint Spraying the Body The body supplied with your model is molded from lightweight and Read the directions on your bottle or can of paint and shake, mix, or durable clear polycarbonate.
  • Page 29 LiPo and NiMH batteries. One NiMH or 2s the Electronic Speed Control Adjustments LiPo battery equipped with a Traxxas High-Current Connector is required. section of this guide. Traxxas Power Cell iD batteries are strongly recommended for maximum performance and safer charging.
  • Page 30 “steering” with the trim knob until the vehicle travels in a Running in Wet Conditions straight line with no steering input. Your Traxxas model is designed with water-resistant features to protect the Electronic Speed Control Adjustments electronics in the model (receiver, servos, electronic speed control). Though...
  • Page 31 NOTES STAMPEDE 4X4 • 31...
  • Page 32 ASSEMBLY MANUAL MODEL 67014-4 6250 TRAXXAS WAY, McKINNEY, TEXAS 75070 1-888-TRAXXAS 191029 KC2743-R01...
