Shark V1930 User Manual

Cordless sweeper
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
Cordless Sweeper
Barredora Electrónica
Modelo:
Model/
4.8 Volt DC – 4,8 Voltios CC
To Maximize the life of your NiCd batteries:
1. Charge for a minimum of 20 hours before initial use.
Failure to do so will reduce the product's battery life
significantly.
2. DO NOT store unit with the charging adapter attached
and plugged in.
3. Only recharge when the batteries are fully discharged
(or as close to fully discharged as possible).
4. DO NOT store in areas of high temperature or humidity.
5. After 3 months of non-use, the product should be fully
discharged and then recharged to maximize battery
power.
6. Use only the charger supplied with the product. If other
chargers are used, the batteries can fail causing damage to
the battery, product, or personal property.
NiCd batteries have a long useful life but at some time they
will need to be replaced. To purchase replacement batteries,
visit www.sharkvac.com
Note: 1. The On/Off switch must be in the "Off" position in
order to charge the unit. If the charging indicator
does not light, depress the On/Off switch once.
2. If the product has never been used or has been
stored for an extended period of time without use – it
will take several complete charge and discharge
cycles to realize the full operational time of your
product.
Copyright © EURO-PRO OPERATING LLC 2007
V1930

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V1930 and is the answer not in the manual?

Questions and answers

Related Manuals for Shark V1930

Summary of Contents for Shark V1930

  • Page 1 Cordless Sweeper Barredora Electrónica Modelo: Model/ V1930 4.8 Volt DC – 4,8 Voltios CC To Maximize the life of your NiCd batteries: 1. Charge for a minimum of 20 hours before initial use. Failure to do so will reduce the product’s battery life significantly.

  • Page 3: Important Safeguards

    Modelo V1930 GARANTÍA LIMITADA DE UN (1) AÑO EURO-PRO Operating LLC garantiza este producto contra defectos de materiales y mano de obra por el término de un (1) año a partir de la fecha de compra original, siempre que sea utilizado para uso doméstico normal, sujeto a las siguientes condiciones, exclusiones y excepciones.
  • Page 4 PARTS AND COMPONENTS Handle Release Upper Handle Folding Pivot Lower Handle Extension Tube Lower Handle Charging Light Indicator On/Off Switch Charging Adapter: Only Use KUANTECH KA12D075015023U Dust Cup Container 10. Transparent Brush Cover 11. Rotating Brush 12. Sweeper Power Head 13.
  • Page 5 INSTRUCCIONES DE USO Limpieza del Recipiente de la Tierra Para obtener el mejor rendimiento, limpie el recipiente para la tierra luego de cada uso. 1. Tire del recipiente para la tierra hacia fuera desde el costado. (Fig. 11) Fig. 11 2.
  • Page 6 OPERATING INSTRUCTIONS 3. To fold the handle, press on the handle release button firmly while bending the handle forward. The folding pivot will click into the bent position. (Fig. 3) 4. To straighten the handle, simply lift the upper handle. The folding pivot will click into the straightened position.
  • Page 7 INSTRUCCIONES DE USO 3. Extraiga cuidadosamente la batería y desconecte los terminales separando los conectores de los cables. Quite la batería de la unidad. (Fig. 7) Conecte los terminales de la unidad a los terminales de la nueva batería, y coloque la batería dentro de la unidad.
  • Page 8 OPERATING INSTRUCTIONS Carefully lift out the battery pack and disconnect the wire terminals by pulling apart the wire terminal connectors. Remove the battery pack from the unit. (Fig. 7) Connect the wire terminal connector from the unit to the wire terminal connector of the new battery pack, and replace the battery pack into the unit.
  • Page 9 (Fig. 9) 4. To vacuum under furniture, press the handle release button and apply pressure in order to bend the sweeper’s handle forward. The top folding pivot will release from the locked position for increased range of motion, allowing you to easily reach under sofas, beds, and chairs.
  • Page 10 OPERATING INSTRUCTIONS Cleaning The Dust Container To achieve the best performance, empty the dust container after each use. 1. Pull the dust container straight out from the side. (Fig. 11) Fig. 11 2. Empty dust container contents. (Fig. 12) If desired- you may rinse with water to clean the dust container - but dry thoroughly before replacing on the sweeper.

  • Page 11: Troubleshooting Guide

    PARTES Y COMPONENTES Botón de Liberación del Mango Mango Superior Pivote Tubo de Extensión del Mango Inferior Mango Inferior Luz Indicadora de Carga Llave de Encendido Cargador: Use Unicamente KUANTECH KA12D075015023U Recipiente Para Tierra Cubierta Transparente del Cepillo Cepillo Giratorio Cabezal Eléctrico de la Barredora Perno y Tuerca de Fijación * El dibujo puede no ser igual al producto real.

  • Page 12: One (1) Year Limited Warranty

    Model V1930 ONE (1) YEAR LIMITED WARRANTY EURO-PRO Operating LLC warrants this product to be free from defects in material and workmanship for a period of one (1) year from the date of the original purchase, when utilized for normal household use, subject to the following conditions, exclusions and exceptions.
