- Page 1 CAM-CIC-3100-3-G-1/GC1; GigE Large Area Scan Industrial Camera User Manual 2023 August 18 V1.1.0...
-
Page 2: Foreword
Foreword Abstract The document briefly describes GigE Large Area Scan Industrial Camera, including product introduction, networking, basic parameters and applications for quick operation. Symbol Convention The following symbols may appear in this document, and their meanings are as follows： Symbol Description Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. -
Page 3: Important Safety Instructions
Important Safety Instructions Here is the proper use of the product and prevention of dangers as well as loss of property, etc. Be sure to follow the instructions when using. Please do not place or install the device in the location with strong sunlight or near ⚫... -
Page 4: Table Of Contents
Directory Contents Contents Foreword ..........................II Important Safety Instructions ....................III Directory ..........................4 1 Product Overview ....................... 5 1.1 Product Introduction ......................5 1.2 Product Features ......................... 5 1.3 Typical Networking ......................6 1.4 Main Technical Parameters ....................6 1.5 Spectral Curve ........................ -
Page 5: Product Overview
Product Overview Product Introduction GigE Large area scan camera adopts high-performance sensor chip and realizes real-time non-compressed image data transmission via GigE, which is compatible with any application development tool which meets GigE Vision and GenICam standard. Max transmission rate 1Gb/s can satisfy the requirements of transmission rate in most industrial applications. -
Page 6: Typical Networking
Typical Networking The most typical networking mode of a large area scan camera is point-to-point connection, which needs no other network medium between the host computer and industrial camera. It can be connected through cable, please refer to Figure 1-1. A host computer can also connect multiple industrial cameras through multiple network ports or switches. - Page 7 Weight 487 g Certification Conforms to CE, FCC, RoHS, GigE Vision V2.0 and GenICam Software GenICam and GigE Vision supported devices Sheet 1-2 CAM-CIC-3100-3-GC1 Technical Parameters 31MP GigE Color Large Area Scan Industrial Camera Sensor Model IMX342 Sensor Type CMOS...
-
Page 8: Spectral Curve
31MP GigE Color Large Area Scan Industrial Camera Storage Temperature: -30 ℃ ～ +80 ℃ ; Operating Temperature Temperature: -30℃ ～ +50℃ 72mm×72mm×64mm (Not including the lens mount Dimension and the rear case connectors) Weight 487 g Certification Conforms to CE, FCC, RoHS, GigE Vision V2.0 and GenICam Software GenICam and GigE Vision supported devices Spectral Curve... -
Page 9: Environmental Requirements
Environmental Requirements The following are the environmental requirements for GigE large area scan industrial camera： Temperature and humidity ⚫ Ambient temperature should not exceed 50 ℃ , it is best to work in an air-conditioned environment. Operating cover temperature：0℃～50℃. Operating ambient humidity：20%～80% no condensation. -
Page 10: Interface Description
The product dimensions are as follows： Figure 2-1 CAM-CIC-3100-3-GC1/ CAM-CIC-3100-3-G-1（Unit：mm） Interface Description The back of the device has two interfaces, the network interface and 12pin power as well as I/O interface, as shown below: Figure 2-2 CAM-CIC-3100-3-GC1/ CAM-CIC-3100-3-G-1 Interface Description... -
Page 11: Network Interface
2.2.1 Network Interface Network interface, RJ45 Ethernet port, three-speed Ethernet 10M / 100M / 1000Mbps transmission interface for camera control, data transmission. It is best to use shielded twisted-pair Category 6 cable in order to ensure the transmission quality, as well as to prevent too much data retransmission and packet loss phenomenon. -
Page 12: Io Port Electrical Specification
Surge (IEC61000-4-5): Ethernet port: 2 kV common mode, 1 kV differential mode (100/700 μs) Power port: 2 kV common mode (1.2/50 μs) EMC Standard Class B *: The power supply should meet SELV and LPS specifications. 2.3.2 IO Port Electrical Specification 2.3.2.1 Opto-isolated Input Sheet 2-3 Opto-isolated input Input Voltage... -
Page 13: Indicator Light Description
Figure 2-4 Opto-isolated Output Circuit Indicator Light Description The indicator light description of the device is shown in Sheet 2-. Sheet 2-5 Indicator Light Description Status Indicator light status Note Red light quick flashing Device booting. IP is assigned, and the application Blue light slight brightness software API is not connected to the device. -
Page 14: Faq
You can solve problems that you may encounter with following instructions: Application fails to discover the device. Reason analysis： ➢ The camera fails to boot up normally. ➢ Connection of network cable is abnormal. ➢ The camera and the Host PC running the client are not in the same LAN. Solutions：... - Page 15 Reason analysis： ➢ External trigger connection is wrong. ➢ It fails to select external trigger in trigger mode. Solutions： Select correct trigger mode and make sure external connection is correct.
-
Page 16: Cleaning And Maintenance
Cleaning and Maintenance This chapter mainly introduces cleaning and replacement of color filter. We have installed a fully transparent protective glass for the mono camera with the main purpose of preventing dust from falling on the surface of the image sensor. The color camera is equipped with a low-pass filter that cuts off to the near-infrared band.
