INSTALLATION & MAINTENANCE
FOR SMART ION CHARGE ELECTRIC VEHICLE CHARGER
MODELS NUMBERS - EV03221000 & EV03221010
PLEASE READ IN FULL BEFORE INSTALLING ANY PRODUCTS
Contact Us
Craig & Derricot Ltd | 46 Hall Lane I Walsall Wood I Walsall I West Midlands I WS9 9DP I United Kingdom
+44(0) 1543 375 541 | sales@craigandderricot.com | www.craigandderricot.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the smart ION CHARGE EV03221000 and is the answer not in the manual?

Questions and answers

Related Manuals for CRAIG & DERRICOTT smart ION CHARGE EV03221000

Summary of Contents for CRAIG & DERRICOTT smart ION CHARGE EV03221000

  • Page 1 INSTALLATION & MAINTENANCE FOR SMART ION CHARGE ELECTRIC VEHICLE CHARGER MODELS NUMBERS - EV03221000 & EV03221010 PLEASE READ IN FULL BEFORE INSTALLING ANY PRODUCTS Contact Us Craig & Derricot Ltd | 46 Hall Lane I Walsall Wood I Walsall I West Midlands I WS9 9DP I United Kingdom +44(0) 1543 375 541 | sales@craigandderricot.com | www.craigandderricot.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION NOTES ..................................4 WARNINGS ................................4 CAUTIONS ................................. 4 PRODUCT OVERVIEW PRODUCT SPECIFICATION – ION EV CHARGER ......................5 PRODUCT SPECIFICATION – IONSENS ........................5 ABOUT SMART ION SUMMARY ................................. 6 ION EV CHARGER COMPONENTS – SOCKETED VERSION................... 8 ION EV CHARGER COMPONENTS –...
  • Page 3 MAINTENANCE GENERAL MAINTENANCE ............................24 CLEANING ................................24 TROUBLESHOOTING ..............................24 WARRANTY ................................24 DISPOSAL ................................. 24 ACCESSORIES ................................24 EVC0047 – Issue 2 3 | Page...

  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION NOTES Please read all instruc�ons before installing and using this product. Store in a safe place for reference. The EV charger should be installed, commissioned, and maintained by or under the supervision of a competent electrician in accordance with current electrical engineering codes of prac�ce, requirements for electrical installa�ons (BS7671), statutory requirements and any specific instruc�on issued by the company.

  • Page 5: Product Overview

    PRODUCT OVERVIEW This OCCP compliant EV charger is an easy to install unit for residen�al loca�ons. It offers 7.4kW single phase fast charging: plug and charge via the ION charge App, or RFID opera�on. This EV charger is equipped with PME fault detec�on with no requirement for an earth rod. The unit also supports dynamic load balancing / management and solar charging via the IONsens device, that is included with your EV charger.

  • Page 6: About Smart Ion

    ABOUT SMART ION SUMMARY The United Kingdom introduced regula�ons that applies to domes�c and private EV charge points. The regula�ons are designed to balance demands for power and to deliver an efficient use of power across the country whilst maintaining a consistent and secure service to EV drivers. Summary of smart capabili�es (correct at �me of print).
  • Page 7 ABOUT SMART ION If an electric vehicle is now put on charge and drawing 16A, the limit would be exceeded, and the property’s fuse would operate to cut all electrical power to the property. With load balancing enabled, the amount of power made available for charging will be automa�cally adjusted to a level that does not exceed the maximum for the property.
  • Page 8 ABOUT SMART ION • Charge points must incorporate a boundary to guard the electrical components from tampering whilst also providing safety to electrical engineers. A tamper proof screw is fited to prevent inadvertent removal of the front cover. See Fig1 & 3, Item C •...
  • Page 9 ABOUTSMART ION ION EV CHARGER EXTERNAL COMPONENTS – TETHERED VERSION Fig. 3 ION EV CHARGER INTERNAL COMPONENTS – TETHERED VERSION Fig. 4 Supplied with: • IONsens including CT • 2 x User Key Fob (Pre-paired) • 1 x 5m Type 2 EV Cable & Plug EVC0047 –...

  • Page 10: Ev Charger Kits

    ABOUT SMART ION EV CHARGER KITS Fig. 5 EVC0047 – Issue 2 10 | Page...

  • Page 11: Ev Charger Installation

    EV CHARGER INSTALLATION CHOOSING A LOCATION Install the EV charger in a loca�on that allows the charging cable to reach the vehicle charge port without pu�ng strain on the cable. The tethered cable length is 5m, therefore, a recommended distance would be no greater than 3m from the car charging point.

  • Page 12: Install Ionsens

    EV CHARGER INSTALLATION INSTALL IONSENS for LOAD BALANCING / MANAGEMENT (supplied with Charger) The EV charger is supplied with a load sensing device with one CT clamp. This must be fited near to your house incoming supply where the house protec�ve fuse and meter is located. See Fig 7, item 1. The CT Clamp is to be fited to the incoming cable (see Fig 8 item 2) and the black and white cable must be fited to the terminals CT1.1 and CT1.2 inside the IONsens enclosure.
  • Page 13 EV CHARGER INSTALLATION Fig. 8 Fig. 9 EVC0047 – Issue 2 13 | Page...

  • Page 14: Mains Cable Connection

    EV CHARGER INSTALLATION MAINS CABLE CONNECTION The EV charger is supplied with a Mains M25 Nylon cable gland. Note: For Steel wire armoured cable, a suitable gland will need to be used (not supplied). Insert the cable through the LH entry cable gland and �ghten the glanding nut. Strip back the cable and terminate the cables into the LH terminal blocks.

  • Page 15: Cable Connection To Ev Charger

    EV CHARGER INSTALLATION CABLE CONNECTION TO EV CHARGER FOR BOTH ETHERNET & IONSENS Use the push-in cable gland to allow the fi�ng of the IONsens and op�onal ethernet cables. The push-in cable gland is only required if the installa�on power cable has no integrated data cable included.

  • Page 16: Ev App Installation

    EV APP INSTALLATION Your charger will require a connec�on to the Internet. This can be done by either Ethernet or Wi-Fi. ACCOUNT SETUP Step 1 Step 2 Step 3 Download the free smart ION Enter a Valid email address Enter Verification PIN sent to charge app by scanning the QR Read the Privacy Policy &...

  • Page 17: Adding A Charge Point

    EV APP INSTALLATION ADDING A CHARGE POINT Step 6 Step 7 Step 4 Step 5 To add a new Charge Enter UUID Enter BLE number Connection via Wi-Fi Point From the Quick Start From the Quick Start Select setup Wi-Fi then Click Add Charger.

  • Page 18: Configuration Settings

    EV APP INSTALLATION CONFIGURATION SETTINGS Naming your Charge Point Charging Costs Select Rename charger. Enter a Select Price se�ngs to enter your name of your choice to help iden�fy average Electricity usage costs, this charge point. i.e Home details maybe found on your electricity bill.

  • Page 19: Operational Settings

    EV APP INSTALLATION OPERATIONAL SETTINGS Alerts During a Charge Naming your Charge Starting a Charge Session Stop a Charge Session Session Point Press and hold the Ready Press and hold the Should an issue occur during Enter a name to help button to start a Charge Charging button to stop a charge session.
  • Page 20 EV APP INSTALLATION OPERATIONAL SETTINGS RFID Management Charging Costs Scheduling Controller Settings Enter your electricity Default Schedules are From this menu the RFID tags can be added and energy cost per KWh. required as part of UK following can accessed. removed.
  • Page 21 EV APP INSTALLATION OPERATIONAL SETTINGS Power Settings Power Management Energy Monitoring Reports Power Management and Solar panel and battery This shows a visual Reports show energy power limits can be set bank monitoring can be representation of usage and costs over a from this menu.

  • Page 22: Ev App & Charger Settings

    EV APP & CHARGER SETTINGS CHARGER LED STATUS INDICATION LED Colour Indication Green Charger is online (Ready) Blue Charger is online (Charging) Yellow Charger is offline (Ready) Violet Charger is offline (Charging) Cover removed or charger malfunction / Charger rebooted White (Blink) / White (Blinking) RFID charger fob is authorised / New firmware stabilising Red (Blink)
  • Page 23 MAINTENANCE GENERAL MAINTENANCE Should the product be installed in a space that is accessible to the public, observe local and na�onal requirements (e.g., BS 7671) in addi�on to all other safety informa�on contained within this manual. CLEANING Should the product require cleaning for cosme�c purposes, use a damp cloth with an all-purpose household cleaner. Avoid the use of strong chemical cleaners and cleaners that contain oil or alcohol, as this will tarnish the plas�c.
