INSTALLATION & MAINTENANCE
FOR SMART ION CHARGE ELECTRIC VEHICLE CHARGER
MODELS NUMBERS - EV03221000 & EV03221010
PLEASE READ IN FULL BEFORE INSTALLING ANY PRODUCTS
Contact Us
Craig & Derricott Ltd | 46 Hall Lane I Walsall Wood I Walsall I West Midlands I WS9 9DP I United Kingdom
+44(0) 1543 375 541 | sales@craigandderricott.com | www.craigandderricott.com
Advertisement
Table of Contents
Related Manuals for CRAIG & DERRICOTT EV03221000
Summary of Contents for CRAIG & DERRICOTT EV03221000
- Page 1 INSTALLATION & MAINTENANCE FOR SMART ION CHARGE ELECTRIC VEHICLE CHARGER MODELS NUMBERS - EV03221000 & EV03221010 PLEASE READ IN FULL BEFORE INSTALLING ANY PRODUCTS Contact Us Craig & Derricott Ltd | 46 Hall Lane I Walsall Wood I Walsall I West Midlands I WS9 9DP I United Kingdom...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION NOTES ..................................3 WARNINGS ................................3 CAUTIONS ................................. 3 PRODUCT OVERVIEW PRODUCT SPECIFICATION – ION EV CHARGER ......................4 PRODUCT SPECIFICATION – IONSENS ........................4 ABOUT SMART ION SUMMARY ................................. 5 ION EV CHARGER COMPONENTS – SOCKETED VERSION................... 7 ION EV CHARGER COMPONENTS –... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION NOTES Please read all instructions before Installing and using this product. Store in a safe place for reference. The EV charger should be installed, commissioned, and maintained by or under the supervision of a competent electrician in accordance with current electrical engineering codes of practice, requirements for electrical installations (BS7671), statutory requirements and any specific instruction issued by the company. -
Page 4: Product Overview
PRODUCT OVERVIEW This OCCP compliant EV charger is an easy to install unit for residential locations. It offers 7.4kW single phase fast charging. Plug and charge via the ION charge App or RFID operation. This EV charger is equipped with PME fault detection with no requirement for an earth rod. The unit also supports dynamic load balancing / management and solar charging via the IONsens device, that is included with your EV charger. -
Page 5: About Smart Ion
ABOUT SMART ION SUMMARY The United Kingdom introduced regulations that applies to domestic and private EV charge points. The regulations are designed to balance demands for power and to deliver an efficient use of power across the country whilst maintaining a consistent and secure service to EV drivers. Summary of smart capabilities (correct at time of print). - Page 6 ABOUT SMART ION If an electric vehicle is now put on charge and drawing 16A, the limit would be exceeded, and the property’s fuse would operate to cut all electrical power to the property. With load balancing enabled, the amount of power made available for charging will be automatically adjusted to a level that does not exceed the maximum for the property.
-
Page 7: Ion Ev Charger Components - Socketed Version
ABOUT SMART ION • Charge points must log and issue an alert to the customer / user if there is a breach of the boundary. The purpose of this device is to protect people from harm, protect the charge point, the charging network, and the electricity network from malicious or accidental damage or abuse and protect the data held on the charge point. -
Page 8: Ion Ev Charger Components - Tethered Version
ABOUT SMART ION ION EV CHARGER EXTERNAL COMPONENTS – TETHERED VERSION Fig. 3 ION EV CHARGER INTERNAL COMPONENTS – TETHERED VERSION Fig. 4 Supplied with: • IONsens including CT • 2 x User Key Fob (Pre-paired) • 1 x 5m Type 2 EV Cable & Plug EVC0047 –... -
Page 9: Ev Charger Kits
ABOUT SMART ION EV CHARGER KITS Fig. 5 EVC0047 – Issue 1 9 | Page... -
Page 10: Ev Charger Installation
EV CHARGER INSTALLATION CHOOSING A LOCATION Install the EV Charger in a location that allows the charging cable to reach the vehicle charge port without putting strain on the cable. Tethered cable length is 5m, therefore, a recommended distance would be no greater than 3m from the car charging point. -
Page 11: Install Ionsens
EV CHARGER INSTALLATION INSTALL IONSENS The EV charger is supplied with a Load sensing device with one CT clamp, this must be fitted near to your house incoming supply where the house protective fuse and meter is located. See Fig 7, Item 1. The CT Clamp is to be fitted to the incoming cable (see Fig 7 item 2) and the Black and white cable must be fitted to the terminals CT1.1 and CT1.2 inside the IONsens enclosure. -
Page 12: Mains Cable Connection
EV CHARGER INSTALLATION MAINS CABLE CONNECTION The EV charger is supplied with a Mains M25 Nylon cable gland. Note: For Steel wire armoured cable, a suitable gland will need to be used (not supplied). Insert cable through LH entry cable gland and tighten glanding nut. Strip back cable and terminate cables into LH terminal blocks. -
Page 13: Cable Connection To Ev Charger
EV CHARGER INSTALLATION CABLE CONNECTION TO EV CHARGER FOR BOTH ETHERNET & IONSENS Use push-in cable gland to allow fitting of the IONsens and optional ethernet cables. The push-in cable gland is only required if the installation power cable has no integrated data cable included. -
Page 14: Ev App Installation
EV APP INSTALLATION Your charger will require a connection to the Internet. This can be done by either Ethernet or Wi-Fi. ETHERNET SETUP Step 4 Step 1 Step 2 Step 3 Download the free Smart Ensure your Bluetooth Enter a valid email address Step 1 Once logged in, Charge settings are switched ON... - Page 15 EV APP INSTALLATION Step 7 Step 8 Step 5 Step 6 Name your charger and The App will now take you Select “Settings” menu. Then select “Controller locate the charger ID. to the Charger home Settings”. Scan the Charger ID QR screen and will display Code or enter the number “READY”.
-
Page 16: Wi-Fi Setup
EV APP INSTALLATION Step 12 Step 9 Step 10 Step 11 The App will then prompt The App will now take you If the front cover has not Your setup for Bluetooth Permission. to back to the Charger been fitted the App will complete, and the charger Enter the 6-digit BLE code home screen and will... -
Page 17: Charger Setup
EV APP INSTALLATION CHARGER SETUP GUIDE Step 4 Step 1 Step 2 Step 3 Click on the setting tab Click on Price settings and Charging schedule default The Power Management enter your Energy cost per charging time have been button will be ON when kWh. -
Page 18: Ev App & Charger Settings
EV APP & CHARGER SETTINGS CHARGER LED STATUS INDICATION LED Colour Indication Green Charger is online Charger is offline and an error has occurred Blue Car is charging Violet Car is charging in offline mode Yellow Offline, ready to charge (plug-in & charge) Blinking Blue RFID read / acknowledged HOW TO USE THE KEY FOB WITH THE RFID... -
Page 19: Maintenance
MAINTENANCE GENERAL MAINTENANCE Should the product be installed in a space that is accessible to the public, observe local and national requirements (e.g., BS 7671) in addition to all other safety information contained within this manual. CLEANING Should the product require cleaning for cosmetic purposes, use a damp cloth with an all-purpose household cleaner. Avoid the use of strong chemical cleaners and cleaners that contain oil or alcohol, as this will tarnish the plastic.
