INTRODUCTION
This service manual is intended as a reference for
the installer, user, and service agent of this
Scotsman Ice Station. It includes the necessary
information to install, start up, operate, clean and
maintain this unit.
For the Installer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4
For the Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5
Service Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9
Electrical Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9
Parts lists and wiring diagrams are located in the center of this manual, printed on yellow
paper.
This manual contains important information, read it before beginning installation or operation.
Keep it for future reference.
Safety Symbol:
Important safety information on a
hazard that might cause serious
injury.
TABLE OF CONTENTS
IS100 and IS150
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Scotsman IS100
Summary of Contents for Scotsman IS100
-
Page 1: Table Of Contents
INTRODUCTION This service manual is intended as a reference for the installer, user, and service agent of this Scotsman Ice Station. It includes the necessary information to install, start up, operate, clean and maintain this unit. Specifications ......... . . Page 2 Model Identifications . -
Page 2: Specifications
Rotor motor is 1/10 H.P. Options: Lighted upper front panel. 4" leg kit. Push button actuation (factory installed). Scotsman Ice Systems are designed and manufactured with the highest regard for safety and performance. They meet or exceed the standards of U.L., N.S.F., and C.S.A. -
Page 3: Model Identifications
PANEL upper front cover by pushing the strikes on the cover into the catches on the unit. * Optional depending upon unit configuration. October 1993 Page 3 IS100 and IS150 Voltage Series LEVER SLOT ICE CHUTE MOUNTING PANEL ICE CHUTE... -
Page 4: For The Installer
Sealing may be accomplished by the use of room temperature vulcanizing (RTV) rubber sealant such as General Electric IS 808 Industrial Sealant, Dow Corning 731 (Scotsman part number 19-0529-01) or the equivalent. With the unit located on the counter as desired: A. -
Page 5: Initial Start Up
Remove the grill from the sink, clean the sink, grill and splash panel, make sure the sink drain is open by pouring hot water into the sink. Return the grill to the sink. October 1993 Page 5 IS100 and IS150 WATER... -
Page 6: How It Works
IS100 and IS150 HOW IT WORKS The ice is stored in a hopper, and the hopper is sloped towards the front. At the front there is an angled rotor: when that rotor turns, it scoops the ice, lifts it to the top of the ice chute and drops it through that chute into the user’s container. -
Page 7: Cleaning & Sanitizing
IS100 and IS150 CLEANING AND SANITIZING The sink, grill and splash panel area should be cleaned daily. The ice storage system should be sanitized monthly. Daily: 1. Lift up and remove grill from sink. 2. Use soap, hot water, and a clean cloth to wash sink and splash panel;... -
Page 8: Cleaning And Sanitizing
IS100 and IS150 CLEANING AND SANITIZING MONTHLY & INITIAL START UP: Sanitize the Ice Storage System. Note: this should only be done by qualified personnel. 1. Unplug the Ice Stand’s electrical cord from the electrical power. Ice hopper contains parts... -
Page 9: Service Diagnosis
5. Rotor will not turn 6. Relay for vend switch does not close during operation. October 1993 Page 9 IS100 and IS150 CORRECTION 1. Fill hopper with ice 2. Check vend switch, replace if open 3. Check drive motor, replace if not working 4. -
Page 10: Removal And Replacement
IS100 and IS150 REMOVAL & REPLACEMENT To Replace Vend Switch: 1. Disconnect Electrical Power. Electrical Hazard. Unplug unit before servicing. 2. Pull out and remove upper front panel. Lever Type A. Twist ice chute 1/3 turn and pull down to remove.
