USB SmartMedia Card Reader
4. Verify that your product matches the one pictured on the screen.
5. Click the button labeled Click Here to Begin Installation and follow the on-screen
instructions. For best results, allow the drivers to be installed into the default
locations.
6.
When the Setup Complete screen appears, click the Finish button.
7. Connect the Reader-14 to the USB port or hub.
8. You may now insert a SmartMedia Card and access it like other drives by clicking
the Removable Disk drive icon in My Computer or Explorer.
Driver Software Installation Procedure for Apple Macintosh
Before connecting the eFilm Reader-14, you must install the device drivers located on
the accompanying CD-ROM. To avoid compatibility issues, install only the Reader-14
driver. Slot or front loading CD-ROMs may not function correctly with a 3" CD disk. For
these systems it is recommended that you download the driver from www.delkin.com
Prior to any software installation always
ensure you have backed up your hard drive
and prepared a recovery disk.
1. Insert the Driver CD-ROM, then double-
click on the CD icon when it appears.
2. Select Reader-14 from the product list.
(See Figure 2)
3. Click the button labeled Install and
follow the on screen instruction. Select
Restart Computer after installation is
complete.

Hardware Installation

After you have installed the drivers, insert the USB plug of the Reader-14 into the USB
port of your computer or hub. See inside front cover for illustration.
When using a hub, an external power source may be required when connecting multiple
devices, such as printers, scanners, and CD writers.

Inserting a SmartMediaCard

Position the card with the arrow-side up
and toward the reader and the gold contact
side down. Insert it gently but firmly into
the slot. Be careful to insert the card in
the proper direction. Inserting a card up-
side down or forcing it may result in
damage to the card and/or reader.
(See Figure 3)
Page 2
DDREADER-14
Delkin Devices User's Manual
