- Page 1 TL-MC85 Quick Start Guide MoCA® 2.5 Network Adapter Package Contents (2) MoCA®2.5 Network Adapter (2) Power Adapter (2) Coaxial Cable (2) Ethernet Cable (1) Quick Start Guide...
- Page 2 HASSLE-FREE INSTALLATION WITH YOUR NEW VIRTUAL PRODUCT ASSISTANT SCAN THE QR CODE NOW TO DOWNLOAD Post a review and get a discount Get 5% off on for your next purchase on your next mocaadapters.com order 2. Leave us an 1. Your opinion is important to us e-commerce review 4.
- Page 3 Table Of Contents Testing Your MoCA Network Adapters........Page 04 MoCA Adapter Connection Setup - Router......Page 06 MoCA Adapter Connection Setup - Cable Modem...Page 10 (Internet + TV Connection) MoCA Adapter Connection Setup - Cable Modem...Page 14 (Internet only) DOCSIS 3.1 Cable Modem Settings.........Page 16 MoCA Device Login Procedure..........Page 18...
- Page 4 Testing Your MoCA Network Adapters...
- Page 5 MoCA Adapters Basic Testing A quick validation on your network speed & device functioning Unbox your MoCA 2.5 Network Adapters and connect the respective power adapters to the power outlet Connect your modem/router to one of the LAN ports of your rst MoCA adapter using a LAN cable Connect the MoCA port of the rst MoCA device to the MoCA port of second MoCA device using a coax cable...
- Page 6 MoCA Adapter Connection Setup To A Router...
- Page 7 Setup Instructions: (MoCA Adapter Connection to a Router Setup) ROOM 1 TL-MC85 ON/OFF IN-OUT MOCA 2.5GE DC 5V Power outlet Coax ON/OFF POWER RESET Router ETHERNET Signal Feed from operator Coax Wall Plate Coax Coax wiring behind wall ROOM 2 TL-MC85 ON/OFF IN-OUT...
- Page 8 Setup Instructions: Router ROOM 1 Unbox your MoCA 2.5 Network Adapter Connect your Adapter to a power outlet Connect one ethernet cable from the router to the TL-MC84 Network Adapter Connect a coax cable from the MoCA port on the Network Adapter to the coax wall outlet Note: If you have a splitter, make sure the splitter is a MoCA splitter that...
- Page 9 Setup Instructions: Router ROOM 2 Unbox your second MoCA 2.5 Network Adapter Connect your Adapter to a power outlet Locate the coax wall outlet and connect a coax cable from the wall outlet to the MoCA port of the Network Adapter. *IMPORTANT* : When the MoCA LED is GREEN on both adapters, your adapters have established a connection Connect a networking device using a LAN cable to...
- Page 10 MoCA Adapter Connection Setup To A Cable Modem (Internet + TV)
- Page 11 Setup Instructions: (MoCA Adapter Connection to a Cable Modem) (Internet + Tv) ROOM 1 TL-MC85 ON/OFF IN-OUT MOCA 2.5GE DC 5V Power outlet Coax Coax wiring behind wall or to coax wall plate ON/OFF Cable Modem Coax POWER RESET Coax signal feed ETHERNET from operator CABLE...
- Page 12 Setup Instructions: Cable Modem - ROOM 1 Unbox your MoCA 2.5 Network Adapter Connect your Adapter to a power outlet Connect one ethernet cable from the Cable Modem to the TL-MC84 Network Adapter Connect a MoCA splitter to the coax cable coming from the coax outlet on the wall.
- Page 13 Setup Instructions: Cable Modem - ROOM 2 Unbox your second MoCA 2.5 Network Adapter Connect your adapter to a power outlet Locate the coax wall outlet and connect a coax cable from the wall outlet to a MoCA splitter Connect a coax cable from the splitter to the MoCA port of the Network Adapter.
- Page 14 MoCA Adapter Connection Setup To A Cable Modem (Internet only)
- Page 15 Setup Instructions: (MoCA Adapter Connection to a Cable Modem) (Internet Only) ROOM 1 TL-MC85 ON/OFF IN-OUT MOCA 2.5GE DC 5V Power outlet Coax signal feed from operator Coax ON/OFF POWER RESET Cable Modem ETHERNET Coax CABLE Coax Wall Plate Coax wiring behind wall ROOM 2 TL-MC85 ON/OFF...
- Page 16 DOCSIS 3.1 Cable Modem Settings...
- Page 17 DOCSIS 3.1 Cable Modem If you are using a DOCSIS 3.1 Cable Modem, changes on the network adapters will have to be made. You may follow the steps below Log in to the network adapter using the default IP address 192.168.144.200. For login procedure refer pg. 18 Click on TL-MC84 Settings and make sure D-Ext and D-Low are unchecked The LOF has to be changed to 1400 as well...
- Page 18 MoCA Device Login MoCA Procedure Device Login...
- Page 19 MoCA Device Login Step-by-step procedure Connect your computer/laptop directly to the MoCA adapter Make sure all the coax connnections should be removed from the MoCA adapter The only connection should be the ethernet cable from the laptop/computer to the MoCA adapter On your computer, click on ‘Search’...
- Page 20 MoCA Device Login Step-by-step procedure Click on ‘Edit’ button next to ‘IP Assignment’ (Fig.4) In the dialog box that pops up, select ‘Manual’ from the drop-down option (Fig.5) Enable the IPv4 button (Fig.6) Fig.4 Fig.5 Fig.6 page...
- Page 21 MoCA Device Login Step-by-step procedure Set the IP address as indicated below Fig.7 For Windows 11 Fig.8 For Windows 10 Fig.10 Subnet prefix length Fig.9 For MAC Note: In case ‘Subnet pre x length’ is required instead of ‘Subnet mask’ , specify the value as ‘24’...
- Page 22 MoCA Protected MoCA Setup (MPS) Device Login...
- Page 23 MoCA Protected Setup (MPS) Click on ‘TL-MC85 settings’ to check which Band is ‘checked’ Note: For DOCSIS 3.1 setup, please refer page 16 Fig.1 Click on ‘Security settings’ and for the selected bands (as in Fig.1), select the ‘Security Enabled’ check box and provide the password (Fig.2 - a).
- Page 24 MoCA Protected Setup (MPS) Click on ‘Save’ (Fig.2 - b) Disable the ‘Enhanced Privacy Enabled’ option (Fig.2 - c) Click on Save (Fig.2 - d) Reboot the device after the above changes have been made (Fig.2 - e) Within a span of 2 minutes, press the MPS button on the rst adapter followed by the MPS button on the second adapter to establish the MPS connection (Fig.3) For all additional adapters, repeat step 7 by pressing the MPS...
- Page 25 Firmware Upgrade MoCA & Device Support Login...
- Page 26 For rmware upgrades, you may visit our website www.transliteglobal.com or send an email to support@transliteglobal.com Support Sales North America: North America: support@transliteglobal.com sales@transliteglobal.com Asia: Asia: support@translite.co.in sales@translite.co.in Rest of the World: Rest of the World: support@transliteglobal.com sales@transliteglobal.com Available at these retailers: mocaadapters.com page...
