- Page 1 TL-MC85 Quick Start Guide MoCA® 2.5 Network Adapter Package Contents (1) MoCA® Network Adapter (1) Power Adapter (1) Coaxial Cable (1) Ethernet Cable (1) Quick Start Guide...
-
Page 2: Table Of Contents
Table Of Contents Setup Instructions:.................Page 03 (MoCA Adapter Connection to a Router Setup) Setup Instructions:................Page 06 (MoCA Adapter Connection to a Cable Modem - Internet + Tv) Setup Instructions:.................Page 09 (MoCA Adapter Connection to a Cable Modem - Internet only) DOCSIS 3.1 Cable Modem............Page 10 Firmware Upgrades..............Page 11 Contact Support................Page 11... -
Page 3: Setup Instructions
Setup Instructions: (MoCA Adapter Connection to a Router Setup) ROOM 1 TL-MC85 ON/OFF IN-OUT MOCA 2.5GE DC 5V Power outlet Coax ON/OFF POWER RESET Router ETHERNET Coax Wall Plate Coax Coax wiring behind wall ROOM 2 TL-MC85 ON/OFF IN-OUT MOCA 2.5GE DC 5V Power... -
Page 4: Setup Instructions
Setup Instructions: Router ROOM 1 Unbox your MoCA 2.5 Network Adapter Connect your Adapter to a power outlet Connect one ethernet cable from the router to the TL-MC85 Network Adapter (2.5GE port preferred) Connect a coax cable from the MoCA port on the Network Adapter to the coax wall outlet Note: If you have a splitter, make sure the splitter is a MoCA splitter that... - Page 5 Setup Instructions: Router ROOM 2 Unbox your second MoCA 2.5 Network Adapter Connect your Adapter to a power outlet Locate the coax wall outlet and connect a coax cable from the wall outlet to the MoCA port of the Network Adapter. *IMPORTANT* : When the MoCA LED is GREEN on both adapters, your adapters are working Connect a networking device using a LAN cable to...
-
Page 6: (Moca Adapter Connection To A Cable Modem - Internet + Tv)
Setup Instructions: (MoCA Adapter Connection to a Cable Modem) (Internet + Tv) ROOM 1 TL-MC85 ON/OFF IN-OUT MOCA 2.5GE DC 5V Power outlet Coax Coax ON/OFF Coax POWER RESET Coax Cable Modem ETHERNET CABLE Coax Wall Plate Coax wiring behind wall ROOM 2 (optional) TL-MC85... - Page 7 Setup Instructions: Cable Modem - ROOM 1 Unbox your MoCA 2.5 Network Adapter Connect your Adapter to a power outlet Connect one ethernet cable from the Cable Modem to the TL-MC85 Network Adapter (2.5GE port preferred) Connect a MoCA splitter to the coax cable coming from the coax outlet on the wall.
- Page 8 Setup Instructions: Cable Modem - ROOM 2 Unbox your second MoCA 2.5 Network Adapter Connect your adapter to a power outlet Locate the coax wall outlet and connect a coax cable from the wall outlet to a MoCA splitter Connect a coax cable from the splitter to the MoCA port of the Network Adapter.
-
Page 9: (Moca Adapter Connection To A Cable Modem - Internet Only)
Setup Instructions: (MoCA Adapter Connection to a Cable Modem) (Internet Only) ROOM 1 TL-MC85 ON/OFF IN-OUT MOCA 2.5GE DC 5V Power outlet ON/OFF Coax POWER RESET Cable Modem ETHERNET CABLE Coax Coax Wall Plate Coax wiring behind wall ROOM 2 TL-MC85 ON/OFF IN-OUT... -
Page 10: Docsis 3.1 Cable Modem
If you are using a DOCSIS 3.1 Cable Modem, changes on the network adapters will have to be made. You may follow the steps below or request Translite for a firmware suitable for Docsis3.1 environment. Log in to the network adapter using the default IP address 192.168.144.200... -
Page 11: Firmware Upgrades
Firmware Upgrades For firmware upgrades, you may visit our website www.transliteglobal.com or send an email to support@transliteglobal.com Sales North America: sales@transliteglobal.com Asia: sales@translite.co.in Rest of the World: sales@transliteglobal.com Support North America: support@transliteglobal.com Asia: support@translite.co.in Rest of the World: support@transliteglobal.com page...
