P a g e
| 1
PRODUCT MODEL NUMBER:
TL-MC85
ETHERNET OVER COAX ADAPTER
ABOUT THIS
MANUAL
DISCLAIMER
No part of this document may be reproduced in any form without the written permission of the copyright
owner.
The contents of this document are subject to revision without notice due to continued progress in
methodology, design and manufacturing. TRANSLITE GLOBAL LLC shall have no liability for any error or
damage of any kind resulting from the use of this document
COPY WARNING
This document includes some confidential information. Its usage is limited to the owners of the
product that it is relevant to. It cannot be copied, modified, or translated in another language
without prior written authorization from TRANSLITE GLOBAL LLC
Advertisement
Table of Contents
Related Manuals for TransLite TL-MC85
Summary of Contents for TransLite TL-MC85
- Page 1 The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. TRANSLITE GLOBAL LLC shall have no liability for any error or damage of any kind resulting from the use of this document COPY WARNING This document includes some confidential information.
-
Page 2: Table Of Contents
P a g e INDEX TABLE OF CONTENTS CHAPTER 1 BASIC ILLUSTRATION ................... 3 .................... 3 ONNECT THE ADAPTER ......................4 NSTALLATION OTES ................... 4 SUAL EPLOYMENT ETHODS CHAPTER 2 INSTALLING THE MOCA ADAPTER ..............8 ......................8 NSTALLATION TEMS NMS ................ -
Page 3: Chapter 1 Basic Illustration
P a g e CHAPTER 1 BASIC ILLUSTRATION CONNECT THE MoCA ADAPTER For a ‘point to point’ connection, you need two adapters. The first MoCA adapter is connected to the Cable modem or Router, the second adapter at the other end of the coaxial cable: 1. -
Page 4: Installation Notes
4. On the receiving end, connect to the MoCA port of the MoCA adapter. 5. TL-MC85 has two available Ethernet ports that can be used to connect up to two network devices. (** The Ethernet ports are Gigabit Ethernet Ports**) INSTALLATION NOTES ➢... -
Page 5: Usual Deployment Methods
P a g e USUAL DEPLOYMENT METHODS TRANSLITE TL-MC85 MoCA2.5 BASIC INSTALLATION... - Page 6 P a g e TRANSLITE TL-MC85 MoCA2.5 INSTALLATION WITH A 2- WAY SPLITTER...
- Page 7 P a g e TRANSLITE TL-MC85 MoCA2.5 INSTALLATION WITH A 3- WAY SPLITTER...
-
Page 8: Installing The Moca Adapter
INSTALLALLING THE MoCA ADAPTER INSTALLATION ITEMS TL-MC85 comes in a plug and play condition. If the user may choose to make changes to the network adapter, changes can be made on the Web GUI by following the instructions as illustrated below: CONNECT TO THE DEVICE VIA WEB NMS ** Adapters have their own IP address (192.168.144.200). - Page 9 P a g e 2.2.1 TL-MC85 SETTINGS MENU (WEB NMS) 1. Band：TL-MC85 supports three bands, D-Ext (1125~1675mhz), D- Low(1125~1225MHz), D-High(1350~1675MHz). 2. Network Search Enabled : when ‘checked’ turns on the frequency scanning. 3. LOF (Last Operating Frequency): This is set by the supplier at 1150MHz. Please note, if you reset the adapter or return the adapter to the factory settings, the LOF will be 1150mHz.
- Page 10 P a g e | 10 2.2.2 DEVICE SETUP MENU (WEB NMS) Device Setup 1. IP address, Netmask & Gateway: The network configuration of the device can be changed to manage the device on your home network. 2. Telnet: The default setting is set to – ‘Enable’.
- Page 11 P a g e | 11 2.2.3 SECURITY MENU (WEB NMS) Security 1. The user may change the default password on this page. The default login is printed at the back of the adapter. 2. Once the password is changed, save and reset (reboot) the adapter for the changes to take effect.
- Page 12 P a g e | 12 TL-MC85 MoCA adapter supports MoCA Protected Setup (MPS) feature. This feature simplifies the setup of new nodes by a unique password that is shared through a MPS push-button. When you use the MPS feature in the default configuration, you must press on the push-buttons of the nodes within two minutes to achieve pairing for privacy.
- Page 13 P a g e | 13 2.2.5 PHY RATES MENU (WEB NMS) PHY Rates Monitor data rates between all adapters in the network...
- Page 14 P a g e | 14 2.2.6 UPGRADE MENU (WEB NMS) Upgrade If there is a firmware upgrade available from the vendor, you will first have to download the new firmware to your computer before uploading to the adapter via the ‘Choose file’ option. Once the upgrade is complete, reset (reboot) the adapter for changes to take effect.
- Page 15 P a g e | 15 2.2.7 REBOOT MENU (WEB NMS) Reboot (reset) For remote management, one can reboot or in other words reset the device on this page.
-
Page 16: Chapter 3 Specifications
P a g e | 16 CHAPTER 3 SPECIFICATIONS Basic Info Model TL-MC85 Technical Standard MoCA2.5 Standard Maximum Network Node Communication Mode Modulation Mode OFDMA Sub-carrier Quantity 512*5 Sub-carrier Bandwidth 195.3125KHz Carrier Modulation BPSK, QPSK, 8QAM, 16QAM, 32QAM, 64QAM, 128QAM, 256QAM,... - Page 17 P a g e | 17 Receiving Sensitivity -70dBm Insertion Loss < 2dB Transmitting Distance 300feet CABLE IN Port 5 ~ 1675MHz Frequency MoCA Port Frequency 1125 ~ 1675MHz TV OUT Port Frequency 5 ~ 1002MHz Maximum PHY Rate 3.6 Gbps Coaxial Cable Bidirectional, up to 3.0Gbps Application Rate...
-
Page 18: Chapter 4 Applications
P a g e | 18 Anti-Static Contact-Discharge 6KV, Air-Discharge 8KV Power Protection Surge-Resisting/Low-voltage Protection Dimension 129*80*32mm（L×W×H） Dimension Operating Environment Operating -10 ~ 45℃ Temperature Operating Humidity 5%～95% , No condensation -30～70℃ Store Temperature CHAPTER 4 APPLICATIONS... - Page 19 P a g e | 19...
