Summary of Contents for Waterflex LANABIKE EVO

  • Page 1 USER’S MANUAL / Keep this user’s manual...

  • Page 2: Safety Precautions

    Safety Precautions For your safety, please read these instructions before use ! Assembly this product properly using original parts according to the installation instruction. Before assembly, inspect whether packages are in good condition and whether spare parts are complete in accordance with transport precautions and the list of spare parts.
  • Page 3 Maintenance advices 7,6. WARNING Check the pH of the water on each utilisations. The pH water should be between 6.7 and 7.6. Any damages caused by a wrong pH balance cancel the warranty. (For anodized aluminum, inox parts, and silicone parts) AISI 316L, 2001/95/EC pH (6,7 / 7,6).

  • Page 4: Exploded View

    Exploded view Tools Note: use these tools only to assemble this exercise bike. WARNING: Keep the tools away from babies and children.

  • Page 5: Part List

    Part List N° Description / Quantity Protective cap Handlebar Pedal (A-B) (A-B) Seat Seat mounting plate Seat tube Bolt M6×30mm 6×30 Clench washer Welded nut Handle «Click & Turn» «Click & Turn» Anode Anode Screw Behind tube Crank (A-B) Crank locknut (A-B) (A-B) Foot mat Height adjustment knob...

  • Page 6: Installation

    Installation Step 1 : (20) (19), (21) (22). Install 20 to the front tube with 19, 21 and 22. Step 2 : (18) (23) (17). Install the front foot tube (18) onto the main frame (23) logo side, then adjust it with knob (17). Step 3 : (13) (23),...
  • Page 7 Installation Step 4 : (23), “Click-and-turn” (10). Install handlebar tube (2) onto the main frame (23), then adjust their position with the «Click-and-turn» handle (10). “Click-and-turn” WARNING: To prevent injuries, align the click-and-turn with the frame. (See picture above) Step 5 : (23), “Click-and-turn”...
  • Page 8 Installation Step 7 : (14) (15). Lock the pedals (3) on the cranks (14) with the lock-nuts (15). Step 8 : To the left pedal A (with crank A) the nut is screwed clockwise and against the lock-nut in the direction clockwise.
  • Page 9 Installation Height adjustment knob : To modify the height of your aquabike, unscrew and pull the round adjustment knob to unlock the bike leg. Then adjust the length and let the adjustment knob come back in position and screw it firmly.
  • Page 10 As you get trained you may need to train longer and harder. It is advisable to train at least three times a week, and if possible space your workouts evenly throughout the week. One more thing You’re looking for advice for your aquabike use? One link : www.waterflex.fr/page/youtube...

  • Page 11: Warranty

    The warranty is rendered null and void in the event of a repair carried out to the equipment by a person not approved by Waterflex. Faulty parts must be returned to Waterflex within the warranty period in order to be covered. The warranty does not cover labor, the cost of unauthorized replacement, or the cost of transporting the parts in question.
  • Page 12 Conseils www.waterflex.fr Assistance / SAV http://support.waterflex.fr Waterflex est une marque du groupe Poolstar www.poolstar.fr...
