Related Manuals for Jaeger-leCoultre REVERSO TRIBUTE DUOFACE CALENDAR
Summary of Contents for Jaeger-leCoultre REVERSO TRIBUTE DUOFACE CALENDAR
-
Page 1: Table Of Contents
CONTENTS Introduction Accuracy and precautions for use Water resistance “1000 Hours Control” test Care instructions for leather straps Technical specifications International Guarantee Limited Warranty (United States of America and Canada) Guarantee for Australia Customer Service... - Page 2 1 Second time zone 2 Day/night indicator 3 Day 4 Month 5 Minute hand 6 Crown 7 Hour hand 8 Moon phase 9 Date...
-
Page 3: Introduction
INTRODUCTION We would like to thank you for the confi- dence you have placed in Jaeger-LeCoultre. Our Maison has applied all its expertise and exacting standards to the creation of this model. We invite you to consult the operating in- structions and hope your Jaeger-LeCoultre timepiece brings you great joy. -
Page 4: Water Resistance
WATER RESISTANCE Your Jaeger-LeCoultre watch is water- resistant to 3 bar. Its water resistance can be identified by the symbol and/or the engraving: “3 bar”... - Page 5 - have the watch’s water resistance checked by an authorised Jaeger-LeCoultre retailer at least once every two years. It is essen- tial to have such a check carried out each...
- Page 6 - avoid using the controls, push-piece, or time-setting crown while under water, or outside the water, if the watch is not yet dry after immersion. - restore the time-setting crown and the push-pieces to their normal positions, (or where applicable, close the compression keys) after every manipulation.
-
Page 7: 1000 Hours Control" Test
“1000 HOURS CONTROL” TEST The Jaeger-LeCoultre Manufacture pays close attention to the quality and to the final checks of its watches. The 1000 Hours Control is a series of in- ternal qualification tests for each of the models in our collection, as well as inter- nal tests on the production of your watch, which go beyond official timing tests. -
Page 8: Care Instructions For Leather Straps
in temperature and atmospheric pressure, ability to withstand shocks and magnetic fields, as well as water resistance. CARE INSTRUCTIONS FOR LEATHER STRAPS 1. Keep the leather strap in a dry place 2. Avoid contact with water, cosmetics, perfumes, alcohol and oily materials 3. -
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS - Mechanical movement Manually wound manufacture, Jaeger-LeCoultre Calibre 853AA. - 21,600 vibrations/hour. - Power reserve: approximately 42 hours. - Page 10 STARTING THE WATCH Your Reverso Tribute Duoface Calendar watch is equipped with a 42-hour power reserve, during which time it can operate without any additional winding. WINDING Crown in position 0. The watch is wound by turning the crown clockwise. The movement is fully wound when the crown is locked.
- Page 11 reached the desired day of the week and set the exact time, push the crown back to position 0. When setting your watch during the af- ternoon, you must first turn the hands through 12 noon. When setting the time, in order to avoid disturbing the calendar functions, the hands must never be turned anti-clo- ckwise and never go beyond 3 a.m.
- Page 12 SETTING THE DATE Press corrector B at 4 o’clock. Each press moves the date hand one day forward. For months with fewer than 31 days, re- peat this process to reach the 1st of the following month. SETTING THE MONTH Press corrector A at 2 o’clock.
- Page 13 is because the automatic date-change mechanism is already in action between these times. BACK ADJUSTING THE SECOND TIME ZONE In the GMT (Greenwich Mean Time) sys- tem used practically throughout the wor- ld, the earth is divided into 24 time zones, each corresponding to 15 degrees’...
- Page 14 +1 +2 +3 +4 +5 +6 +7 +8 +9 +10 +11 +12 To set the second time zone indication of the Reverso Tribute Duoface Calendar watch, turn over the case of your watch (to the back face), without closing it back up.
- Page 15 By sliding it sideways you will cause the time display on the back dial to jump by one hour each time, thus, enabling you to correctly set the second time zone dis- play. During this operation, it is also re- commended to take into account the day/ night indication on the 6-hour disc.
- Page 16 Australia, Jaeger-LeCoultre products must be purchased exclusively from authorised Jaeger-LeCoultre retail- ers or from Jaeger-LeCoultre Boutiques. Maintenance and repair work must be en- trusted to an authorised Jaeger-LeCoultre retailer, a Jaeger-LeCoultre Boutique, or an authorised Jaeger-LeCoultre Service Centre. If these conditions are not met, the manufacturer’s guarantee does not...
-
Page 17: International Guarantee
Any part found by our technical services to be defective as a result of a manufac- turing defect will, at the sole discretion of Jaeger-LeCoultre, be repaired or replaced free of charge. The Jaeger-LeCoultre In-... - Page 18 Guarantee is valid only if the guarantee certificate enclosed with this booklet has been duly completed, dated, stamped, and signed by the authorised Jaeger-LeCoultre retailer or the Jaeger- LeCoultre Boutique, which sold you your watch. The Jaeger-LeCoultre International Guar-...
- Page 19 Jaeger-LeCoultre retailer, Jaeger- LeCoultre Boutique, or an authorised Jaeger-LeCoultre Service Centre (for further information please see your User Manual). For quartz watches, this guarantee does not cover the battery life. As a consumer, you may have legal rights under applicable national legislation gov- erning the sale of consumer goods;...
-
Page 20: Limited Warranty (United States Of America And Canada)
LIMITED WARRANTY (UNITED STATES OF AMERICA AND CANADA) The following Limited Warranty applies to Jaeger-LeCoultre products sold or pre- sented for warranty repairs in the United States of America and Canada only. TERMS AND CONDITIONS OF AEGER-LE OULTRE LIMITED WARRANTY... - Page 21 Jaeger-LeCoultre retailer or the Jaeger-LeCoultre Boutique, which sold you your watch. This Jaeger-LeCoultre Limited Warranty does not cover defects resulting from ac- cidents, mishandling, or incorrect, abusive use (for example, knocks, dents, crushing,...
- Page 22 Jaeger-LeCoultre retailer, a Jaeger- LeCoultre Boutique, or an authorised Jaeger-LeCoultre Service Centre (for fur- ther information please see your User Manual).
- Page 23 The liability of Jaeger-LeCoultre is limited solely and exclusively to repair or replace- ment under the terms and conditions stat- ed herein. Jaeger-LeCoultre shall not be liable, by virtue of this Limited Warranty...
-
Page 24: Guarantee For Australia
You are also entitled to have the goods repaired or replaced, if goods fail to be of acceptable quality and the failure does not amount to a major failure. This Jaeger-LeCoultre Guarantee gives you additional rights and remedies un- der the Australian Consumer Law and... - Page 25 Every Jaeger-LeCoultre product is made and tested to meet the Jaeger-LeCoultre quality standards. Nevertheless, should your Jaeger-LeCoultre product prove defective, please contact the Jaeger- LeCoultre retailer or Jaeger-LeCoultre Boutique indicated on your guarantee certificate;...
- Page 26 Jaeger-LeCoultre will remedy these identi- fied defects free of charge for up to two (2) years from the date of purchase. Thereafter, Jaeger-LeCoultre will repair any defective product or part subject to a service charge. The Jaeger-LeCoultre Guarantee does not...
- Page 27 It is essential to have the water resistance checked by an authorised Jaeger-LeCoultre retailer, a Jaeger-LeCoultre Boutique, or an author- ised Jaeger-LeCoultre Service Centre at least every two years, and in any event, prior to any period of intensive use. Please refer to the operating instructions for fur- ther details.
- Page 28 In Australia, a claim under the Jaeger- LeCoultre Guarantee may be sent to Richemont Australia Pty Ltd, provider of the guarantee service, at the address be- low or as specified above: Richemont Australia Pty Ltd PO Box 4780 Sydney, NSW 2001 Tel: +1 800 71 0665 Email: client.relations.asia@jaeger- lecoultre.com...
-
Page 29: Customer Service
CUSTOMER SERVICE A Jaeger-LeCoultre timepiece is a high- precision instrument that operates 24 hours a day, or 8,760 hours a year. There- fore, it is essential to have it serviced reg- ularly in order to guarantee its good work- ing order and its durability. If significant variations occur in the settings, it may be necessary to have the movement serviced. - Page 30 Jaeger- LeCoultre watches and clocks. In certain cases, especially for operations requiring special tools and parts, the Ser- vice Centres will send your watch to the Jaeger-LeCoultre Manufacture in Switzer- land to have the necessary work carried out.
