Eartec The UltraLITE - Full Duplex Wireless System Quick Start Guide


UltraLITE systems include one headset labeled "MASTER". This MASTER headset must be turned "ON" to link the corresponding REMOTE headsets.

Battery

All UltraLITE headsets are powered by a Lithium Polymer battery that will operate 6 hours when fully charged.

Charging

  1. Batteries are charged via the multi- charger.
  2. Insert the batteries making sure the contacts are properly a ligned.
  3. RED: Charging; GREEN: Fully Charged.

Installation

  1. Press the release button located on the bottom of the battery compartment.
  2. Insert the battery into the compartment (arrow indicates proper direction) and snap door closed.

Low Indicator
A repetitive beep (every 20 seconds) indicates low power – battery should be charged or replaced.

Battery Care

To preserve optimum charge level remove battery from headsets when system not in use.

Operation

Adjusting for Fit & Performance

  1. Adjust the headband slides for size as necessary.
  2. Position the microphone capsule at one finger's width from the corner of your mouth to ensure superior speech recognition and noise cancellation.
  3. "TALK" identifies front of microphone: always have this indicator facing towards your mouth.

STARTUP

  1. Turn ON the MASTER headset, switch is located below battery compartment. Flashing blue LED on earcup confirms headset is in search mode.
  2. Turn ON the REMOTE headset(s), press the power button located above volume controls.. Flashing blue LED on earcup confirms headset is in search mode.
  3. Flashing LEDs change to solid blue to indicate that headsets are connected.

SET VOLUME

UltraLITE features 5 volume settings. Select the desired volume by slowly clicking the UP or DOWN buttons. An audible tone reflects volume level. A double tone indicates low or max volume has been reached.

SHUT DOWN

Power OFF the MASTER headset utilizing switch, then PRESS and HOLD the power button on the Remote headset(s) for 4- ‐5 seconds to turn off.
Note: To preserve optimum charge level, remove battery from headsets when system not in use.

AutoMute Function

Boom swivels over the top 270 degrees. Headset can be worn on left or right ear.

Microphone mutes automatically when boom is set to "UP" position.

Prior to returning your headset for warranty or service you must call Eartec and for an
RA (Return Authorization) number: 1 (401) 782- 4966
Service
Eartec Co Inc
145 Dean Knauss Dr
Narragansett RI 02882
www.eartec.com
