Eartec UltraLite Printable Instructions

Programming The HUB – Printable
Instructions
HUB HD Mini-Base Programming Instructions
1. Start with all "Remote" UltraLite / UltraPaks powered "ON".
2. Remove belt clip on HUB Mini-Base to expose channel buttons "1"
and "2". Install battery in the HUB Mini-Base and turn power switch
"ON".
3. Press and hold programming button "1" (to program to channel
1) or "2" (to program to channel 2) on HUB for five seconds.
Red LED will begin flashing. This indicates that the HUB is ready to
link to a "Remote" UltraLite / UltraPak.
4. To program a "Remote" UltraLite / UltraPak press the volume "Down
arrow" 3 times and then press and HOLD the volume "UP arrow". Once
the LED on the Remote unit flashes blue/red, release the volume UP
arrow.
5. The pairing process can take from 5-30 seconds. Once the UltraLite /
UltraPak links, the LED will turn solid blue. The HUB will turn from a
flashing LED to a solid red LED. When both LED's are solid "Blue" the
UltraLite / UltraPak are paired to the HUB.
6. To program additional UltraLite / UltraPaks, to the HUB repeat steps
3-5 for each remaining unit.
*Each HUB can have up to 4 remote UltraLite / UltraPaks linked to each
channel.
