4 0 0 0 A N S I L U M E N S
PLC-XU110/100
The smallest and brightest of 4,000 AL
XGA projector in the world
AMAZING BRIGHTNESS LEVEL FOR AN ULTRAPORTABLE
The PLC-XU110/100 projects an outstanding brightness level
of 4,000 ANSI Lumens, illuminating even well-lit conference
rooms.
SMART AUTO INPUT SEARCH AND AUTO VERTICAL
KEYSTONE CORRECTION
Aimed to reduce setup time, the Auto Input Search function
detects various input signals and automatically selects the
correct mode to project images from their original sources.
Another timesaving function called the Auto Vertical Keystone
Correction (XU110 only) automatically compensates for
keystone picture distortions during setup.
ANITTHEFT ALARM SECURITY FUNCTION
The vibration sensor of PLC-XU110/100 is able to detect the
slightest position change of locked projectors to from being
stolen. Any irregular movements will set off the antitheft alarm
to alert the owner of suspicious behaviors.
TWO COMPUTER INPUTS (DVI-I AND D-SUB)
The PLC-XU110/100 have two computer input terminals—
DVI-I input (XU110) and 2 D-sub input (XU100). Also, each
has a D-sub monitor out terminal.
WIRELESS/WIRED LAN CAPABILITY
The PLC-XU110 is ready for wireless and wired LAN
connection to give you greater projecting versatility.
IEEE802.11b/g Wireless Function
Automatic Connection Setting for Wireless
Multi Control with Web Management
Moderator Function
Real-Time Transmission
One-Shot Transmission
Five-Unit Simultaneous Projection
E-mail Alert
WEP/LEAP Authentication
HIGH-QUALITY UXGA PROJECTION COMPRESSED
The PLC-XU110/100 deliver UXGA signal compatibility with
SANYO's Digital Realized Interpolation Technology (DRIT).
QUICK START AND POWER-OFF AND GO
No more waiting for the projector to cool down. Simply
disconnect the power cord right after the presentation, without
worrying about overheating.
USER-SPECIFIED START-UP SCREEN
To create a more professional presentation, logo and image
files may be captured for display during the projector's
countdown start-up sequence.
PRESENTATION TECHNOLOGIES
Back Panel of PLC-XU110
Issued 09/06
W I R E L E S S & W I R E D N E T W O R K I N G P R O J E C T O R
21605 Plummer Street
Chatsworth, CA 91311
Ph: 888-337-1215 (toll-free)
Fax 818.717.2719
www.sanyolcd.com
Back Panel of PLC-XU100
TENTATIVE
S p e c i f i c a t i o n s
Resolution
Brightness (typical)
Uniformity
LCD Panel System
Number of Pixels
Contrast Ratio
Projection Image (diagonal)
Aspect Ratio
Throw Distance
Zoom/Focus
Up/Down Ratio
Digital Keystone Correction
Projection System
Projection Lens
Lens Throw Ratio
Projection Lamp
Scanning Frequency
Dot Clock
Color System
Computer Compatibility
UXGA, WCGA, SXGA, XGA, SVGA, VGA, MAC analog
Sound Output
Voltage
BTU Rating
dB Rating
Power Consumption
Dimensions (WxHxD)
Net Weight
User Maintenance
PC Input Terminals
Video Input Terminals
Composite Video (RCA x 1) S-Video (mini-DIN 4-pin)
Output Terminals
Service Port Terminal
Mouse Control Port
Other Terminals
USB type A for Included USB Wireless LAN Adapter or
Included Accessories
ROM(Application soft)(XU110) Alarm Label (XU110)
Optional Accessories
POA-USB02 – USB Memory
POA-CACOMPVGA – VGA / Component Video cable
POA-MACAP - VGA / MAC Adapter
6103316345 – Replacement Lamp
POA-CAC-VCL2 – Carrying Case
POA–RCKIT03 – Laser R./C
POA-RSKIT04 – Presentation Kit
Warranty
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations.
XGA (1024 x 768)
4000 ANSI Lumens
85 %
0.8" TFT Poly x3
2,359,296 (786,432 x 3)
500:1 / 400:1
(XU110/XU100)
33"-300"
4:3
4.3'-32.8'
Manual (1:1.2 zoom)
9:1
Vert. +/- 40
Polarized Beam Splitter optical system
F1.7-2.1 / f1.05"-1.26"
1.51 – 1.83 : 1
300W UHP
H 15-100kHz; V 50-100Hz
140 MHz
PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
One-piece, 1-watt Mono
100-240V AC; 50/60/Hz (auto sense/select)
1331 (XU110), 1314 (XU100)
TBD
TBD
13.1" x3.0"x9.1" (not including Adjustable Feet)
7.7 lbs. (XU110), 7.5 Ibs. (XU100)
Clean air filters, replace lamp assembly
DVI-I x 1 (w/HDCP) (XU110)
D-Sub15 x 1/2 (XU110/100)
Audio x 1 (stereo mini-jack : common)
R & L/mono audio (RCA x 2)
Component Video (D-Sub15 input w/optional cable)
Audio for Component Video (stereo mini-jack)
D-Sub15 x 1 (Monitor Out)
Variable Audio from PC Audio Input or
Video Audio Input (Stereo Mini-Jack)
Mini DIN 8-pin
USB type B x 1(XU110)
Optional USB Memory(XU110)
RJ45 for Wired LAN (XU110)
Wireless/wired remote control with Mouse Pad and
Laser Pointer(wired only XU110)
2 AAAA batteries(110) 2 AAA batteries(100)
Owner's manual (Quick manual & CD-ROM) VGA
(XU110) cable PIN code label AC power supply
cord USB Wireless LAN Adapter (XU110) CD-
Soft Carry Bag (XU110)
Three years parts and labor; 90 days Initial lamp;
Quick Repair Program under warranty
©2005 SANYO
