SERVICE MANUAL

Product code
1 122 352 20
(KL6AC)
1 122 353 20
(LL6AC)
1 122 353 22
(LL6CC)
Multimedia Projector
Match the Chassis No. on the unit's back cover with the
Chassis No. in the Service Manual.
If the Original Version Service Manual Chassis No. does
not match the unit's, additional Service Literature is re-
quired. You must refer to "Notices" to the Original Service
Manual prior to servicing the unit.
FILE NO.
Model No. PLc-Xu101
U.S.A, Canada,
Europe, U.K, Asia
original Version
chassis No. KL6-Xu10100
REFERENCE NO.
SM
5110857-00
