- Page 1 AUTO-BLiP INTELLIGENT DOWNSHIFTS www.AUTO-BLiP.com User Manual 2006+ Honda s2000 Version 1.3 Copyright © 2012 Tractive Technology, LLC. All rights reserved. Page 1...
- Page 2 Do Not mount the AUTO-BLiP where it can obstruct the view of the driver Do Not mount the AUTO-BLiP in a manner that could cause it to be propelled through the vehicle during an accident causing injury, such as over or near an air bag ...
- Page 3 For this installation, you will only be working with the clutch Safety Interlock switch. Soldering the Auto-Blip harness wires (6) to the respective car wires provides for the best results. However, due to the challenge of working under the dash, this should only be done by a professional.
-
Page 4: Installation
5. Connect AUTO-BLiP white wire to the white/green wire on the brake pedal sensor (Figure 3). 6. Connect AUTO-BLiP blue wire to the white/black wire on the brake pedal sensor (Figure 3). 7. Connect AUTO-BLiP red wire and green wire, one each to the, to the red/yellow and red/blue wires on the ECU (Figure 5). - Page 5 Remove locking Slide plastic cover Figure 2 (ECU Location) Brake Sensor Clutch Interlock Sensor Figure 3 (Sensor Locations) Copyright © 2012 Tractive Technology, LLC. All rights reserved. Page 5...
- Page 6 Clutch Interlock Sensor Figure 4 (Clutch Interlock Sensor) Unplug ECU connector to access APPS wires Figure 5 (Accelerator Pedal Position Sensor Wires) Copyright © 2012 Tractive Technology, LLC. All rights reserved. Page 6...
-
Page 7: How It Works
7. The “BLIP” LED turns on when a throttle blip event occurs. Note: The AUTO-BLIP will automatically turn OFF after 6 hours of inactivity. It will remain OFF until the ON/OFF button is pressed or power to the unit is removed and re-applied. - Page 8 In order for your AUTO-BLiP unit to function properly, you must first perform the calibration sequence outlined in this section!!! 1. Turn on ignition, but do not start engine. AUTO-BLiP “STATUS” LED light will light up. If not, turn ignition off and verify the power supply and ground connectors are fully seated.
-
Page 9: Tech Support
3. Be sure the unit has been calibrated, as outlined in the calibration section, according to your vehicle’s model and year. 4. Check harness for cuts, scrapes or abrasions. 5. Technical support: call (713)289-4015 (Mon-Fri from 9A-3P CST); email al@auto-blip.com Copyright © 2012 Tractive Technology, LLC. All rights reserved. Page 9... - Page 10 This warranty applies only to AUTO-BLiP product manufactured by Tractive Technology, LLC that can be identified by the "AUTO-BLiP" trademark, trade name, or logo affixed to them. This warranty does not cover damage resulting from an accident, misuse, abuse, or neglect and/or damage during any type of transportation resulting from improper packaging;...
