- Page 1 AUTO-BLiP INTELLIGENT DOWNSHIFTS www.AUTO-BLiP.com BMW E90/92 thru 2008 Customer contribution to Bimmerpost blog (not corroborated by Auto-Blip) Version 1.2 Copyright © 2012 Tractive Technology, LLC. All rights reserved. Page 1...
- Page 2 Do Not mount the AUTO-BLiP where it can obstruct the view of the driver Do Not mount the AUTO-BLiP in a manner that could cause it to be propelled through the vehicle during an accident causing injury, such as over or near an air bag ...
-
Page 3: Installation Chart
For this installation, you will only be working with the clutch Safety Interlock switch. Soldering the Auto-Blip harness wires (6) to the respective car wires provides for the best results. However, due to the challenge of working under the dash, this should only be done by a professional. -
Page 4: Installation
INSTALLATION: Remove the panel under dash to access the pedals. For help: www.pelicanparts.com/BMW/techarticles Connect AUTO-BLiP black wire to the wire behind pin #4 at the OBD2 port see Fig 1 bellow. Alternate placement to OBD2: Tap the Brown/Black wire at the clutch pedal sensor (located at the very top of pedal) Connect AUTO-BLiP white wire to the wire behind pin #16 at OBD2 port see Fig 1 bellow. -
Page 5: How It Works
7. The “BLIP” LED turns on when a throttle blip event occurs. Note: The AUTO-BLIP will automatically turn OFF after 6 hours of inactivity. It will remain OFF until the ON/OFF button is pressed or power to the unit is removed and re-applied. - Page 6 For vehicles equipped with DIGITAL sensors for the brake and/or clutch pedals, please follow the calibration steps below: 1. Turn on ignition, but do not start engine. AUTO-BLiP “STATUS” LED light will light up. If not, turn ignition off and verify the power supply and ground connectors are fully seated.
- Page 7 BRAKE and/or CLUTCH will prevent the unit from exiting the calibration sequence. This is done to prevent AUTO-BLiP from blipping the throttle at the incorrect time. When a failure is detected the AUTO-BLiP will continuously blink the “BRAKE”, “CLUTCH”, and/or “BLIP” LEDs, signaling a failure during calibration of the respective signals.
-
Page 8: Tech Support
3. Be sure the unit has been calibrated, as outlined in the calibration section, according to your vehicle’s model and year. 4. Check harness for cuts, scrapes or abrasions. 5. Technical support: call (713)289-4015 (Mon-Fri from 9A-3P CST); email al@auto-blip.com Copyright © 2012 Tractive Technology, LLC. All rights reserved. Page 8... - Page 9 This warranty applies only to AUTO-BLiP product manufactured by Tractive Technology, LLC that can be identified by the "AUTO-BLiP" trademark, trade name, or logo affixed to them. This warranty does not cover damage resulting from an accident, misuse, abuse, or neglect and/or damage during any type of transportation resulting from improper packaging;...
