  • Page 1 FRYER Manual Instructions TEK 40 LPG , TEK 40 NG, TEK 50 LPG, TEK 50 NG, TEK 70 LPG, TEK 70 NG & TEK SPG NG Manual instructions Manueltalimatları Kurulum ve Çalıştırma Installation and Operation Manual de instrucciones Manuel d’instructions...
  • Page 2: Table Of Contents

    DOCUMENTCODE: INDEX ENGLISH MACHINE INTRODUCTION ............................1 INTRODUCTION TO MACHINE& MODELS ....................1 IMPORTANT SAFETY INFORMATION & USAGE ..................1 SPECIFICATION CHART ..........................1 INSTALLATION ................................2 TRANSPORT, HANDLING, UNPACKING, LOCATION..................2 MANUFACTURER’S IDENTIFICATION LABEL DESCRIPTION ..............2 INSTALLATION AND ASSEMBLY .......................3 2.3.1 UNCRATING .............................3 2.3.2 INSTALLATION OF LEGS ........................3 HOW TO INSTALL UPPER FLUE ASSEMBLY TO TEK 40 MODELS ..............5 GAS CONNECTIONS ..........................5 2.5.1...
  • Page 3: Machine Introduction

    MACHINE INTRODUCTION 1.1 INTRODUCTION TO MACHINE& MODELS All equipment manufactured by THERMATEK. Is for use with the type of gas specified on the rating plate and for installation will be in accordance with National Fuel Gas Code ANSI Z223.1 (latest edition) Instruction to be followed in the event the user smells gas shall be posted in a prominent location.
  • Page 4: Installation

    INSTALLATION 2.1 Transport, handling, unpacking, location. 2.2 Manufacturer’s identification label description. 2.3 Installation and assembly. 2.4 Gas Connections 2.1 TRANSPORT, HANDLING, UNPACKING, LOCATION Upon receiving your new THERMATEK Equipment, check the package and the machine for any damages that may have occurred during transportation. Visually inspect the exterior of the package. If damaged, open and inspect the contents with the carrier.
  • Page 5: Installation And Assembly

    2.3 INSTALLATION AND ASSEMBLY SHIPPING DAMAGE CLAIM PROCEDURE The equipment is inspected and crated by skilled personnel before leaving our factory. The transportation company assumes full responsibility for safe delivery upon acceptance of this equipment. If shipment arrives damaged: Visible loss or damage: Note on freight bill or express delivery and signed by person making delivery.
  • Page 6: How To Install Upper Flue Assembly To Tek 40 Models

    2.1 HOW TO INSTALL UPPER FLUE ASSEMBLY TO TEK 40 MODEL Step 1: Turn furnishing in order to see fryer back. Step 2: Insert upper flue and Install Screws into locations shown at bottom of back upper flue to secure. Step 3: Place the Back Panel.
  • Page 7: Gas Connections

    2.5 GAS CONNECTIONS The gas supply (service) line must be the same size or greater than the inlet line of the appliance. THERMATEK equipment’s appliances use a ¾” NPT inlet. Pipe joint compound must be resistive to Natural or LP gas. For equipment using propane gas do not install supply lines with a diameter less than ½...
  • Page 8: Pressure Regulator Conversion

    2.5.4 PRESSURE REGULATOR CONVERSION A. Remove cap and snap out plastic plunger from bottom of cap. B. Turn plunger over and snap back in original location. C. Re-insert the cap assembly into the regulator and tighten. Failure to install the pressure regulator will void the appliance warranty The fryer needs to be restrained to prevent tipping when installed in order to avoid the splashing of hot liquid.
  • Page 9: Operation

    OPERATION 3.1 General information. 3.2 Lighting Instructions. 3.3Daily Shut-Down. 3.1 GENERAL INFORMATION. Operation of this equipment must be performed by qualified or authorized personnel who have read and are familiar with the functions of the equipment. WARINING Hot oil and hot surfaces can cause severe burns. Use caution when operating the fryer. Do not attempt to move the fryer filled whit hot oil or shortening.
  • Page 10: Maintenance

    MAINTENANCE 4.1 CLEANING For continued performance efficiency and longevity of your Fryer it is essential to carry out a good maintenance program. 4.1.1 DAILY 1. Remove and wash thoroughly all “loose” parts (basket hanger, baskets, crumb screen, etc.). 2. Wipe clean all exterior and interior accessible surfaces and parts. 3.
  • Page 11: Trouble Shooting

    TROUBLE SHOOTING PROBLEM PROBABLE CAUSE REMEDY Pilot will not a. No gas a. Turn main gas valve “ON” light b. Gas tap dial not set at “Pilot” b. Set dial position and depressed. combination gas valve to “Pilot”. Depress and hold while lighting.
  • Page 12 115 Rotary Drive, Valmont Industrial Park West Hazleton, PA 18202...
