- Page 1 Speed Striker™ Power Screed Speed Striker™ Power Screed STRIKE45-L 28166 WS1716 1 of 14 3-2017/Rev .A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Precaution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Common Components . -
Page 3: Common Components
COMMON COMPONENTS 1. Start/Stop Switch 2. Engine 3. Recoil Starter 4. Oil Cap 5. Gas Cap 6. Throttle Lever 7. Handle Bar Mounting Blocks 8. Handle Bars 9. Kickstand 10. Drive Shaft 11. Vibration Dampeners 12. Blade 13. Eccentric Weight Cover 14. -
Page 4: Assembly Instructions
ASSEMBLY INSTRUCTIONS Assembly is easy, following these steps: INSTALLING HANDLE BARS AND KICKSTAND: Step 1 – Remove the 4 hex screws (A) that hold down the two handle mounting blocks A A A Step 2 – Slide kickstand arm onto kickstand end and fasten with nut &... - Page 5 ASSEMBLY INSTRUCTIONS INSTALLING THROTTLE CABLE: Step 2 – The throttle has a rotating silver peg (A) with a slot on one side of it . One end of the throttle cable has a metal Step 1 – Remove carburetor cover by pressing clips . barrel (B) that fits into this slot .
- Page 6 ASSEMBLY INSTRUCTIONS Step 5 – Thread the exposed metal end of the throttle cable Step 6 - Once cable is through throttle lever, return the into the throttle lever . The lever will need to be “opened” to lever to the “idle” position shown above . Using pliers, pull expose the hole it fits into .
-
Page 7: Machine Adjustments
MACHINE ADJUSTMENTS WARNING HANDLE Your screed handle can be adjusted for a customized fit . Always make sure engine is stopped with switch in "OFF" position before making adjustments . ECCENTRIC WEIGHTS The factory weight set- ting will provide sufficient board vibration for most jobs . -
Page 8: Parts Breakdown
PARTS BREAKDOWN DET. QTY. DESCRIPTION GX35 HONDA MOTOR HANDLEBAR CLAMP HANDLEBAR ASSEMBLY BASE EXTRUSION KILL SWITCH VIBRATION ISOLATOR ECCENTRIC WEIGHT #1 ECCENTRIC WEIGHT #2 ECCENTRIC SHAFT ECCENTRIC WEIGHT BUSHING WEIGHT ADJUSTMENT CAP LOWER BEARING HOUSING COUPLING DRIVE SHAFT CLUTCH FLEX SHAFT BLADE ATTACHMENT NUT BLADE KICKSTAND END... - Page 9 PARTS BREAKDOWN REPLACEMENT BLADES Part# SIZE-FT. SIZE-M 13336 SWBLADE4 1 .2 19288 SWBLADE45 4 .5 1 .37 13281 SWBLADE6 1 .8 13283 SWBLADE8 2 .4 13284 SWBLADE10 3 .0 28226 SSBLADE12-L 3 .7 13290 SWBLADE14 4 .3 13290 SWBLADE16 4 .9 12950 SWBLADE16P2 16 (2 sets of mounting holes)
-
Page 10: Wet Screeding
HOW TO WET SCREED Blade Length SETTING ELEVATION OF SLAB • Use grade pins (A) to set height of slab in the middle of the pour . 12-18 inches • Chalk line or expansion joint sets elevation around walls . •... -
Page 11: Form To Form Screeding
HOW TO SCREED FORM TO FORM Length of board should overlap form boards on both sides of the pour WIDTH OF SCREED BOARD WIDTH OF FORM Keep bottom of blade as flat as possible while striking off of forms To ensure the longest possible board life, use the lowest possible vibration setting in relationship to the slump of concrete being used . -
Page 12: Technical Data/Capacities
TECHNICAL DATA/CAPACITIES Model Number STRIKE45-L CAUTION Drive System Flexible Shaft Weight 28 . 5 lbs . (12 . 9 kg) Your screed ships with a 4, 4 . 5 , 6, 8, 10, 12, 14, 16' Blade Lengths pre-measured bottle of oil (3 .5 oz) . 1 . -
Page 13: How To Operate
HOW TO OPERATE FUEL AND OIL Make sure gas tank has plenty of 86 octane or higher gasoline . Your 4 stroke Honda engine used straight gasoline, NEVER USE A GAS/OIL MIX . Empty entire bottle of provided Honda engine oil into crank case . - Page 14 Always remember, the less vibration the better . Use only enough vibration to be able to comfortably pull screed backwards, leaving a smooth, level surface . 104 S. 8th Ave. Marshalltown, IA Phone 800-888-0127 / 641-753-0127 Fax 800-477-6341 / 641-753-6341 www.MARSHALLTOWN.com...
