- Page 1 PORTABLE DAB RADIO USER’S MANUAL SENCOR SRD 6600 DAB+...
-
Page 3: Safety Information
Safety information 1. Safety information IMPORTANT SAFET Y INSTRUCTIONS The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). - Page 4 Safety information 10. NON-USE PERIODS – The power cord of the product should be unplugged from the outlet and slide the power switch to OFF position when left unused for long periods of time. 11. OBJECT AND LIQUID ENTRY – Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock.
-
Page 5: Controls And Connections
Controls & Connections 2. Controls & Connections TUNE + /- button SCAN button MENU button 10. SLEEP button ST.MO/ SELECT button 11. VOLUME knob STANDBY button 12. HANDLE LCD Display 13. DC input socket 6. FUNCTION button 14. Power ON/OFF switch PRESET button 15. -
Page 6: Getting Started
Getting Started 3. Getting Started 3.1. DAB/FM antenna Before using your radio for DAB or FM reception, full extend the telescopic antenna which located at the back of unit. You may need to adjust the position of the telescopic antenna for maxing signal strength. -
Page 7: Adjust The Volume
Getting Started To turn the unit in STANDBY mode: • Press the STANDBY button. The clock will continue to run whilst mains power is connected. 3.5.2. Using battery power Charging the battery • Slide the power switch to “OFF” position. •... -
Page 8: Listen To Dab Radio
Getting Started Press TUNE +/- to scroll the menu options. To select an option, press SELECT [Main menu] button -> SYSTEM [Clock Setup] Set the Clock setup to Manual (Defaulted at Radio). To select an option, press SELECT button. 6. Repeat steps 2-5 if any sub-option is available under an option. 3.8. -
Page 9: Show Dab Information
Getting Started 3.8.4. Show DAB information During DAB radio broadcast, press INFO button repeatedly to scroll through the following information (if available): • Station name • Channel and frequency • Audio bit rate • Signal strength • Time/ Date • Dynamic label segment (DLS) •... -
Page 10: Store Fm Radio Stations Manually
Getting Started 3.10.2. Store FM Radio stations manually Tune to FM radio station. Press and hold PRESET button in 3 secs to activate programming mode. Display show P1 and briefly, press TUNE +/- repeatedly to select a preset number Press SELECT to confirm Repeat steps 1-4 to store more FM stations. -
Page 11: Sleep Function
Getting Started 3.11. Factory Reset This option will restore all settings to ‚ factor y original’. All clock, station lists and stored preset stations will be cleared. After factor y reset the radio will automatically re-scan the DAB band. 3.12. Aux in Connect your auxiliary device to the 3.5mm AUX IN socket on the back of the unit. -
Page 12: Troubleshooting
Troubleshooting 4. Troubleshooting PROBLEM CAUSE / SOLUTION No power – Slide the power switch to ON position. – Ensure that the power plug is connected properly. – Ensure that there is power at the AC Mains. – Ensure that the batteries are fully charged. –... -
Page 13: Specifications
The CE symbol shown on the unit, in the user’s manual and on the package indicates the unit meets the basic requirements of guideline R&TTE, 1995/5/EC, Guideline for low voltage 73/23/EEC. The declaration of conformity can be found at www.sencor.cz. EN 11 Copyright ©... - Page 14 INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste. Please, dispose of this product at your applicable collection point for the recycling of electrical &...
-
Page 15: Warranty Conditions
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the serial number or the warranty seal has been damaged). Authorized ser vice centers Visit www.sencor.eu for detailed information about authorized service centers. EN 13 Copyright © 2016, Fast ČR, a. s. - Page 18 Designed in Europe by Sencor ® , Made in China www.sencor.cz...
