ADF Web HD67735-A1 User Manual

Server / modbus tcp master - converter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Industrial Electronic Devices
User Manual
Revision 1.000
English
IEC 61850 Server / Modbus TCP Master -
Converter
(Order Code: HD67735-A1 )
For Website information:
www.adfweb.com?Product=HD67735
For Price information:
www.adfweb.com?Price=HD67735-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG
For other IEC 61850 server products see also the following link:
Converter IEC 61850 Server to
www.adfweb.com?Product=HD67733
www.adfweb.com?Product=HD67734
www.adfweb.com?Product=HD67736
www.adfweb.com?Product=HD67737
www.adfweb.com?Product=HD67738
www.adfweb.com?Product=HD67739
www.adfweb.com?Product=HD67740
www.adfweb.com?Product=HD67741
www.adfweb.com?Product=HD67742
www.adfweb.com?Product=HD67743
www.adfweb.com?Product=HD67744
www.adfweb.com?Product=HD67745
www.adfweb.com?Product=HD67746
www.adfweb.com?Product=HD67747
www.adfweb.com?Product=HD67748
www.adfweb.com?Product=HD67749
www.adfweb.com?Product=HD67750
www.adfweb.com?Product=HD67751
www.adfweb.com?Product=HD67B82
www.adfweb.com?Product=HD67752
www.adfweb.com?Product=HD67753
www.adfweb.com?Product=HD67754
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.000
Page 1 of 28
(Modbus Master)
(Modbus Slave)
(Modbus TCP Slave)
(BACnet Master)
(BACnet Slave)
(CAN)
(CANopen)
(DeviceNet Master)
(DeviceNet Slave)
(EtherNet/IP Master)
(EtherNet/IP Slave)
(J1939)
(KNX)
(MQTT)
(NMEA 0183)
(NMEA 2000)
(PROFIBUS Master)
(PROFIBUS Slave)
(PROFINET Master)
(PROFINET Slave)
(SNMP Manager)
(SNMP Agent)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD67735-A1 and is the answer not in the manual?

Questions and answers

Related Manuals for ADF Web HD67735-A1

Summary of Contents for ADF Web HD67735-A1

  • Page 1 Industrial Electronic Devices User Manual Revision 1.000 English IEC 61850 Server / Modbus TCP Master - Converter (Order Code: HD67735-A1 ) For Website information: For other IEC 61850 server products see also the following link: www.adfweb.com?Product=HD67735 Converter IEC 61850 Server to www.adfweb.com?Product=HD67733...

  • Page 2: Table Of Contents

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 2 of 28 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that INDEX you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST...

  • Page 3: Security Alert

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 3 of 28 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.

  • Page 4: Example Of Connection

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 4 of 28 Industrial Electronic Devices EXAMPLES OF CONNECTION: ADFweb.com S.r.l.

  • Page 5: Connection Scheme

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 5 of 28 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67735-A1 ADFweb.com S.r.l.

  • Page 6: Characteristics

    Page 6 of 28 Industrial Electronic Devices CHARACTERISTICS: The HD67735-A1 are IEC 61850 / Modbus TCP Master - Converters. It allows for the following characteristics: Up to 512 Modbus reading requests and 512 Modbus writing requests; Isolation between Ethernet - Power Supply;...

  • Page 7: Power Supply

    The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67735-A1 Caution: Do not reverse the polarity power HD67735-A1 ADFweb.com S.r.l.

  • Page 8: Function Modes

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 8 of 28 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’...

  • Page 9: Leds

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 9 of 28 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered...

  • Page 10: Ethernet

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 10 of 28 Industrial Electronic Devices ETHERNET: IEC 61850 and Modbus TCP connection and the updating of the converter must be made using Connector3 and/or Connector4 of the HD67733-X-A1 with at least a Category 5E cable.

  • Page 11: Use Of Compositor Sw67735

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 11 of 28 Industrial Electronic Devices USE OF COMPOSITOR SW67735: To configure the Converter, use the available software that runs with Windows called SW67735. It is downloadable on the site www.adfweb.com and its operation is described in this document.

  • Page 12: New Configuration / Open Configuration

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 12 of 28 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “IEC 61850 Server / Modbus TCP Master - Converter”...

  • Page 13: Software Options

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 13 of 28 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
  • Page 14 User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 14 of 28 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.

  • Page 15: Set Communication

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 15 of 28 Industrial Electronic Devices SET COMMUNICATION: By Pressing the “Set Communication” button from the main window for SW67735 (Fig. 2) the window “Set Communication” appears (Fig. 3). The window is divided in different sections in order to define the different parameters of the converter: IEC 61850 Server...
  • Page 16 User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 16 of 28 Industrial Electronic Devices IEC 61850 S ERVER This section is used to define the main parameters of IEC 61850 line. The means of the fields are: In the field “Port”...
  • Page 17 User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 17 of 28 Industrial Electronic Devices TCP M ODBUS ASTER This section is used to define the main parameters of Modbus TCP line. The means of the fields are: In the field “IP...

  • Page 18: Iec 61850 Access

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 18 of 28 Industrial Electronic Devices IEC 61850 ACCESS: By Pressing the “IEC 61850 Access” button from the main window for SW67735 (Fig. 2) the window “Set Variables Access for IEC 61850” appears (Fig.

  • Page 19: Modbus Set Access

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 19 of 28 Industrial Electronic Devices MODBUS SET ACCESS: By pressing the “Modbus Set Access” button from the main window for SW67735 (Fig. 2) the window “Set Modbus Access” appears. This window is divided in two parts, the "Modbus Read"...
  • Page 20 User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 20 of 28 Industrial Electronic Devices In the field “Poll Time” the delay time to make the request is defined; In the field “Max Error” the number of consecutive errors that the converter waits before suspending the request until the next reboot is defined.
  • Page 21 User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 21 of 28 Industrial Electronic Devices In the field “NPoint” the number of consecutive registers to be written is defined; In the field “Poll Time” the delay time to make the request is defined; If the field “On Change”...

  • Page 22: Tls Known Certificate

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 22 of 28 Industrial Electronic Devices TLS KNOWN CERTIFICATE: Figure 6: “TLS Known Certificate” window By pressing the “TLS Known Certificate” button from the Main Window of SW67735 (Fig. 2) the “Definition the list of Known Certificates” window appears (Fig.

  • Page 23: Update Device

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 23 of 28 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port.
  • Page 24 User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 24 of 28 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67735 device. Warning: If Fig.

  • Page 25: Mechanical Dimensions

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 25 of 28 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 9: Mechanical dimensions scheme for HD67735-A1 ADFweb.com S.r.l.

  • Page 26: Ordering Informations

    Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67733: IEC 61850 Server / Modbus Master - Converter Order Code: HD67735-A1 IEC 61850 Server / Modbus TCP Master - Converter ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –...

  • Page 27: Disclaimer

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 27 of 28 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.

  • Page 28: Warranties And Technical Support

    User Manual IEC 61850 Server / Modbus TCP Master Document code: MN67735_ENG Revision 1.000 Page 28 of 28 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
