1. Description.
EXP4IO expansions allows "M" series basestation interfacing with 4 INPUT/OUTPUT channels configurable in couples: analog,
digital, NTC and open collector contacts.
Developed to improve wireless basestation features (
connected to expansion bus onboard on basestations. The expansion configuration is performed using the
software.
To connect expansions to basestation and setup the system for sample export toward outputs, refer to
Manual R29" chapter "Wireless basestation expansions".
2. EXP4IO expansion types.
•
EXP4IO-00: 4 NTC10K output channels expansion to be coupled with COSTER central units.
•
EXP4IO-07: 3 NTC10K output channels expansion and 1 NTC1K output channel to be coupled with COSTER central units
provided with EXTERNAL NTC1K probe input.
•
EXP4IO-33: 4 0÷10Vdc input channels expansion.
•
EXP4IO-66: 4 0÷10Vdc output channels expansion.
For each MWDG basestation, up to 4 I/O expansion modules (
Addresses, selectable by rotary switch, starts from position number 1 to position number 4; is recommended to place expansion
modules in address ascending order.
CAPETTI ELETTRONICA s.r.l. - Strada Stratta 57
10090 CASTIGLIONE TORINESE - TORINO - ITALY
VAT 04837130014 - Phone 011.981.98.11 - Fax 011.981.98.210
e-mail info@capetti.it - web www.capetti.it
Picture 1 - Product image
analog and digital inputs and outputs
) can be connected.
with 4 channels each
EXP4IO-xx
User Manual
), are I/O expansion units to be directly
WineCapManager
"WineCap System - User
WA5047E_EXP4IO-xx_User Manual_R09
V4.6
