Page 1 Reaper OSC D700...
Page 2 Reaper OSC This guide shows you how to set up the D700 in Reaper. All pictures provided were taken with Reaper 6.73 but it is also applicable to most other Reaper versions. All files mentioned in this guide can be found on the USB drive, in the Asparion Configurator installation folder or on our website.
Page 3 Step 2: Open Reaper Click on Options->Preferences…...
Page 4 Step 3: Go to OSC Click Add...
Page 5 Step 4: Select OSC from the list Click on (open config directory) from the list Copy all the Reaper files (e.g. Asparion D700 8 Fader.ReaperOSC) in that directory Select (refresh list)
Page 6 Step 5: Configure as shown below Make sure the ports match the ports selected in the Asparion Connector. If you want to connect more than one extension, select Asparion D700 16 Fader (resp. 24, 32, …) as Pattern config...
Page 7 Step 6: (optional) To manually assign keys (e.g. the Magic * button), do the following: Go to Actions->Show action list… Choose an action and click Add… and then assign the button by clicking it...
Page 8 Hints: With the knobs Pan, EQ, Send and FX you can assign a function to the encoders. With a click on the encoder, you can reset the parameter The EQ button will assign the Receive channels to the encoders. The actual EQ can be controlled via the FX button like all other plugins In FX mode you can control the currently selected plugin.
Page 9 For more information visit www.asparion.de...
