Main Features SBS function The SBS function produces rich, deep bass tones for a more power- ful overall sound. FM Radio Reception You can listen to FM radio using various functions such as the automatic tuning, preset FM stations, and etc. Album function The Album function allows easy browsing and searching of your...
Contents Safety Warning Buttons and Controls Preparation before using your unit How to Connect Using the rechargeable batteries Using standard batteries (not supplied) In-car use CD Playback MP3-CD Playback Skip/Search function Mode function Last Memory/SBS function ESP/Album function +10 button Program function To confirm the program To change the program...
Safety Warning Take care not to allow dust or other contami- nants to come into con- tact with your player. Do not put anything other than a CD (CD-R or CD-RW) inside your player. Such actions will dam- age your player. Do not touch the lens with your finger or scratch it.
Headphone Road safety Do not use the headphones while riding a bicycle, driving any kind of motor vehicle or motorcycle. This is very dangerous and is illegal in certain regions. It is dangerous to listen to headphones at high volume while crossing roads. In order to protect your hearing Do not wear the headphones with the volume set too high.
Buttons and Controls Main Unit Accessories STA-1 (AH59-01065A) (AH30-00038A) (AH59-01100A) Remote Control Headphone Car Cassette Adaptor...
Page 7
Program button (Refer to pages 20, 21) ESP/Album button (Refer to pages 18, 19) +10 button (Refer to page 18) Skip/Search buttons (Refer to page 15) Stop button Play/Pause button Mode button (Refer to page 16) Bottom of the Main Unit Hold SCJ-1 (AH44-00028A)
Page 8
Buttons and Controls Remote Control Front Rear Radio Belt clip Stop/Power off button Volume FM button • Mo/ST button Skip/Search button Automatic Tuning button CD Power On/Play/Pause button Headphone jack Hold switch (see page 15) Display AL/+10/MEM. button Mode/P.SET button Main Unit connection jack...
Page 9
Display The picture of the display panel below is based on MP3-CD playback. PROGRAM indicator SBS Indicator RANDOM indicator REPEAT indicator ESP Indicator Remaining Battery Power indicator Anti-S.T. (Anti-shock Time) Buffer Level meter Playtime indicator Track Number indicator Album Name indicator (MP3-CD Only) Title (track title &...
Connection to External Device (if necessary) * Your CD Player may be connected to the AUX IN jack of an external device 1. Reduce the volume of the external device 2. Connect the Line Out jack to the Input jack of the device with a...
Using rechargeable batteries Open the cover of the battery compartment Insert the rechargeable batteries into the battery compartment. • Carefully check the correct orientation of the positive and negative terminals of the battery. An AC adaptor must be connected to the AC outlet and power input.
Preparation before using your unit Using standard batteries Attach the external battery pack as shown in the picture. • Then, turn the lock control to secure firmly in place. Open the cover of the battery compartment. Carefully check the correct orienta- tion of the positive and negative ter- minals of the batteries.
Carefully insert the car cassette adaptor into the car radio’s cassette compartment. Start the CD player and adjust the sound with the car radio controls. If no sound is heard or the car cassette adaptor is removed, change the playback direction on the car cassette deck.
CD Playback Slide the Open button to open the door. Insert a CD. • Push the door to close it. Press the Play/Pause ) button. • Once the CD is recognized, playback commences. To stop playback, press the Stop ( ) button.
) button. • The inserted MP3-CD will be scanned for about 30~90 seconds. Playback will then commence. Your CD Player will take a few moments to scan through all the tracks recorded on a MP3 CD. To stop playback, press the Stop ( ) button.
• Buttons pressed during CD playback will not function. (On the display, the “Hold” indicator will flash.) • Use the HOLD function when carrying your CD Player around with you. Use of this function will allow you to conserve battery life as it prevents the CD Player from being turned on unintentionally if a button is pressed.
Mode function Briefly press the Mode button to activate the Repeat function or hold it down for longer to activate the Random function. Repeat function Press the Mode button. (Press Mode/P.SET button on the remote control) • Each time the button is pressed, REP1, REP ALBUM and REP ALL are selected.
Last Memory function When MP3-CD playback is selected again after your CD player has been stopped or turned off, the unit plays back from the point that you last listened to. • Press and hold the Last Memory/SBS but- ton.
ESP/Album function (Electronic Skip Protection) Press the ESP/Album button. • CD Playback: Press the ESP/Album button to turn this function on and off. (During playback of an MP3-CD, ESP will always be active whether or not the ESP/Album button is pressed.) •...
Page 20
ESP/Album function (continued) Album Function Press the ESP/Album button. (Press +10/Album button on the remote control) • It moves to the next album. Example) Pressing the ESP/Album button during playback of the first album will take you to the start of the first track of the second album.
Program function You can store up to 30 tracks of your favorite tunes. Example: When storing track number 4 to program number 1. From Stop mode, press the Program button on the main unit. Using button, select the desired track. Press the Program button.
Program function (continued) To confirm the program From Stop mode, press the Program • button. Each time the button is pressed, • track numbers will be shown on the display according to their program sequence. To change the program To change the programmed tracks during program •...
Listening to FM Radio To tune in a station Press and hold the -FM button on the remote control. • The frequency of the received station appears on the display of the remote control. • Press the button to select either mono or stereo (MO/ST).
Presetting Stations You can either manually or automatically preset and store FM stations. Manually presetting stations EXAMPLE: Storing an FM station at 89.1 MHz into preset number 2 Tune to a station of 89.1 MHz and then press the AL/+10/MEM button on the remote control.
Page 25
Automatically presetting stations Press and hold the Mode/P.SET button on the remote control. • "PSET" flashes. Then, each frequency of the received station is incrementally stored into the preset numbers from 1 to 15. • When a station is stored, the station is heard for about 3 seconds before the automatic preset tuning resumes again.
Features Playback sequence of albums and tracks • When using Windows Explorer. • The arrows indicate playback sequence of albums and tracks. • Albums with .jpg, .wav or .doc are not audio files and therefore will be skipped. (E) CD-ROM drive ALBUM 01 Skipped Kevin01.mp3...
Maintaining and looking after your unit Looking after your CDs Wash the disc with a neutral detergent diluted in water, and then wipe gently with a soft dry cloth from the center of the disc to the outside. Handling your CDs Carefully pick up the disc by its edge without touching the disc’s surface.
Troubleshooting Guide Problem Unit has no power. Playback does not func- tion. Headphones don’t work. A sound or track is skipped. Some of the MP3 files on a CD are not recognised. Check Did you insert the battery with the correct polari- Are the batteries drained? Is the AC adaptor connected correctly? Is the door open?
Specifications Frequency range Signal/noise ratio Channel Separation Total harmonic distortion D/A conversion Headphone output Line out output Scope of playback supported DISC Sizes Diameter Dimensions File Compatibility • The unit will playback files created in MP3 format (Mpeg1.Layer 3) with *.mp3 as their extension.
Page 30
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.
Page 31
OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDEN-...
Page 32
SAMSUNG ELECTRONICS AMERICA, INC. SERVICE DIVISION 400 Valley Road, Suite 201 Mount Arlington, NJ 07856 1-800-SAMSUNG (1-800-726-7864) www.samsungusa.com AH68-01096Q...
